  • Page 1 MODULAR CRESCENT CUBER KM-1300NRF INSTRUCTION MANUAL HOSHIZAKI MODEL ISSUED: JUNE 1, 2000 REVISED: JUNE 7, 2000...
  • Page 2 HOSHIZAKI provides this manual primarily to assist qualified service technicians in the installation, maintenance and service of the icemaker. Should the reader have any questions or concerns which have not been satisfactorily addressed, please call or write to HOSHIZAKI Technical Support for assistance.

  • Page 3: Table Of Contents

    I. SPECIFICATIONS ...4 1. NAMEPLATE RATING ...4 2. DIMENSIONS/CONNECTIONS ...5 II. INSTALLATION AND OPERATING INSTRUCTIONS ...6 1. CHECKS BEFORE INSTALLATION ...6 2. HOW TO REMOVE PANELS ...6 3. LOCATION ...7 4. SET UP ...7 5. ELECTRICAL CONNECTION ...9 6. INSTALLATION OF REMOTE CONDENSER UNIT ...10 [a] CHECKS BEFORE INSTALLATION ...10 [b] LOCATION ...10 [c] SET UP ...11...

  • Page 4: Specifications

    I. SPECIFICATIONS 1. NAMEPLATE RATING MODEL NUMBER SERIAL NUMBER AC SUPPLY VOLTAGE COMPRESSOR PUMP OTHER MAXIMUM FUSE SIZE MAX. HACR BREAKER (USA ONLY) MAX. CIRC. BREAKER (CANADA ONLY) MINIMUM CIRCUIT AMPACITY DESIGN PRESSURE REFRIGERANT MOTOR-COMPRESSOR THERMALLY PROTECTED NOT INTENDED FOR OUTDOOR USE See the Nameplate for electrical and refrigeration specifications.

  • Page 5: Dimensions/Connections

    2. DIMENSIONS/CONNECTIONS Note: When used with a storage bin not recommended by Hoshizaki, the icemaker needs the space at the bottom opening as in the illustration.

  • Page 6: Installation And Operating Instructions

    Nameplate. 7) A remote condenser unit is needed with this model. The recommended remote condenser unit is HOSHIZAKI CONDENSER UNIT, Model URC-12F. 2. HOW TO REMOVE PANELS - See Fig. 1 a) Front Panel ... Remove the two screws.

  • Page 7: Location

    3. LOCATION This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within +45°F to +100°F; Normal operating water temperature should be within +45°F to +90°F. Operation of the icemaker, for extended periods, outside of these normal temperature ranges may affect production capacity.
  • Page 8 Fig. 2 Fig. 3...

  • Page 9: Electrical Connection

    5. ELECTRICAL CONNECTION 1. Electrical connection must be made in accordance with the instructions on the “WARNING” tag, provided with the pig tail leads in the Junction Box. 2. This icemaker requires a ground that meets the national and local electrical code requirements.

  • Page 10: Installation Of Remote Condenser Unit

    6. INSTALLATION OF REMOTE CONDENSER UNIT [a] CHECKS BEFORE INSTALLATION 1) Unpack and remove shipping carton, tape(s) and packing. 2) Check that the refrigerant lines do not rub or touch lines or other surfaces, and that the fan blade turns freely. [b] LOCATION The condenser unit must be positioned in a permanent site under the following guidelines.

  • Page 11: [C] Set Up

    The two copper tubings should be insulated separately. See Fig. 7. • A connector kit “OS-QUICK” is available for field-fabricated lines from HOSHIZAKI AMERICA. • R-404A precharged tubing kits, available as optional equipment also from HOSHIZAKI AMERICA, are recommended.

  • Page 12: [D] Electrical Connection

    3) Connect the Fan Motor leads in the Junction Box of the remote condenser unit to the Fan Motor leads in the Junction Box of the HOSHIZAKI remote air-cooled icemaker. 4) Install a ground wire from the icemaker to the remote condenser unit.

  • Page 13: [E] Stacking Condenser Unit

    [e] STACKING CONDENSER UNIT 1) Secure the lower condenser unit to the Legs with eight bolts (not included). 2) Attach the upper condenser unit on the top of the lower. 3) Secure the upper condenser unit with the four screws provided. 4) Install refrigerant lines, and make electrical connection for each Fan Motor as shown in Items [c] and [d].

  • Page 14: Water Supply And Drain Connections

    7. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 10 To prevent damage to the pump assembly, do not operate the icemaker when the water supply is OFF, or if the pressure is below 10 PSIG. Do not run the icemaker until the proper water pressure is reached.
  • Page 15 Fig. 10...

  • Page 16: Final Check List

    8. FINAL CHECK LIST 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within +45°F to +100°F all year around? 3) Is there at least a 6" clearance around the icemaker for maintenance or service? 4) Have all shipping tape(s), packing and cartons been removed from the icemaker? Are the cube guides in their correct position? Are the separators properly attached to their holding clips?

  • Page 17: Start Up

    9. START UP 1. All parts are factory-adjusted. Improper adjustments may result in failure. 2. If the unit is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the Compressor. 3. Do not operate the unit in the “WASH” position without water in the Water Tank.

  • Page 18: Preparing The Icemaker For Long Storage

    10 . PREPARING THE ICEMAKER FOR LONG STORAGE When shutting off the icemaker for an extended time, drain out all water from the water tank and remove the ice from the Storage Bin. The Storage Bin should be cleaned and dried. Drain the icemaker to prevent damage to the water supply line at sub-freezing temperatures, using air or carbon dioxide.

  • Page 19: Maintenance And Cleaning Instructions

    [a] CLEANING PROCEDURE 1) Dilute approximately 27 fl. oz. of recommended cleaner Hoshizaki “Scale Away” or “LIME-A-WAY” (Economics Laboratory, Inc.), with 5 gal. of water. 2) Remove all ice from the Evaporator and the Storage Bin.
  • Page 20 Note: To remove cubes on the Evaporator, turn off the power supply and turn it on after 3 minutes. The defrost cycle starts and the cubes will be removed from the Evaporator. 3) Turn off the power supply. 4) Remove the Front Panel, and then remove the Insulation Panel by first removing the Thumbscrew, lifting up the panel slightly and pulling it toward you.

  • Page 21: [B] Sanitizing Procedure

    1) Dilute IMS-II Sanitizer or a 5.25% Sodium Hypochlorite solution with water (Add 2.5 fl. oz. of sanitizer to 5 gal. of water). Note: IMS-II Sanitizer, Part #SA0004, is available through your Hoshizaki Dealer. 2) Pour the sanitizing solution into the Water Tank.

  • Page 22: Maintenance

    12) Clean the Storage Bin with water. 13) Turn on the power supply, and start the automatic icemaking process. 2. MAINTENANCE This icemaker must be maintained individually, referring to the instruction manual and labels provided with the icemaker. 1) Stainless Steel Exterior To prevent corrosion, wipe the exterior occasionally with a clean and soft cloth.
  • Page 23 HOSHIZAKI HOSHIZAKI AMERICA, INC. 618 HIGHWAY 74 SOUTH PEACHTREE CITY, GA 30269 U.S.A. PHONE: 770-487-2331 91A1DL10A...
