STEP 6. Sealing the joint seams; see Detail A. Apply the Butyl Tape 12 over
the end frame joint as follows:
a. Remove the tape's paper backing as it is applied.
b. Press the tape (Mylar side up) firmly onto the end frames especially in
the center where the merchandisers join.
c. Run the tape continuously the full width of the end frames including
the saddle and 3 inches up at the front and rear.
d. DO NOT apply the tape over the removable front shelf supports.
STEP 7. Install the Fascia Joint Trim 4 centered over the fascia joint and fasten
with Screws 9 .
STEP 8. FHM, FHMG, FHMS & FHMSG Models Only—Install the Ambient
Plenum Joint Trim
with an ambient plenum and fasten with Screws 9 .
STEP 9. MHF, MHFH, MHFG & MHFGH Only—Remove the screw near the
end of each of the joining light channels. Position the Light Channel
Retainer 13 so that it straddles the two channels as shown (Detail B).
Secure with the screws previously removed.
3
5 centered over the joint of those merchandisers
P/N 0316517D
