- Page 1 EPAC BICYCLE ELECTRIC PEDAL-ASSISTED CYCLE USER MANUAL PIUMA For information, technical support and assistance, visit www.argentobike.it...
-
Page 3: Table Of Contents
HARGING THE BATTERY ...................... 11 ONTROL DEVICES ........................11 HEELS ......................11 RAKING SYSTEM ........................12 SSEMBLY PIUMA ................... 12 MODEL ASSEMBLY ................13 AXIMUM LIMIT OF THE SEAT POST ..............14 AINTENANCE INSTRUCTIONS AND ROADING ........................14 LEANING ....................14 HAIN LUBRIFICATION .................... -
Page 4: Foreword
1.2 Assistance Service For any inconvenience or request for clarification, contact without hesitation the Assistance Service of your authorized ARGENTO dealer, who has competent and specialized staff, specific equipment and original spare parts. 1.3 Graphical form of safety warnings To identify the safety messages in this manual, the following graphic warning symbols will be used. -
Page 5: Safety Warnings
For any data not included or not deducible from this manual, it is recommended to consult directly the Assistance Service of your authorized ARGENTO dealer. 2.3 Warnings for users - It is forbidden to load a passenger. -
Page 6: Maintenance Warnings
Original spare parts Use only original ARGENTO spare parts. Any liability of the manufacturer for damage or loss of functionality caused as a result of using non-original accessories and parts is excluded. -
Page 7: Description Of The Bicycle (Epac)
3. DESCRIPTION OF THE BICYCLE (EPAC) 3.1 Parts list 1. R EAR LIGHT ARRIER 3. B SAMSUNG 36V ATTERY 4. S 5. F RAME FOLDING DEVICE 6. S 7. D ISPLAY 8. S SHIMANO HIFTER 9. B RAKE LEVER 10. F RONT LIGHT 11. -
Page 8: Terms Of Use
3.2 Terms of use The pedal-assisted bicycle was designed and built to be driven outdoors, on public roads and on cycle paths, but always on asphalted surfaces. Any modification of the state of construction can compromise the behavior, safety and stability of the pedal-assisted bicycle and can lead to an accident. Other types of use, or the extension of use beyond that envisaged, do not correspond to the destination assigned by the manufacturer, and therefore the manufacturer cannot accept any responsibility for any resulting damage. -
Page 9: Lifting And Transport
Strictly forbidden actions Ride the pedal-assisted bicycle for uses other than those for which it was built, i.e. a passenger's pleasure craft. Ride your pedal-assisted bicycle in areas where there is a danger of explosions. Ride your pedal-assisted bicycle in adverse weather conditions (pouring rain, hail, snow, strong wind, etc.). -
Page 10: Commissioning
5. COMMISSIONING 5.1 Charging the battery Before using the bicycle for the first time, it is necessary to charge the battery for at least 4-6 hours, until charging is complete, using the battery charger supplied. The average charging time is around 4-6 hours. The batteries are of the lithium type 36V. -
Page 11: Control Devices
Precautions when charging Always connect the plug to the battery and then the power plug to the mains. When recharging is complete, always disconnect the plug from the mains first and then the plug from the battery. Always recharge the battery completely. Always use original power supplies. -
Page 12: Assembly
6. ASSEMBLY 6.1 PIUMA model assembly 1. Carefully remove the bike from the packaging, then remove all the protective material, being careful not to scratch the painted parts and not to pull the bike cables. The removal of the bike from the packaging must be carried out by two adults, in order not to incur injuries or crushing. -
Page 13: Maximum Limit Of The Seat Post
• In the event that, during the assembly, unclear passages or difficulties in the assembly itself should be encountered, DO NOT RIDE THE ASSISTED BIKE. • Contact the Assistance Service of your authorized ARGENTO dealer. 6.2 Maximum limit of the seat post IT IS STRICTLY FORBIDDEN... -
Page 14: Maintenance Instructions And Roading
This manual does not include information regarding disassembly and extraordinary maintenance, since these operations must always be carried out exclusively by the staff of the Assistance Service of your authorized ARGENTO dealer. The Assistance Service is able to provide all the information and to answer all requests to take care of and keep your pedal-assisted bicycle perfectly efficient. -
Page 15: Checking The Parts
7.3 Checking the parts The supporting frame of the pedal-assisted bicycle and the welds must be free of visible defects such as: cracks, deformations, incisions, corrosions, etc. Make sure that all the bolts and pedals of the pedal-assisted bicycle are properly tightened. -
Page 16: Led Display
8. LED DISPLAY 8.1 Foreword The pedal-assisted bicycle is equipped with an LED display for the complete management of all the functions provided for your bike. 8.2 Main features The LED display is equipped with: 1) Display on / off button. 2) Management of the pedal assistance level (low-med-high level available). - Page 17 Allowed speed The maximum speed allowed by law is 25km / h. Any interventions not authorized by the manufacturer to the control unit exclude the manufacturer of any damage caused to people and / or things, also the warranty on the purchased product is invalidated. The control unit has been programmed not to allow changes to the maximum speed parameter.
-
Page 18: Connection Diagram
9. CONNECTION DIAGRAM... - Page 19 DISTRIBUTED BY:...
