REACH-IN
TempGuard Model
RFH1-SSB-HD

PARTS LIST

ITEM #:
71228
ISSUED: October 31, 2003
REVISED:
July 28, 2005

Advertisement

Table of Contents
loading

Related Manuals for Hoshizaki Temp Guard RFH1-SSB-HD

Summary of Contents for Hoshizaki Temp Guard RFH1-SSB-HD

  • Page 1: Parts List

    Reliability is a beautiful thing REACH-IN TempGuard Model RFH1-SSB-HD PARTS LIST ITEM #: 71228 ISSUED: October 31, 2003 REVISED: July 28, 2005...

  • Page 2: Table Of Contents

    F. Body-Final ... 15 G. Panel-Front Hinged Assembly... 17 H. Evaporator Cover Assembly (Freezer) ... 18 J. Evaporator Cover Assembly (Refrigerator) ... 19 K. Capacitor Box Assembly ... 20 L. Label Location ... 21 M. Evaporator Assembly (Freezer) ... 22 N.

  • Page 3: Auxiliary Code

    Auxiliary Codes RFH1-SSB-HD Note About Ordering Parts Most assemblies cannot be ordered as complete units; parts in the assemblies generally must be ordered separately. October 2002 March 2003 December 2003 December 2004...

  • Page 4: Material Abbreviations

    Material Abbreviations ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene...

  • Page 5: Reach-In

    A. Reach-In RFH1-SSB-HD M-5, N-6, P-5, Q-5 11a 11b 12 13 J1 J2 H1 H2 Control Board Wiring Detail 4a 4b B1 B2 B3 B4 17 17a 19 20 20a 9 9a 9b 23 23a 7 7a 8 8a 24 24a Drain Hose Detail...
  • Page 6 8, SS 7L22-0800 2A1269A04 2A2318A01 4×8, SS 7P32-0408 3A1377A02 4×8, SS 7P32-0408 2A2303A01 2A2011A04 Freezer 3A2084A02 5×10, SS 7C32-0510 4A0407-01 Refrigerator 3A2084A01 5×10, SS 7C32-0510 4A0407-01 2A2330A01 4×8, SS 7P32-0408 2A1042A10 L=200 4A1801L01 412831-07 412832-07 2A2103-01 4×8, SS 7P32-0408 5×10, SS...
  • Page 7 Title: A. Reach-In Model: RFH1-SSB-HD Index Description Flat Washer Spacer – Hinge Vinyl Hose Vinyl Hose Cover – Rear T2 Screw Cover – UL Front T2 Screw Power Cordset Wire Clamp T2 Screw Pan – Heated Drain Cover – Heated Pan Cover –...

  • Page 8: Refrigeration System

    B. Refrigeration Assembly RFH1-SSB-HD M-5, N-6, P-5, Q-5 See Detail C Drawing on Next Page 6 17...
  • Page 9 B. Refrigeration Assembly (Details) RFH1-SSB-HD M-5, N-6, P-5, Q-5 Detail A Detail B Detail C...
  • Page 10 Relay – Start Capacitor – Start Valve – Expansion Clamp Base – Refrigeration Model: RFH1-SSB-HD Material or Model Number Part Number Freezer 3A2083A01 5×10, SS 7C32-0510 Refrigerator 3A2083A02 5×10, SS 7C32-0510 Freezer 3A0724A03 4×8, SS 7P32-0408 Refrigerator 3A1087A03 4×8, SS 7P32-0408...

  • Page 11: Control Panel Assembly

    C. Control Panel Assembly RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: C. Control Panel Assembly Index Description Panel – Control Board – Display Nylon Screw Palnut Label – Display Label – Display Mount – Display Board Locking Hole Plug Plug – Hole Locking Hole Plug Ribbon Cable Model: RFH1-SSB-HD...

  • Page 12: Control Box Assembly

    D. Control Box Assembly RFH1-SSB-HD M-5, N-6, P-5, Q-5 18 19 13 14 11 12...
  • Page 13 Title: D. Control Box Assembly Model: RFH1-SSB-HD Index Description Base – Control Box Cover – Control Box Board – Control Board Support Board Connector Board Connector Board Connector Board Connector Terminal Block Tapping Screw Transformer Tapping Screw Compressor – Relay Tapping Screw Bushing Switch –...

  • Page 14: Breaker Box Assembly

    E. Breaker Box Assembly RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: E. Breaker Box Assembly Index Description Box – Breaker Circuit – Breaker Bushing Model: RFH1-SSB-HD Material or Model Number Part Number 3A1375-01 4A1932-02 428394-04 Required Number...

  • Page 15: Body-Final

    F. Body-Final RFH1-SSB-HD M-5, N-6, P-5, Q-5...
  • Page 16 Title: F. Body-Final Model: RFH1-SSB-HD Index Description Body – Prefinal Door – Half (UR) Door – Half (LR) Hinge – Stop Pin Stop Pin Hinge – Tension Screw Pivot Pin Hinge – Bushing Cover Hinge – Lock Washer Hinge – Pivot Pin (Top) Bracket –...

