TECHNICAL DOCUMENT
DHR 230RC-series
Remote Controlled Searchlight
Den Haan Rotterdam

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 230RC Series and is the answer not in the manual?

Questions and answers

Related Manuals for DHR 230RC Series

Summary of Contents for DHR 230RC Series

  • Page 1 Navigation Lights Signalling Lights Searchlights Whistles TECHNICAL DOCUMENT DHR 230RC-series Remote Controlled Searchlight Den Haan Rotterdam...

  • Page 2: Safety Notes

    Den Haan Rotterdam SAFETY NOTES • Turn power off before inspection, installation or removal • Don’t stare directly into the LEDs, Always use eye protection when handling LEDs • This product can be damaged by electrostatic discharge, ESD. When handling take close care before opening the drum to avoid damaging the LEDs.

  • Page 3: Preface

    By introducing products with advanced LED-technology, DHR has safe- guarded a visibly safe future for marine vessels in all weather conditions.

  • Page 4: Table Of Contents

    Den Haan Rotterdam 5. TABLE OF CONTENTS Safety notes Preface Quality standards 1. Mounting instructions 2. Specifications 3. Dimensions 4. Photos 5. Electrical diagrams 6. Safety, maintenance and correct use Doc. A00DOC-ZL0005 Rev. C - May 2023...

  • Page 5: Mounting Instructions

    Den Haan Rotterdam 1. MOUNTING INSTRUCTIONS WARNING! Den Haan Rotterdam does not accept responsibility for any damage if the searchlight is installed incorrectly and/or used improperly. When in doubt consult a qualified electrical technician. MOUNTING THE PANEL Place the control panel inside the wheelhouse, where it is protected against weather influences. The panel has been designed in order to be flush-mounted in an instrument cabinet, as shown in the illustration below.
  • Page 6 Den Haan Rotterdam ELECTRICAL INSTALLATION Install the electrical wiring according to the wiring diagrams showed on pages 12 - 15. Keep the distance between the power supply and Searchlight as short as possible. Long wires will increase a voltage drop lamp, what affects the performance.

  • Page 7: Specifications

    Den Haan Rotterdam 2. SPECIFICATIONS CONTROL PANEL Model PAN2019NF Dimensions Height 105 mm [4.33 inch] Width 140 mm [4.33 inch] Weight 0,6 kg [1.32 lb] Electrical Voltage 24 VDC -20 /+30% Maximum wattage 20 W Fuse Resettable - 3A Electrical insulation class Housing Front Aluminium / Acrylic black - IP65...
  • Page 8 Den Haan Rotterdam SEARCHLIGHT Model 230RCL21 (115/230VAC) 230RCL11 (24VDC) Dimensions Height 617 mm [24.29 inch] Width 331 mm [13.03 inch] Weight 16 kg [35.27 lb] Electrical LED-driver 115/230 VAC 24VDC Motor voltage 6-13 VDC Preferred cable type H07RN-F Cable diameter Ø...

  • Page 9: Dimensions

    Den Haan Rotterdam 3. DIMENSIONS CONTROL PANEL 140 5,51 All sizes are in mm [inch] UNLESS OTHERWISE SPECIFIED: DEN HAAN ROTTERDAM BV TITLE: Searchlight panel PAN2019NF DIMENSIONS ARE IN MILLIMETERS [INCHES] Fascinatio Boulevard 1182 2909VA Capelle a/d IJssel NAME DATE DO NOT SCALE DRAWING DRAWN Johan Jurgens...
  • Page 10 Den Haan Rotterdam REVISIONS SEARCHLIGHT ZONE REV. DESCRIPTION DATE 250 9,84 162,5 6,4 10 0,39 Drill holes Fasteners • The permissible torque should be 8 Nm • Use only A4-grade stainless steel All sizes are in mm [inch] Doc. A00DOC-ZL0005 Rev.

  • Page 11: Photos

    Den Haan Rotterdam 4. PHOTOS Rev. C - May 2023 Doc. A00DOC-ZL0005...

  • Page 12: Electrical Diagrams

    Den Haan Rotterdam 5. ELECTRICAL DIAGRAMS CONTROL PANEL WITH SEARCHLIGHT 230RCL21 (115/230VAC) 115/230VAC 24VDC Max. 50 metre 3G1,5mm² 115/230VAC Fuse • T3A (230VAC) Beam A2(-) • T4A (115VAC) 24VDC(+) A1(+) RP Motors Beam Not used Not used Down Down Right Right Left Left...
  • Page 13 Den Haan Rotterdam CONTROL PANEL WITH SEARCHLIGHT 230RCL11 (24VDC) 24VDC Max. 50 metre 3G1,5mm² 24VDC Fuse T8A 8 - 24VDC(+) 7 - 24VDC(-) 1 - Beam A2(-) A1(+) 6 - RP Motors Beam 2 - Up Not used Not used 3 - Down Down 4 - Right...
  • Page 14 Den Haan Rotterdam TWO PANELS WITH SEARCHLIGHT 230RCL21 (115/230VAC) 115/230VAC 24VDC PAN2019NF Searchlight 230RCL21 PANDUALNF PAN2019NF 3G1,5mm² 115/230VAC Fuse • T3A (230VAC) • T4A (115VAC) 1 - Beam 8 x1.5mm² A2(-) 8 - 24VDC(+) Searchlight 230RCL21 (max. 25 metre) A1(+) 6 - RP Motors A7-24VDC(-) 24VDC(-)
  • Page 15 Den Haan Rotterdam TWO PANELS WITH SEARCHLIGHT 230RCL11 (24VDC) 24VDC PAN2019NF Searchlight 230RCL11 PANDUALNF PAN2019NF 3G1,5mm² 24VDC 8 - 24VDC(+) Fuse T8A 7 - 24VDC(-) 1 - Beam 8 x1.5mm² A2(-) Searchlight 230RCL (max. 25 metre) A1(+) 6 - RP Motors 24VDC(-) A7-24VDC(-) B7-24VDC(-)
  • Page 16 Den Haan Rotterdam THIRD PARTY CONTROL (115/230VAC) 3G1,5mm² 115/230VAC Fuse • T3A (230VAC) 3G1,5mm² • T4A (115VAC) 115/230VAC Beam 24VDC + Fuse A2(-) • T3A (230VAC) 24VDC(+) • T4A (115VAC) A1(+) RP Motors Beam 24VDC + A2(-) Joystick 24VDC(+) For directions Beam on/off and neutral A1(+)

  • Page 17: Safety, Maintenance And Correct Use

    Den Haan Rotterdam 6. SAFETY, MAINTENANCE AND CORRECT USE This product, like all LED searchlights, uses semi-conductors that can be damaged by elec- trostatic discharge (ESD). When handling, take close care before opening the drum to avoid damaging the LEDs. THE FOLLOWING PRECAUTIONS MUST BE TAKEN •...
  • Page 18 ADVANCED MARITIME SIGNALLING SOLUTIONS Den Haan Rotterdam Fascinatio Boulevard 1182 2909 VA Capelle a/d IJssel The Netherlands T +31 (0) 10 413 07 55 E sales@dhr.nl www.dhr.nl...
