ARGENTO Alpha User Manual

Hide thumbs Also See for Alpha:
Table of Contents

Advertisement

Quick Links

Download this manual
This manual is valid for the following electrically power assisted cycles (EPAC)
For information, technical support, assistance or to consult the general terms of the warranty, please contact your
English
Alpha
Omega
Contents
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
User manual
Instructions translated from the original Italian
Thank you for choosing this product.
dealer or visit www.argentobike.it
01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Alpha and is the answer not in the manual?

Questions and answers

Related Manuals for ARGENTO Alpha

Summary of Contents for ARGENTO Alpha

  • Page 1: Table Of Contents

    English This manual is valid for the following electrically power assisted cycles (EPAC) Alpha Omega Contents Introduction Warnings on use and safety Product overview Technical data sheet Assembly Display Battery First use Storage, maintenance and cleaning Liability and general terms of warranty...

  • Page 2: Introduction

    1. Introduction Overview This manual is an integral and essential part of the electrically power assisted cycle (EPAC). Before using the bike for the first time, it is essential that users read, understand and strictly observe the requirements outlined below. M.T.
  • Page 3 CAUTION Using the electrically power assisted cycle All users must have read and understood the instructions and information outlined in the manual. If, during assembly, any factory defects are detected, certain steps are unclear or issues with assembly or adjustments occur, do not ride the vehicle and contact your dealer or visit www.argentobike.it for technical support.
  • Page 4 It is the user’s responsibility to ascertain the suitability of the devices used for passenger transport in terms of construction characteristics, safety systems, anchoring systems and their installation and assembly on the electrically power assisted cycle based on its structure and within the permitted load limits (maximum load supported by the bike and by the luggage rack supplied, if present).
  • Page 5 Any other types of use, or any extensions of use beyond the one intended, do not correspond to the intended use attributed by the manufacturer and the latter, therefore, disclaims all liability for any resulting damage. The autonomy of the battery supplied with the electrical power assisted cycle, and therefore the relative travel data in estimated km, can vary significantly depending on the specific methods of use (total load transported, muscle contribution provided by the rider, level of electrical assistance to the selected pedal, frequency of departures/restarts), on the mechanical and electrical conditions of the product (tyre pressure and wear, battery efficiency level) and external...
  • Page 6 • Use the electrically power assisted cycle under the influence of alcohol or drugs. • Use the electrically power assisted cycle in areas at a risk of fire, explosions or in places with a corrosive and/or chemically active atmosphere. • Use the electrically power assisted cycle in adverse weather conditions (heavy rain, hail, snow, strong wind, etc.). •...

  • Page 7: Product Overview

    3. Product overview Alpha Saddle 21. Pedal (right side) Seat post 22. Front tyre Seat post clamp 23. Front wheel rim Rear wheel padlock 24. Front wheel Rear luggage rack 25. Quick-release front wheel Rear LED light 26. Front disc brake Rear mudguard 27.
  • Page 8 Omega Saddle 21. Pedal (right side) Seat post 22. Front tyre Seat post clamp 23. Front wheel rim Rear wheel padlock 24. Front wheel Rear luggage rack 25. Quick-release front wheel Rear LED light 26. Front disc brake Rear mudguard 27.

  • Page 9: Technical Data Sheet

    4. Technical data sheet Product description Product code EAN code Alpha AR-BI-220011 8052679456062 General information Display LCD - CDC13-BT Motor Bafang 36V 250W - rear brushless Battery Li-Ion 36V 10.4Ah 374Wh - integrated Front and rear mechanical disc brakes - brake levers with cut-off sensor...

  • Page 10: Assembly

    5. Assembly Carefully remove the bike from the packaging* and remove the protective material taking care not to damage the relevant aesthetic parts or force the cables and pre-assembled components. *The bike must be removed from the packaging by two adults to ensure that it is not damaged and avoid the risk of injury and/or crushing.
  • Page 11 Front mudguard installation Remove the front light fixing screw located in the front part of the fork to allow the fender bracket to be inserted; secure the fender together with the front light to the top of the fork using the previously removed screw. Subsequently (also after installing the front wheel), secure the side supports of the front fender to the corresponding fork stems by removing, and subsequently inserting, the screws on them (right and left side) taking care to screw them gradually and alternately until tightened.
  • Page 12 Installing and positioning the seat post Insert the seat post into the seat tube of the frame and, after positioning the saddle correctly, secure the seat post firmly using the special clamping device (seat post clamp) on the frame. DANGER Minimum insertion seat post insertion limit For structural and safety reasons, it is strictly forbidden, when using the bike, to extract the seat post from the seat tube of the frame beyond the limit indicated on the latter to avoid the risk of causing any structural fractures to the bike and incurring...
  • Page 13 relative part/component being fixed is not mobile and/or unstable if subjected to a vigorous attempt to remove and/or extract (handlebar, seatpost channel, wheels, etc.) and by verifying that the tightening lever has adequate resistance during the closing phase (such as to leave a mark on the palm of the hand used for lever tightening, so-called "imprint on palm") and, after closing, requires a considerable force to be exerted to allow relative opening.