  • Page 17: Panel-Front Hinged Assembly

    G. Panel-Front Hinged Assembly RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: G. Panel-Front Hinged Assembly Model: RFH1-SSB-HD Index Description Hinge – Front Panel (L) Hinge – Front Panel (R) Channel – Hinge Truss Head Screw Panel – Front Material or Model Number Part Number 4A2153-01 4A2154-01 4A2170-01...

  • Page 18: Evaporator Cover Assembly (Freezer)

    H. Evaporator Cover Assembly (Freezer) RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: H. Evaporator Cover Assembly (Freezer) Index Description Cover – Evaporator Grill – Fan T2 Screw Bracket – Fan Motor Insert Threaded Truss Head Screw Blade – Fan Motor Fan Evaporator Truss Head Screw Hex Nut Split Lock Washer...

  • Page 19: Evaporator Cover Assembly (Refrigerator)

    J. Evaporator Cover Assembly (Refrigerator) RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: J. Evaporator Cover Assembly (Refrigerator) Index Description Cover – Evaporator Grill – Fan T2 Screw Bracket – Fan Motor Insert Threaded Truss Head Screw Blade – Fan Motor Fan Evaporator...

  • Page 20: Capacitor Box Assembly

    K. Capacitor Box Assembly RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: K. Capacitor Box Assembly Model: RFH1-SSB-HD Index Description Base – Capacitor Box Cover – Capacitor Box Bushing Relay – Start Capacitor – Start Strap T2 Screw Material or Model Number Part Number 3A2082-01 3A2081-01 420470-03...

  • Page 21: Label Location

    Wiring Label Wiring Label Wiring Label Label – R404A Label – Penguin – HA (L) Label – On/Off Emblem – Hoshizaki Label – Display Info Label – Door Heater Switch Caution Label Cover – Nameplate Material or Model Number Part Number...

  • Page 22: Evaporator Assembly (Freezer)

    M. Evaporator Assembly (Freezer) RFH1-SSB-HD M-5, N-6, P-5, Q-5 13 13a 9 11...
  • Page 23 Title: M. Evaporator Assembly (Freezer) Index Description Evaporator Thermistor – Cabinet Heater – Defrost Mount – Evaporator Truss Head Screw Insert Threaded Drain Pan Assembly T2 Screw Thermistor Bracket (A) T2 Screw Thermistor Bracket (B) Wire Saddle Thermistor Clip Heater – Drain Thermistor –...

  • Page 24: Evaporator Assembly (Refrigerator)

    N. Evaporator Assembly (Refrigerator) RFH1-SSB-HD M-5, N-6, P-5, Q-5...
  • Page 25 Title: N. Evaporator Assembly (Refrigerator) Index Description Evaporator Mount – Evaporator Truss Head Screw Insert Threaded Drain Pan Assembly T2 Screw Thermistor Bracket (A) T2 Screw Thermistor Bracket (B) Shield – Thermistor Thermistor – Defrost Thermistor Clip Thermistor – Cabinet...

  • Page 26: Condenser Assembly (Freezer)

    RFH1-SSB-HD M-5, N-6, P-5, Q-5 4a 4b Title: P. Condenser Assembly (Freezer) Index Description Condenser T2 Screw Insert – Threaded Blade – Condenser Fan Bracket – Condenser Fan Truss Head Screw Cable Tie Retainer – Filter T2 Screw Hex Nut Fan –...

  • Page 27: Condenser Assembly (Refrigerator)

    Q. Condenser Assembly (Refrigerator) RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: Q. Condenser Assembly (Refrigerator) Index Description Condenser T2 Screw Insert – Threaded Blade – Condenser Fan Bracket – Condenser Fan Truss Head Screw Cable Tie Retainer – Filter T2 Screw Hex Nut Motor –...

  • Page 28: Body-Prefinal

    R. Body-Prefinal RFH1-SSB-HD M-5, N-6, P-5, Q-5...
  • Page 29 Title: R. Body-Prefinal Model: RFH1-SSB-HD Index Description Cabinet Prefoam Pilaster Truss Head Screw Insert – Threaded Bulb – Light Shield – Light Cheese Head Screw Switch – Door Bushing Plate – Strike (Front) Truss Head Screw Plate – Strike (Base) T2 Screw Grommets Grommets...

  • Page 30: Door-Half (Ur)

    S. Door-Half (UR) RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: S. Door-Half (UR) Model: RFH1-SSB-HD Index Description Door – Prefoam (UR) Lock – Tumbler Lock – Stop Washer Cam – Door Lock Lock – Screw Gasket – Door (Half) Handle – Door Lock Washer Lock –...

  • Page 31: Door-Half (Lr)

    T. Door-Half (LR) RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: T. Door-Half (LR) Model: RFH1-SSB-HD Index Description Door – Prefoam (LR) Lock – Tumbler Lock – Stop Washer Cam – Door Lock Lock – Screw Gasket – Door (Half) Handle – Door Lock Washer Lock –...

  • Page 32: Literature And Packaging

    U. Literature and Packaging RFH1-SSB-HD M-5, N-6, P-5, Q-5 Title: U. Literature and Packaging Index Description Instruction Manual Packaging (Available only for models currently in production) Filler – Door Pad – Corner Post – Corner Support – Corner Stop – Door Flat Washer Hex Head Bolt Pallet...
