Installation Instructions

STEP 1. Apply the Gasket 1 around the perimeter of the merchandiser as shown
and as follows:
a. Apply the gasket to metal surfaces only.
b. Recess the gasket approximately
c. Avoid splicing the gasket on horizontal runs.
d. Do not stretch gasket around corners.
e. Remove the paper backing after gasket is applied.
STEP 2. After the first merchandiser has been leveled in its permanent location,
move the joining merchandiser firmly against the first to compress the
gasket for a good seal.
STEP 3. Fasten the two merchandisers together through their end frame joining
holes with Cap Screws 6 , Flat Washers 7 , and Hex Nuts 8 .
STEP 4. Install the Front Panel Joint Trim 2 centered over the merchandiser joint
and fasten using Screws 9 .
STEP 5. Install Rubrail Joint Trim 3 as follows:
Merchandisers Without Glass Fronts
Place rubrail joint trim centered over merchandiser joint. Drill pilot
holes into rubrail and fasten trim with Screws 9 .
Merchandisers With Glass Fronts
Place rubrail joint trim centered over merchandiser joint.
Insert Screw 10 through hole in trim and fasten in place
with Wing Nut 11 .
2
1
CAUTION:
DO NOT USE THE CAP SCREWS
TO PULL THE MERCHANDISERS TOGETHER
DAMAGE TO THE MERCHANDISER AND
END FRAME DISTORTION
CAN RESULT
-inch in from the exterior surfaces.
/
8
.
.
