Summary of Contents for Dragonfly Energy DFGC2H
- Page 2 Please read the accompanying battery manual prior to this guide. Thank you for investing in a Dragonfly Energy system and welcome to the Dragonfly Energy family. This guide provides important information on how to install the heat-enable function on your Dragonfly Energy Battery. If you have purchased with us before, you will find this guide useful as a reference tool.
- Page 3 • ¾ inch Forstner drill bit, step bit, or equivalent • 220 grit sandpaper • ½” wrench • ½” socket wrench • torque wrench set to 10 ft-lbs. Figure 4: Additional Tools Needed Dragonfly Energy Heat Enable Instruction Guide | Edition. HIM_HeatedRev008_07282022...
- Page 4 However, once the connection has been made to the heat-enable jumper wire, the connection will be live at 12V. Take care to avoid any contact with other live wires or grounds. Dragonfly Energy Heat Enable Instruction Guide | Edition. HIM_HeatedRev008_07282022...
- Page 5 Step Three: Deactivating the Heat-Enable Function To deactivate the heat-enable function on your heated Dragonfly Energy Battery, simply remove the heat-enable jumper wire from the heat-enable post. Remember to tape down the end of heat-enable jumper wire with electrical tape and cover the ring terminal so it does not make contact with other live wires or grounds.
- Page 6 When the “O” is pressed down the switch is in the open or OFF position. See Figure 11 for an example if the switch in the ON Figure 11: Rocker switch fully installed and in the “ON” position position. Dragonfly Energy Heat Enable Instruction Guide | Edition. HIM_HeatedRev008_07282022...
- Page 7 BMV, that power will not be recorded if Monitoring or when the heating function turns on. The monitoring device will need to be recalibrated. Devices Dragonfly Energy Heat Enable Instruction Guide | Edition. HIM_HeatedRev008_07282022...
- Page 8 Notice: Product improvements and enhancements are continuous; therefore, the specifications and information contained in this document may change without notice. Dragonfly Energy Corp. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
