Page 2
HOSHIZAKI provides this manual primarily to assist qualified service technicians in the installation, maintenance and service of the icemaker. Should the reader have any questions or concerns which have not been satisfactorily addressed, please call or write to the HOSHIZAKI Technical Support Department for assistance.
[b] KM-1300MWH (Water-cooled) [b] KM-1300MWH (Water-cooled) [b] KM-1300MWH (Water-cooled) [b] KM-1300MWH (Water-cooled) [b] KM-1300MWH (Water-cooled) See the Nameplate for electrical and refrigeration specifications. This Nameplate is located on the upper right hand side of rear panel. Since this Nameplate is located on the rear panel of the icemaker, it cannot be read when the back of the icemaker is against a wall or against another piece of kitchen equipment.
[c] KM-1300MRH (Remote Air-cooled) [c] KM-1300MRH (Remote Air-cooled) [c] KM-1300MRH (Remote Air-cooled) [c] KM-1300MRH (Remote Air-cooled) [c] KM-1300MRH (Remote Air-cooled) See the Nameplate for electrical and refrigeration specifications. This Nameplate is located on the upper right hand side of rear panel. Since this Nameplate is located on the rear panel of the icemaker, it cannot be read when the back of the icemaker is against a wall or against another piece of kitchen equipment.
6) See the Nameplate on the Rear Panel, and check that your voltage supplied corre- sponds with the voltage specified on the Nameplate. 7) This icemaker needs a storage bin. The recommended storage bin is HOSHIZAKI ICE STORAGE BIN, Model B-500 series.
3. LOCATION 3. LOCATION 3. LOCATION 3. LOCATION 3. LOCATION This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within +45°F to +100°F; Normal operating water tem- perature should be within +45°F to +90°F. Operation of the icemaker, for extended periods, outside of these normal temperature ranges may affect production capacity.
Page 12
Before operating the icemaker, the Bin Control Thermostat Bulb must be set correctly. 5) Set the Bin Control Thermostat Bulb as follows. See Fig. 3. (a) Take off the shipping tape securing the Thermostat Bulb Holder. Remove the Ther- mostat Bulb Holder from the Shipping Hook by lifting it up and shifting to the right. (b) Slide the Thermostat Bulb Holder down through the hole located in the bottom of the icemaker until it is placed in the Bracket.
5. ELECTRICAL CONNECTION 5. ELECTRICAL CONNECTION 5. ELECTRICAL CONNECTION 5. ELECTRICAL CONNECTION 5. ELECTRICAL CONNECTION 1. Electrical connection must be made in accordance with the instructions on a “WARNING” tag, provided with the pig tail leads in the Junction Box. 2.
6. INSTALLATION OF REMOTE CONDENSER UNIT 6. INSTALLATION OF REMOTE CONDENSER UNIT 6. INSTALLATION OF REMOTE CONDENSER UNIT 6. INSTALLATION OF REMOTE CONDENSER UNIT 6. INSTALLATION OF REMOTE CONDENSER UNIT [a] CHECKS BEFORE INSTALLATION [a] CHECKS BEFORE INSTALLATION [a] CHECKS BEFORE INSTALLATION [a] CHECKS BEFORE INSTALLATION [a] CHECKS BEFORE INSTALLATION 1) Unpack and remove shipping carton, tape(s) and packing.
The two copper tubings should be insulated sepa- rately. See Fig. 7. • Precharged tubing kits, available as optional equipment from HOSHIZAKI AMERICA, are recommended . 4) Line sets fabricated in the field should be evacuated through the charging ports on the Aeroquip couplings and charged with R-404A refrigerant vapor to a pressure of 15 - 30 PSIG.
3) Connect the Fan Motor leads in the Junction Box of the remote condenser unit to the Fan Motor leads in the Junction Box of the HOSHIZAKI remote air-cooled icemaker. 4) Install a ground wire to the remote condenser unit.
[e] STACKING CONDENSER UNIT [e] STACKING CONDENSER UNIT [e] STACKING CONDENSER UNIT [e] STACKING CONDENSER UNIT [e] STACKING CONDENSER UNIT 1) Secure the lower condenser unit to the Legs with eight bolts (not included). 2) Attach the upper condenser unit on the top of the lower. 3) Secure the upper condenser unit with the four screws provided.
7. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 10 7. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 10 7. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 10 7. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 10 7.
8. FINAL CHECK LIST 8. FINAL CHECK LIST 8. FINAL CHECK LIST 8. FINAL CHECK LIST 8. FINAL CHECK LIST 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within +45°F to +100°F all year around? 3) Is there at least 6"...
9. START UP 9. START UP 9. START UP 9. START UP 9. START UP 1. All parts are factory-adjusted. Improper adjustments may result in failure. 2. If the unit is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the Compressor.
10 . PREPARING THE ICEMAKER FOR LONG STORAGE 10 . PREPARING THE ICEMAKER FOR LONG STORAGE 10 . PREPARING THE ICEMAKER FOR LONG STORAGE 10 . PREPARING THE ICEMAKER FOR LONG STORAGE 10 . PREPARING THE ICEMAKER FOR LONG STORAGE When shutting off the icemaker for an extended time, drain out all water from the water line and remove the ice from the Storage Bin.
Page 23
[2] Remove the water from the potable water supply line: 1) Remove the Front Panel. (Except water-cooled model) 2) Move the Control Switch, on the Control Box, to the “OFF” position. 3) Wait 3 minutes. 4) Close the Potable Water Supply Line Shut-off Valve and open the Potable Water Supply Line Drain Valve.
1. CLEANING INSTRUCTIONS 1. CLEANING INSTRUCTIONS 1. CLEANING INSTRUCTIONS 1. HOSHIZAKI recommends cleaning this unit at least once a year. More frequent cleaning, however, may be required in some existing water con- ditions. 2. To prevent injury to individuals and damage to the icemaker, do not use ammonia type cleaners.
[a] CLEANING PROCEDURE [a] CLEANING PROCEDURE [a] CLEANING PROCEDURE 1) Dilute approximately 27 fl. oz. of recommended cleaner Hoshizaki “Scale Away” or “LIME-A-WAY,” (Economics Laboratory, Inc.) with 5 gallons of water. 2) Remove all ice from the Evaporator and the Storage Bin.
17) Replace the Front Panel in its correct position. 18) Turn on the power supply to fill the Water Tank with water. 19) Turn off the power supply after 3 minutes. 20) Remove the Front Panel, and fully open the Cleaning Valve. 21) Move the Control Switch to the “WASH”...
Page 27
5) Turn off the power supply after 15 minutes. 6) Remove the Front Panel, and then remove the Insulation Panel by first lifting the Top Panel and sliding the Top Panel to the back a little. 7) Remove the Rubber Cap covering the Overflow Pipe in the Water Tank. Remove the Over- flow Pipe by turning it counterclockwise.
2. MAINTENANCE 2. MAINTENANCE 2. MAINTENANCE 2. MAINTENANCE 2. MAINTENANCE This icemaker must be maintained individually, referring to the instruction manual and labels provided with the icemaker. 1) Stainless Steel Exterior To prevent corrosion, wipe the exterior occasionally with a clean and soft cloth. Use a damp cloth containing a neutral cleaner to wipe off oil or dirt build up.
Page 29
HOSHIZAKI HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH PEACHTREE CITY, GA 30269...
