Now the trampoline is opened and
3.
still upside down, install all 8 pcs of legs.
T bar Assembly:
Attention: There is a hole at the center of the frame tube, before
install the bottom connect bar, please find the hole first (as shown A).
1.Please find out bottom bar (TR06), then install it on the two legs, firstly
removing the rubber cap from these two legs, as shown B and C, Fix the
bottom Bar TR06 with Two TR12 screws with help of Allen Key TR08, then
install rubber cap.
TR12 X 2
A B C
TR08 X 1
2.Now connect the trampoline frame(TR01) and Bottom Bar (TR06) with the
handle bar OUTER (TR05) by two long screws(TR09)
TR09 x2
