DevilsOwn Alcohol Injection System Manual page 2

Alcohol Injection System works:
The DevilsOwn™ Alcohol Injection System begins with a connection to a
supply tank containing a methanol/water mixture. We recommend
DevilsOwn Brew for use with our products. This mixture is pumped at high
pressure through the tubing to the nozzle holder. The amount of alcohol
and water that is injected through the nozzle is easily adjusted by means of
metering the nozzle.
The DevilsOwn™ Alcohol Injection System is designed to work as a
bolt-on kit for stock or mildly modified vehicle. A mildly modified vehicle
includes those with header upgrades, exhaust upgrades, air filter kits, etc. If
major engine modifications have been performed a dual nozzle upgrade
may be required for safe alcohol system operation. Major engine
modifications would
aftermarket cylinder heads, head porting, camshafts, intake manifolds, etc.
Parts
1 Pressure Switch
1 Vacuum Tee
1 Brass Nipple
1 250psi Pump
6ft Wire Loom
15ft Nylon Hose
1 30 Amp Relay
1 Relay Socket
10 ft Red and Black 16GA
wire
Mechanical Bag
1 Brass Check Valve
1 Black Nozzle Holder
2 Nozzles
4 #10 x 1-1/2", Screws
DevilsOwn Injection
How the DevilsOwn™ Base
include
Kit Contents
larger turbochargers,
Electrical Bag
3
1
1
4
Tools Needed
• Drill with 7/8" and 11/32" bits
• 1/8 NPT tap
• 18mm, 7/16", and
9/16wrench
• 1/4" socket with ratchet
• Marker
• W ire cutters
• Electrical tape
(Recommended)
• Multi-meter (Optional)
superchargers,
Blue Posi-Tap™
Red Posi-Tap™
Fuse Holder
6" Long Zip Tie
