NO.
71172
JULY 7, 2000
ISSUED:
HOSHIZAKI
MODULAR CRESCENT CUBER
MODEL
KM-1300SAF-R
PARTS LIST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KM-1300SAF-R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hoshizaki KM-1300SAF-R

Summary of Contents for Hoshizaki KM-1300SAF-R

  • Page 1 71172 JULY 7, 2000 ISSUED: HOSHIZAKI MODULAR CRESCENT CUBER MODEL KM-1300SAF-R PARTS LIST...
  • Page 2 KM-1300SAF-R Aug. 1999...

  • Page 3: Material Abbreviations

    MATERIAL ABBREVIATIONS ALUMINUM COPPER PLASTIC RUBBER STEEL AUXILIARY CODE (Note)

  • Page 4: Ice Cuber Assembly

    KM-1300SAF-R A. ICE CUBER ASSEMBLY VIEW "A"...
  • Page 5 KM-1300SAF-R A. ICE CUBER ASSEMBLY MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER REFRIGERATION CIRCUIT 1A0207A04 WATER CIRCUIT 2A0835A02 CONTROL BOX ASSEMBLY (HS-1101) 2A1333A01 T2 SCREW 7P31-0408 LABEL LOCATION 2A1711A01 TRANSFORMER BOX ASSY 334324A01 5X10 7B0130510 HEX HEAD BOLT w/ WASHER (LF) EVAP.
  • Page 6 KM-1300SAF-R A. ICE CUBER ASSEMBLY MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER LOUVER (C) 103122-03 TAPPING SCREW - BLACK STEEL, 4X8 433954-01 AIR FILTER (B) 208283G03 AIR FILTER (C) 208284G01 FRONT PANEL 213708-02 TRUSS HEAD SCREW 4X16, SS 7C32-0416 POWER SUPPLY CORD...

  • Page 7: Refrigeration Circuit

    KM-1300SAF-R B. REFRIGERATION CIRCUIT (1/2) 1 1a 3 3a 40 47 4 4a 40 47 40 47 20 21 9 10 2 2a 41 42 43...
  • Page 8 KM-1300SAF-R B. REFRIGERATION CIRCUIT (2/2) 41 42 43 5 5a 6 6a EXPANSION VALVE DETAIL THERMISTOR DETAIL...
  • Page 9 KM-1300SAF-R B. REFRIGERATION CIRCUIT MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER EVAPORATOR 104696A01 REAR FRAME 3A0827G01 T2 SCREW 7P31-0408 SIDE FRAME (A) 219472G01 T2 SCREW 7P31-0408 SIDE FRAME (B) 323901G01 T2 SCREW 7P31-0408 FRONT FRAME 325857-01 T2 SCREW 7P31-0408...
  • Page 10 KM-1300SAF-R B. REFRIGERATION CIRCUIT MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER HOT GAS VALVE BRACKET 442162-01 T2 SCREW 7P31-0408 LINE VALVE BRACKET 4A1406-01 T2 SCREW 7P31-0408 PRESSURE SWITCH ACB-1UB09 433441-07 434938-01 PRESSURE SWITCH BRACKET T2 SCREW 7P31-0408 COPPER TUBE - ACCESS COPPER...
  • Page 11 KM-1300SAF-R B. REFRIGERATION CIRCUIT MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER VALVE BODY 440352-01 COIL - VALVE 440353-01 ABS-25-1-HD-2 BOLT 440353F01 TRUSS HEAD SCREW 7C31-0408 CLAMP 443461-02 DRIER BRACKET 4A0807-01 T2 SCREW 7P31-0408 COPPER TUBE (D) - HIGH COPPER 4A0921-01 SIDE...

  • Page 12: Water Circuit

    KM-1300SAF-R C. WATER CIRCUIT...
  • Page 13 KM-1300SAF-R C. WATER CIRCUIT MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER PUMP MOTOR ASSEMBLY (S-0862) 215692A04 TRUSS HEAD SCREW 5X8, SS 7C32-0508 WATER SUPPLY PIPE COPPER 4A0768G05 T2 SCREW 7P31-0408 RUBBER GASKET SI.R 413854-03 WATER VALVE BRACKET 3A0736-01 T2 SCREW 7P31-0408...
  • Page 14 KM-1300SAF-R C. WATER CIRCUIT MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER FLOAT SW. BRACKET 3A0449-01 T2 SCREW 4X8, SS 7P32-0408 EPDM 3A1325-03 CONNECTOR - FLOAT SWITCH FLOAT SWITCH FS-0893B-1 4A0886-01 TRUSS HEAD SCREW 4X10, SS 7C32-0410 CLAMP No.4253...

