Waydoo Flyer ONE Quick Start Guide
EN
Normal Mode Speed Limit Mode
Switching Working Mode:
Menu
Mode
Units
Language
return
Short press "+" and "-" simultaneously when the Jet
ONE Controller is powered on to enter Settings.
Scroll through the menu by pressing the "+" or "-" and
press the Power Button to con rm.
Mode Mode
speed limit off speed limit
return top gear
return
After entering the sub-menu, use "+" or "-" to scroll
and press the Power Button to select the Mode. Press
"+" or "-" to switch and press the Power Button to
con rm. The highest gear can be adjusted in speed
limit mode.
5
All rights reserved by Waydoo
Finally press "+" or "-" to scroll to the return option, and
press the Power Button to con rm until you exit the
Settings. Refer to the Units and change operation as
follows:
Menu
Mode
Units
Language
return
Units Units
Units kph Units
return return
For languages, refer to the Language and change
operation work as the following mode operation.
Menu
Mode
on
Units
24
Language
return
语言切换
Language
语言切换
Language
EN
返回
return
PowerFlight Cell
The PowerFlight Cell can be embedded in the board
and has an average battery life of 55-85 minutes. The
battery has a capacity of 32500mAh and the voltage is
14S/58.8V. Additionally, the built-in AL system tracks
the battery status, allowing for a safer user experience.
1
2
3
(Front)
mph
1. Bluetooth Button
2. Battery Status Display
3. Rotary Lock
Battery
25%
Status Indicators
Fast Charger
Adopting an aluminium alloy diecasting , the Fast
Charger has an input voltage of 90-260 V, output
voltage of 58.6-59 V, charging current of 16-18 A, and
a protection level of IPX6.
中文
1
1. Integrated Line 2. Power Cord
3. Indicator Light
Waydoo Flyer ONE Quick Start Guide
Charging Status Description
LED
Steady blue light
4
5
Flashing blue light
Flashing green light
Full green light
(Back)
4. Power Button
Note: Fully charge the PowerFlight Cell when using for
5. Integrated Port
the rst time. Make sure to use the standard charger.
Fault Indicator
Output Indicator
100%
Charge the PowerFlight Cell
1. Connect the charger' s integrated line to the battery
integrated port.
2. The charger power indicator shows a steady blue
light indicating standby mode; then short press the
2
linking switch on the smart battery, and the indicator
will change from a steady blue light to a ashing blue
light, waiting for communication; then the ashing
3
blue light turns to ashing green, indicating that it
enters the charging mode.
Status
EN
Standby
Connecting
Charging
Fully charged
6
