Extension Cord Requirements

If you need an extension cord, is it the proper gauge? See Table 2 below for
extension cord requirements.
Table 2 – Required Extension Cord Wire Gauge
Flow
Control
Option
VFD
Slide Gate
VFD
Slide Gate
VFD
Slide Gate
VFD

Flex-Duct Length

Make sure you have enough flexible-duct with your tester for the job. Each tester
includes 3.8 m, which is enough for most applications. Extra lengths of flexible-duct
are available at www.oriflow.com/products.

Determining Maximum Allowable Leakage

To determine the maximum allowable leakage for the project, use ORIFLOW's free
online programs to make these calculations (www.oriflow.com/programs).
Calculations are done for either of the two typical specifications: percentage of
system flow, or leakage class. If the specification uses leakage class, you will need
to calculate the total duct system surface area. Oriflow has a free Adobe form
available to our customers that will calculate duct surface area given the duct shape,
dimensions and length.
© Copyright 2018 ORIFLOW LLC
Rhino Model
Voltage Phase
230 1
230 3
230 3
380 3
380 3
460 3
460 3
4
Extension
Wire
Cord Length
Gauge
(meters)
3 to 15 10
15 to 30 10
3 to 15 14
15 to 30 14
3 to 15 14
15 to 30 14
3 to 15 14
15 to 30 14
3 to 15 14
15 to 30 14
3 to 15 14
15 to 30 14
3 to 15 14
15 to 30 14
Rev: 03-2018