  • Page 15: Control Box Assembly

    KM-1300SAF-R D. CONTROL BOX ASSEMBLY 12 13 4 4a 25 22 25...
  • Page 16 KM-1300SAF-R D. CONTROL BOX ASSEMBLY MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER CONTROL BOX 2A0799G01 CAPACITOR - STARTING 4A1094-01 330V 160MFD CAPACITOR-RUN 4A1146-02 440V 35MFD STRAP 434580-08 T2 SCREW 7P31-0408 STARTER 040-0001-38 4A0875-01 T2 SCREW 7P31-0408 MAGNETIC CONTACTOR VC20...
  • Page 17 KM-1300SAF-R D. CONTROL BOX ASSEMBLY MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER BUSHING OCB-875 428394-04 BARRIER 4A1096-01 TRUSS HEAD SCREW 7C31-0406 TOGGLE SWITCH – VDE 8956K172 4A1147-01 CAPACITOR 250V 5MFD 4A2128-04 T2 SCREW 7P31-0408 LOCK WASHER 4, SS 7R22-0400...

  • Page 18: Label Location

    KM-1300SAF-R E. LABEL LOCATION 1 1a...
  • Page 19 KM-1300SAF-R E. LABEL LOCATION MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER EMBLEM - RINNAI PETP FILM 413440G01 FASTENER 7PG1-0300 MODEL NUMBER LABEL PETP FILM 4A0468-48 LABEL - PENGUIN (R) PETP FILM 4A0526-01 LABEL - AIR FILTER PETP FILM 426177-01 MAINTENANCE LABEL...

  • Page 20: Transformer Box Assembly

    KM-1300SAF-R F. TRANSFORMER BOX ASSEMBLY...
  • Page 21 KM-1300SAF-R F. TRANSFORMER BOX ASSEMBLY MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER TRANSFORMER COVER 447956-01 T2 SCREW 7P31-0408 TRANSFORMER PY12-19312 447420-01 TRUSS HEAD SCREW 7C31-0408 BUSHING OCB-500 428394-02 TRANSFORMER BRACKET 447955-01...
  • Page 22 KM-1300SAF-R G. EVAPORATOR...
  • Page 23 KM-1300SAF-R G. EVAPORATOR MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER EVAPORATOR (S-0533) 103444G02 EVAP. BRACKET (A) 323690-01 EVAP. BRACKET (B) 323691-01 END PLATE (A) 323692-01 END PLATE (B) 323693-01 HOOK 324152-01 EVAP. BRACKET 436582-01 COPPER TUBE COPPER 434137-01...

  • Page 24: Pump Motor Assembly

    KM-1300SAF-R H. PUMP MOTOR ASSEMBLY...
  • Page 25 KM-1300SAF-R H. PUMP MOTOR ASSEMBLY MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER PUMP MOTOR 2U0106-01 M91A60SP201 PUMP FLANGE 215662-01 PUMP MOTOR BRACKET 323904-01 TOOTH WASHER M6, SS 7R22-0600 HEX HEAD BOLT 6X40, SS 7B02-0640 FLAT WASHER M6, SS 7F22-0600 SPLIT LOCK WASHER...
  • Page 26 KM-1300SAF-R J. ACCESSORIES...
  • Page 27 KM-1300SAF-R J. ACCESSORIES MODEL TITLE INDEX DESCRIPTION MATERIAL PART REQUIRED NUMBER OR MODEL NUMBER NUMBER INSTRUCTION MANUAL PAPER 91A1KG11A INSTALLATION MANUAL PAPER 91A1DK10A UNIVERSAL BRACE 4A0363-01 HEX HEAD BOLT 5X12, SS 7B02-0512 THUMBSCREW ABS, SS 415949G01 THERMOSTAT EXTENSION 3A0408-01 BRACKET TRUSS HEAD SCREW 4X10, SS 7C32-0410...
