Waydoo Flyer ONE Quick Start Guide
5. The motor stops rotating during use:
Immediately release the trigger of the remote control to stop the motor, turn o the remote control, and lay on
the board and paddle back to land using your hands. Check whether the status indicator of the remote control
shows normal connection status. Next, check whether the battery level is normal, and then check whether the
powertrain and the board are loose. If it is loose, tighten it in time. If the problem is not solved after attempting
the above steps, remove the battery and check whether sea water has seeped into the metal joints or if there is
any corrosion. If the above situation has occured, rinse the plug with fresh water and dry it with a rust remover to
remove the rust on the metal joints. Finally, wash and dry the plug.
EN
6. The machine shakes, vibrates, and it is di cult to maintain balance during use: Immediately release the trigger
of the remote control to stop the motor, turn o the remote control, lay on the board, and paddle back to land
using your hands. Remove the battery and check whether the mounting bolts of the power assembly are loose. If
loose, tighten them in time.
7. The remote control connection appears intermittent during use: Immediately release the trigger of the remote
control to stop the motor, turn o the remote control, lay on the board, and paddle back to land using your hands.
Turn on the remote control and check whether the Bluetooth icon is ashing. If it is ashing, restart the battery
and pair again using Bluetooth. If the problem is still not resolved, contact after-sales service in time.
8. The remote controller has a fault: "Err.1" = Angle sensor initialization failed. "Err. 2" Spi ash initialization failed.
"Err. 3" = Angle sensor and spi ash initialization failed. "Err. 4" = GPS failed. "Err. 7" = Angle sensor initialization,
spi ash initialization, and GPS failed.

Maintenance

Regularly check the waterproof components (such as the Jet ONE Controller, the PowerFlight Cell, and the mast
head) for damage and the status of each module of the power system and control system.
1. After using the product, turn o the Jet ONE Controller and PowerFlight Cell.
2. To clean the Power Assembly & Wing Set, align the water inlet of the motor mount with a fresh water pipe, and
clean the motor mount for approx. 30 seconds to ensure that the motor mount is clean and free of debris. Next,
clean the motor shroud, propeller, and propeller guard. Afterwards, clean the mast plug. Make sure to remove any
salt, sand, or other debris that is found. Finally, clean the mast.
3. Clean the board, battery mounting position, and the mast mounting base and other parts with fresh water to
ensure that there is no salt, sand, or other debris remaining. Wipe with a dry towel and let sit in a dry environment
to remove the remaining water.
4. Clean the battery, battery integrated ports, and buttons with fresh water. Use a dry towel and let stand in a dry
environment to remove the remaining water.
5. Clean the remote control. Pay special attention to the location of the remote control trigger. If you nd that
there is a jam when pulling the trigger, check whether there is any gravel in the trigger. If so, rinse the gravel out
with clean water.
13

All rights reserved by Waydoo

6. After cleaning, wait for the moisture of all parts to dry before putting the parts back into the package.
7. When storing this product, avoid direct sunlight. Ultraviolet rays and high temperatures will cause permanent
damage to the product.
8. To ensure safety, make sure to turn o the remote control and battery when transporting this product.
Waydoo Flyer ONE – Warranty Period
EPP Board
Mast & Power Assembly
Main Wing and Tail Wing
PowerFlight Cell 1 year (or less than 300 cycles)
Jet ONE Controller
Fast Charger
After-sales Service Plan
1. When contacting Waydoo, explain in detail the problem with the product.
2. Waydoo's technical support sta will try to diagnose and solve your problem by phone, email, or remote
assistance.
3. If you still cannot solve your problem, send the product to Waydoo for further testing. Waydoo will arrange
services for you according to the corresponding warranty service type of the product.
Non-after-sales Coverage
1). Damage caused by transportation or loading and unloading during the return, exchange, and repair. 2). Any
unauthorized modi cation, disassembly, opening, and repair without o cial authorization. 3). Battery damage
caused by any accidental factors or human factors, such as obvious hard object damage, cracks, severe deforma-
tion, broken power cord, disconnection, etc. 4). Product failure or damage caused by installation, use, mainte-
nance, and storage not in accordance with the requirements of the instruction manual. 5). Damage due to circuit
modi cation, battery pack modi cation, or using unmatched chargers guided by uno cial instructions. 6).
Damage caused by using outside the safe load range of the product. 7). Damage caused by forced use of the
product when the parts are damaged. 8). Damage caused by using batteries with quality problems. 9). The
product or component has the identi cation label changed or removed. 10). Failure or damage caused by force
majeure (such as re, earthquake, ood, etc.). 11). Products or parts that have exceeded the warranty period.
Waydoo Flyer ONE Quick Start Guide
1 year
1 year
1 year
1 year
1 year
14
