Electrum Sabercrafts Smart Saber Aegis Operation Manual page 10

Electrum Unity App
9:41 AM 100%
9:41 AM 100%
9:41 AM 100%
Find more information at ElectrumSabers.com/Resources
9:41 AM 100%
Blade Profiles
This menu allows you to adjust main color, pulse color, clash color, and
clash duration. Pixel Blade effects are also located here, if applicable.
Blade Color
Flicker Setup Color
With Audio/Pulse
Clash Setup Color
Localized Lockup
Sound Settings
This menu has access to your Sound Fonts and Audio EQ effects. Select
a Sound Font at the bottom of this page to begin.
EQ Effect Gains
Smooth File Creation These options allow you to convert a Sound Font
Switch LEDs will "Scroll",
indicating that the process
is ongoing. Do not reset
saber during this process.
9:41 AM 100%
The main color of your blade. This is the color
the blade will be if set to Solid, and the first
color it will use in a flicker, pulse or mixed color
sequence.
This is the secondary color of your blade. If
using any other pixel profile than Solid, your
blade will alternate, pulse or mix in this color
based on the effect chosen.
When using the Flicker Pixel Profile, this will
set the flicker effect to play based on either the
audio peaks, or pulse between main and flicker
colors on a time you set.
9:41 AM 100%
This option sets the clash effect color that you
blade will flash when it detects impact.
On Pixel blades, this option will flash spots of
your blade with your clash and lockup effects,
instead of the entire blade.
9:41 AM 100%
Each of these options allows you to add an EQ
boost to your sound effects: Bass for low tones,
Mid for mid-tones, and Treble for high tones.
These are added in real time, so experiment!
to Smooth Swing. It will generate a series of high
and low tone pairs based on the hum, using the
frequency values specified in frequency setups.
Higher numbers = more deviation from the hum.
9:41 AM 100%
9:41 AM 100%
9:41 AM 100%
10
