felton industries FEL4PPS Assembly Instructions

WARNING: READ THE ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING THE 4 SIDED PEDESTAL PARK SETTING.
Make sure to wear protective gloves and foot protection when installing and assembling this product. Unpack the unit and make sure all the components are
included before proceeding. This activity requires two o more people as lifting is involved. Please ensure all bolts are only finger-tightened during the assembling
process for flexibility in lining up components. Securely tighten the bolts before anchoring the product to the ground.
ITEM PART
FE4P9 M6 x 25mm. HEXAG. HEAD BOLT
FE4P10 M10x120mm. HEX. HEAD BOLT
FE4P11 M10x110mm. HEXAG. HEAD BOLT
FE4P12 M12x100 mm. HEX. HEAD BOLT
FE4P13
FE4P14
FE4P15
FE4P16
FE4P17
FE4P5
FE4P1
Thank you for purchasing our high quality products. The Interactive 4 Sided pedestal Park Setting has been manufactured with certified materials, to achieve high reliability and minimum mainte-
nance. It is our commitment to provide you cost effective solutions for outdoor applications.
1
Lay the 4 Table planks [FE4P6] upside down and flush ends. Place the table
frame [FE4P5] on top the table planks and attach it with hex. head bolts
[FE4P9] and locknuts [FE4P9] - Finger tighten.
FASTENER DESCRIPTION
M6 LOCKNUT
M10 LOCKNUT
M12 LOCKNUT
M10 PLAIN WASHER
M12 PLAIN WASHER
FE4P 2
[FE4P9x4]
[FE4P13x4]
ITEM PART
QTY
FE4P1
64
FE4P2
2
8 FE4P3 HORIZONTAL SEAT BRACE—SHORT FIXING PLATES
2
FE4P4 HORIZONTAL SEAT BRACE—LONG FIXING PLATES
64
FE4P5
16
FE4P6
4
FE4P7
24
4
FE4P 3/4 FE4P 6/7
[FE4P5]
[FE4P6]
Lay a seat plank [FE4P2] upside down on a flat surface. Have the
seat frame [FE4P2] on top and attach it to the seat plank, by using
hex. head bolts [FE4P9] and locknuts [FE4P13] - Finger tighten.
[FE4P2]
COMPONENT DESCRIPTION
CENTRAL UPRIGHT
SEATING FRAME / LEGS
TABLE FRAME
1000 mm.—TABLE PLANK
900 mm.—SEATING PLANK
FE4P9/11/12 FE4P13/14/15
[FE4P9x4]
[FE4P13x4]
[FE4P7]
QTY
1
4
2
2
1
4
4
FE4P16/17
2
P1
