Section 7: Optional Parts

Self Sealing Float Switch (optional)
On the side of the tank, drill a 7/8" hole a
minimum of 1" from the bottom of tank. Place
the self sealing float switch inside the opening.
Make sure the arrow on the side of the switch
is pointing down. Tighten slightly past hand
tight. Do not over tighten. Note the 2 wires
coming out of the switch. Take one wire and
run it directly to ground. Take the other wire
and hook up to the ground of an LED or a yellow
wire of the controller.
Dual nozzle (optional)
With this option the check valve is removed
from the nozzle holder. It is placed before
the Y fitting. Then you take the straight
1/8"npt fittings and screw them into the black
90 nozzle holders. We recommend placing
both nozzles at 180 degs. of each other.
Solenoid (optional)
Attach the red wire directly to 12v power.
Attach the black wire to the blue wire of our
controller. If you are not using a controller,
attach the red wire to the red wire of the pump,
the black wire to a ground. Place the 1/8"
fittings into the solenoid. Cut your tubing and
place it inline. Fluid can travel thru it in any
direction.
Nozzle Mounting Adapter (optional)
Drill a 9/16" hole in your intake tube. Pop it in
and tighten. Has an integrated O ring to
eliminate boost leaks.
