DHR 150CB Series Instruction Manual

Navigation Lights Signalling Lights
INSTRUCTION MANUAL
DHR150/180/210/220 CB-series
Manual Controlled Searchlights
Den Haan Rotterdam
Den Haan Rotterdam

DISCLAIMER

Despite constant care and attention DHR puts in its manuals it
is still possible that information in this manual is incomplete or
incorrect.
We do not guarantee that the information in the manual is suit-
able for the purpose for which the information was consulted.
All information is offered in the state in which it actually is and
without any (implicit) guarantee or warranty regarding its va-
lidity or its suitability for a particular purpose or otherwise. All
illustrations are for illustrative purposes only. This manual is not
intended to cover every possible detail about the product.
We exclude all liability for any damages, direct or indirect, of
any nature whatsoever, arising from or in any way connected
with the use of this manual. In addition we are not liable for dam-
ages, direct or indirect, arising from the use of information ob-
tained from this manual.
A user of this manual may not publish copyright protected works
or other information from the manual or in any way reproduce
the information without our permission. This also includes the
reproduction of information or parts thereof by publication in an
electronic (computer) network.
Searchlights Whistles
ADVANCED MARITIME
SIGNALLING SOLUTIONS
Den Haan Rotterdam
Fascinatio Boulevard 1182
2909 VA Capelle a/d IJssel
The Netherlands
T +31 (0) 10 413 07 55
E sales@dhr.nl
www.dhr.nl

DIMENSIONS

Approx.± 15˚
Approx.± 15˚
Extension tube
250-330-500mm
120˚
Mounting holes
Ø 214
218
300
200
Max. 35
Max. 35
210CB 220CB
Ø 92
3 x Ø 7
Max. 35
Ø 73
150CB/180CB
Dimensions in mm.
Figure 1
312
200
Width
(See table)
Height Height
(See table) (See table)
156
