Oriflow Rhino Operating Instructions Manual page 8

Determining Which Orifice Plate to Use (continued)
Table 7 – Tester Capacities using the 125 mm Orifice Plate
System Static
Pressure
(Pa)
500
1000
1500
2000
2500
3000
3500
4000
Table 8 – Tester Capacities using the 159 mm Orifice Plate
System Static
Pressure
(Pa)
500
1000
1500
2000
2500
3000
3500
4000
© Copyright 2018 ORIFLOW LLC
Minimum
Maximum
Leakage*
Leakage
(L/s)
(L/s)
125 560
125 520
125 480
125 430
125 380
125 310
125 240
125 175
Minimum
Maximum
Leakage*
Leakage
(L/s)
(L/s)
215 730
215 670
215 630
215 560
215 510
215 425
215 310
215 230
7
Rev: 03-2018
