- Page 1 Dragonfly Energy Battle Born Batteries Heat Enable Instruction Dragonfly Energy, Corp. 1335 Greg St. STE. 103 Sparks, NV 89431 Phone: 855-292-2831 Email: info@battlebornbatteries.com...
- Page 2 Thank you for purchasing one of our internal heat batteries. Read prior to use. Please note the BB10012H battery model is used in this manual’s diagrams. Tools Upon arrival, please verify your battery has arrived with the following items: Included with every Heat Battery: *See Figure 1 and Figure 2.
- Page 3 Installing a Single Heat Enable Battery Included in every purchase of a heat battery is a standard heater enable jumper wire. See Figure 2. To enable the heating function, use the provided jumper to connect the POSITIVE terminal and the heater enable stud. Step One: Making a connection on the Positive Terminal The 5/16”...
-
Page 4: Installation Steps
Installing the ON/OFF Switch The Heat Battery Kit provides the components for you to install a remote switch for enabling/disabling the heat function of the battery, however it is not a requirement. If you have multiple batteries, we suggest that you configure your daisy chain first, then, instead of installing the jumper from the stud to the positive terminal you install the switch, see Figure 8 for an example. - Page 5 Wiring Examples for Heat Enable: 12V System Figure 14: Heat Enable daisy chained in 12V parallel 24V System Figure 15: Heat Enable daisy chained in 24V series/parallel 48V System Figure 16: Heat Enable daisy chained in 48V series For additional product information, please visit our website. You will be able to find additional product information on any of our internally heated batteries at https://battlebornbatteries.com/product-category/lifepo4-batteries/ under the specific model’s product listing.
