Oriflow Rhino Operating Instructions Manual page 7

Determining Which Orifice Plate to Use (continued)
Table 4 – Tester Capacities using the 50 mm Orifice Plate
System Static
Pressure
(Pa)
500
1000
1500
2000
2500
3000
3500
4000
Table 5 – Tester Capacities using the 75 mm Orifice Plate
System Static
Pressure
(Pa)
500
1000
1500
2000
2500
3000
3500
4000
Table 6 – Tester Capacities using the 100 mm Orifice Plate
System Static
Pressure
(Pa)
500
1000
1500
2000
2500
3000
3500
4000
© Copyright 2018 ORIFLOW LLC
Minimum
Maximum
Leakage*
Leakage
(L/s)
(L/s)
17 87
17 78
17 73
17 66
17 57
17 47
17 35
17 26
Minimum
Maximum
Leakage*
Leakage
(L/s)
(L/s)
40 195
40 180
40 165
40 145
40 130
40 105
40 80
40 60
Minimum
Maximum
Leakage*
Leakage
(L/s)
(L/s)
75 370
75 340
75 310
75 280
75 245
75 195
75 155
75 105