  • Page 14: Display

    6. Display The electrically power assisted cycle has a control device on the handlebar, LCD display, powered by the battery supplied with the bike which controls all the bike’s electrical and electronic functions. • LCD display - CDC13-BT Overview of controls and symbols Indicator light for light ON 2.
  • Page 15 CAUTION The walk assist mode must be used in compliance with the regulations in force in the country of use and is only allowed when pushing the electrically power assisted cycle by walking alongside the bicycle and holding the handlebar grips firmly with both hands.

  • Page 16: Battery

    Press the + or – buttons to select the unit of measurement for the speed and travel data displayed on the display: International metric system (Km/h and Km) or British imperial system (MPH and Mile) P2 - User password ON/OFF display: Available options = on / off OFF = selecting “off”, confirmed by pressing the M button, excludes the user password request (identification code) to allow the user to access and activate the display and allow full control of all the functions provided for the electrically power...
  • Page 17 EPAC Battery charger INPUT Battery charger OUTPUT Recharge life Alpha AC 100V-240V 1.8A (Max) DC 42V 2.0A (Max) 4-6 h Omega AC 100V-240V 1.8A (Max) DC 42V 2.0A (Max)
  • Page 18 Battery charging jack Power supply jack Battery charging LED indicator light CAUTION Using a battery charger that differs from the one supplied, which is not suitable or approved, to charge the e-bike battery may damage it or involve other potential risks. Never leave the e-bike unsupervised while it is charging.

  • Page 19: First Use

    DANGER Battery warnings The battery consists of lithium-ion cells and chemical elements that are hazardous to health and the environment. Do not use the item if it emits odours, substances or excessive amounts of heat. Do not dispose of the item or the battery with household waste.

  • Page 20: Storage, Maintenance And Cleaning

    Handlebars The handlebar can be adjusted in height and inclination by working on the relative fixing systems on the handlebar attachment. To adjust the angle of the handlebars, loosen the clamp on the stem, rotate the handlebars until the desired position is reached and secure it by tightening the clamp until it can no longer be moved.
  • Page 21 All the maintenance operations must be performed with the battery detached and the bike resting on the kickstand. The different parts that make up the bike are subject to various types of wear from use. In particular, the following components should be regularly checked and serviced: tyres, wheels, brakes, gears, chain, suspension and frame.
  • Page 22 This manual does not provide in-depth information regarding disassembly and extraordinary maintenance, as these operations must always be carried out exclusively by the authorized dealer's Support Service personnel. The Assistance Service is able to provide all the indications and to respond to all the requests to take care of and keep your pedal-assisted bicycle perfectly efficient.

  • Page 23: Liability And General Terms Of Warranty

    It is the user’s responsibility to ascertain the suitability of the equipment used to transport the bike by fitting and installing devices (e.g. bike racks) in accordance with the legal requirements of the country in which it is ridden. CAUTION The manufacturer is not liable for any breakages caused by lifting and/or transporting the electrically power assisted cycle after delivery.

  • Page 24: Information On Disposal

    11. Information on disposal CAUTION Handling of the electrical or electronic device at the end of its service life (applicable in all European Union countries and in other European systems with separate collection systems) This symbol on the product or packaging indicates that the product should not be considered as normal household waste, but should be taken to a facility authorised to dispose of waste from electrical and electronic equipment (WEEE).

  • Page 25: Declarations Of Conformity

    Model code Generic denomination Trademark batch number (s) AR-BI-220011 Alpha ARGENTO E-MOBILITY AR2222XXXXX The object of the declaration described above fulfils all the relevant provisions of the following Directives: Directive 2006/42/CE on machinery. Directive 2014/30/EU on the harmonization of the laws of the Member States relating to electromagnetic compatibility.
  • Page 26 Serial identification number (s) and/or Model code Generic denomination Trademark batch number (s) AR-BI-220012 Omega White ARGENTO E-MOBILITY AR2322XXXXX Omega Black AR-BI-220013 ARGENTO E-MOBILITY AR2422XXXXX The object of the declaration described above fulfils all the relevant provisions of the following Directives: Directive 2006/42/CE on machinery.
