ATTITUDE LTD II
WARNING:
This product contains chemicals known to the State of Cali-
fornia to cause cancer, or birth defects or other reproductive harm.
DO NOT PLACE SOLDER, ELECTRICAL/ELECTRONIC OR PLASTIC
COMPONENTS IN YOUR MOUTH FOR ANY REASON WHAT SO EVER!
Avoid prolonged, unprotected contact between solder and your skin! When
soldering, do not inhale solder fumes or expose eyes to solder/flux vapor!
If you come in contact with solder or components located inside the enclo-
sure of this product, wash your hands before handling food.
EG
011920
ELECTRIC BASS
SERVICE MANUAL
BL
Black
（ブラック）
■ CONTENTS （目次）
（総組立）
（回路図）
.......................................................................4
（配線図）
（総合仕様）
Copyright (c) Yamaha Corporation. All rights reserved.
LVR
Lava Red
（ラヴァレッド）
.................................................2
....................................................4
....................................................5
HAMAMATSU, JAPAN
´08.08
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Yamaha ATTITUDE LTD II
Summary of Contents for Yamaha ATTITUDE LTD II
- Page 1 WIRING ...............4 （配線図） If you come in contact with solder or components located inside the enclo- SPECIFICATIONS ............5 （総合仕様） sure of this product, wash your hands before handling food. 011920 HAMAMATSU, JAPAN Copyright (c) Yamaha Corporation. All rights reserved. ´08.08...
- Page 2 ATTITUDE LTD II ■ OVERALL ASSEMBLY （総組立） Jack Assembly （ジャックの取り付け） F11a F11c F11b Replacement nut is supplied without string slot. E21 E22 E23 F01a FRONT VOLUME: 15A 500KΩ F01c REAR VOLUME: A 500KΩ F01b F01d F01e FRONT TONE: A 500KΩ...
- Page 3 ATTITUDE LTD II PART NO. DESCRIPTION 部 品 名 REMARKS REF NO. QTY RANK OVERALL ASSEMBLY 総 組 立 ATTITUDE LTD II NECK ASSEMBLY ネ ッ ク Ａ ｓ ｓ ｙ (QC22590) BODY 胴 本 体 (QC22570) WH31960 0 TUNING MACHINE ASSEMBLY GB-2L (BN) 糸...
- Page 4 ATTITUDE LTD II ■ CIRCUIT DIAGRAM （回路図） FRONT TONE FRONT VOLUME FRONT PICKUP HIGH CUT FRONT OUTPUT （フロントトーン） （フロントボリューム） （フロントピックアップ） （ハイカット） （フロント出力） A 500KΩ 15A 500KΩ REAR VOLUME REAR PICKUP REAR OUTPUT （リアボリューム） （リアピックアップ） （リア出力） A 500KΩ BPHP-02 ■ WIRING （配線図）...
- Page 5 ATTITUDE LTD II ■ SPECIFICATIONS （総合仕様） ● STANDARD SPECIFICATIONS ● 基本仕様 Scale Length ............863.6 mm 弦長 ................863.6 mm Body-Neck Construction ..........Bolt On 棹接続方法 ............ボルトオン Length ..............1184.6 mm 全長 ................ 1184.6 mm Width ................331 mm 全幅 ................331 mm Net Weight ..............4.0 kg 質量 ................4.0 kg ● COLOR ● ...
- Page 6 ELECTRIC BASS ATTITUDE LTD II...
