Fluid Tank
❑ Remove factory washer fluid tank
❑ Drill 7/8" hole in tank and install supplied self sealing bulkhead
❑ Reinstall fluid tank
Pump
❑ Mount pump using supplied screws (as near the tank as possible)
❑ Attach ground wire to chassis ground
Nozzles
❑ Remove engine component where nozzle will be installed
❑ Drill 11/32" hole in component
❑ Install filter in nozzle
❑ Install nozzle into engine component
❑ Reinstall engine component
Tubing
❑ Run tubing from tank to pump, leaving slack (avoid hot & moving
parts)
❑ Find a place in line for check valve, cut tubing, and install
❑ Attach holders to nozzles
Optional Fluid Level Switch
❑ Drill 7/8" hole in fluid tank, 1-3/4" from bottom of tank
❑ Place switch inside tank and screw in place
❑ Run one wire to chassis ground
❑ Run other wire to LED or buzzer
