Installing Mirrors - Hussmann IMPACT Excel C2-X Instructions

Multi-deck Meat, Produce, & Dairy
Mirror Kit
4
6

Installing Mirrors

Snap
Rivet
2
1
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
Push
1
5
5
4
Slides over
and down
6
Installing Mirror into Mirror Retainer Assembly
Note: For factory
installation, begin here:
5 Insert Mirror – 1 into the
Bottom Mirror Clip – 6 and
gently push toward back of
case until it meets the Top
Retainer Assembly – 4.
Upright
IMPORTANT: Check that all
mirror clips are in the upper
position before continuing.
Install Mirror – 1 into the Top
6
Mirror Clip – 6 and slide the
Mirror Clip
to hold the mirror in place.
5
Mirror Clip in
Top Position
2
Mirror Retainer Assembly
(with top mirror clip exploded)
P/N 0376451A
then
OVER DOWN
6
Snap
Slide Over
Rivet
and Down
1
5
