Etu-751C Rear Panel - ADC WorldDSL UTU-701C Quick Installation Manual

700-701-900-02, Revision 02
ETU-751C R
The components on the ETU-751C rear panel are shown and described
below.
D15F 120
G.703 connector
G.703 In Connector
Item
D15F 120Ω G.703
connector
BNC 75Ω In/Out G.703
connectors
D9F HDSL line connector
On/Off switch
Power cord receptacle
UTU-701C and ETU-751C List 1
P
EAR ANEL
Ω
D9F HDSL line
Ω
BNC 75 BNC 75
G.703 out connector

ETU-751C Rear Panel

ETU-751C Rear Panel Components
Description
Connects E1 balanced 120Ω circuits to the enclosure.
Connects E1 unbalanced 75Ω circuits to the enclosure.
Connects the HDSL pairs to the enclosure.
Rocker switch that allows you to turn the externally applied
AC power on or off.
Accepts female end of three-prong power cord supplying
100-240 Vac at 50-60 Hz.
June 5, 2002
connector
Ω
On/Off switch
Overview
Power cord
receptacle
7
