Battery Alarm (SetUp Menu)
(Setting Saved in Memory)
Make sure that the SetUp menu is selected, then press the POWER-MENU key until BATTERY ALARM appears. Select Off or 8.5 to 13.5 Volts. Battery Alarm
sounds when the input battery voltage is equal to or less than the menu setting. (Off, 8.5 to 13.5 Volts, Default = Off)
Scroll through all SetUp menu choices to exit the SetUp menu.
Language (SetUp Menu: Int'l Only)
(Setting Saved in Memory)
Make sure that the SetUp menu is selected, then press the POWER-MENU key until LANGUAGE appears (International Units Only). LANGUAGE selects the
display language for menus. (Settings vary, Default = English)
Scroll through all SetUp menu choices to exit the SetUp menu.
Units (SetUp Menu)
(Setting Saved in Memory)
Make sure that the SetUp menu is selected, then press the POWER-MENU key until UNITS appears. UNITS selects the units of measure. (Feet/F, Meters/C,
Fathoms/C, Default = Feet/F for domestic units, and Meters/C for international units, where F stands for Fahrenheit and C stands for Celsius)
Scroll through all SetUp menu choices to exit the SetUp menu.
Channel Select (SetUp Menu)
(Setting Saved in Memory)
Make sure that the SetUp menu is selected, then press the POWER-MENU key until CHANNEL SELECT appears (SmartCast™ user mode only). CHAN-
NEL SELECT selects the type of RSS you are using. (A, B, Default = A)
Scroll through all SetUp menu choices to exit the SetUp menu.
NOTE: The Channel Select setting must match the actual hardware configuration of your RSS in order for the RSS to function. See Using the Advanced RSS for information about
changing the channel of your Advanced RSS manually using the wet switch on the Advanced RSS.
Channel A and B RSS Units
Your PiranhaMax unit comes with an Advanced RSS. This Advanced RSS may be programmed to either Channel A or Channel B. This A/B Channel option
gives you the flexibility to switch to a different channel if another angler is using a PiranhaMax30 or SmartCast™ unit within 150 feet of your RSS to reduce
possible interference. See Changing the Channel on the Advanced RSS for details on selecting either Channel A or Channel B.
NOTE: RSS units, regardless of channel, may generate erratic depth readings as a result of sonar interference when used in close proximity (closer than 40 feet) to each other or to other sonar
devices.
Understanding the Advanced RSS
The Advanced RSS provides the following functionality:
• Water Surface Temperature
• Grayscale Sonar Data
When you are using the PiranhaMax in SmartCast™ mode, grayscale sonar data and water temperature will be displayed automatically on the screen.
You must manually program the Advanced RSS in order to turn the light on or off or to change the RSS channel setting to A or B.
Default settings on new products are Light = OFF and Channel = A.
• Blinking Light for nighttime use
• A/B Channel Select.
