- Page 1 Navigation Lights Signalling Lights Searchlights Whistles TECHNICAL DOCUMENT DHR 230RCB220 Remote Controlled Searchlight Den Haan Rotterdam...
- Page 2 Den Haan Rotterdam (Intentionally blank page) Version 1.1 January 2019...
- Page 3 Den Haan Rotterdam Safety notes: • Turn power off before inspection, installation or removal • Keep combustible materials away from lamp • Do not exceed 105% of rated voltage • Allow lamp/fixture to cool before handling • Do not use the searchlight if outer glass is scratched or broken Damage due to inappropriate handling is not covered by the warranty.
- Page 4 By introducing products with advanced LED-technology, DHR has safeguarded a visibly safe future for marine vessels in all weather conditions.
-
Page 5: Table Of Contents
Den Haan Rotterdam TABLE OF CONTENTS 1. Mounting instructions 2. Specifications 3. Dimensions 4. Photos 5. Wiring diagrams 6. Maintenance and correct use 7. Replacing of motor frame 8. Recommended spare parts Version 1.1 January 2019... -
Page 6: Mounting Instructions
Den Haan Rotterdam 1. MOUNTING INSTRUCTIONS Warning! Den Haan Rotterdam does not accept responsibility for any damage if the searchlight is in- stalled incorrectly and/or used improperly. When in doubt consult a qualified electrical techni- cian. Mounting the panel Place the control panel inside the wheelhouse, where it is protected against weather influences. The panel has been designed in order to be flush-mounted in an instrument cabinet, as shown in the illustration below. - Page 7 Den Haan Rotterdam Electrical installation Install the electrical wiring according to the wiring diagrams showed on pages 11 - 14. Keep the distance between the power supply and halogen lamp as short as possible. Long wires will increase a voltage drop near the halogen lamp, which affects the light output.
-
Page 8: Specifications
Den Haan Rotterdam 2. SPECIFICATIONS Control panel Model PAN2011 Dimensions Depth 110 mm Width 110 mm Weight 0,6 kg Electrical Voltage 24 VDC±20% Maximum wattage 20 W Fuse Electrical insulation class Housing Front Stainless steel 316 Back Aluminium, painted black Operating temperature 0°... - Page 9 Den Haan Rotterdam Searchlight Model 230RCN220 Dimensions Height 617 mm Width 331 mm Weight 16 kg Electrical LED-driver 230 VAC / 75W Motor voltage 6-13 VDC Preferred cable type H07RN-F Cable diameter Ø 6-12 mm Optics Mirror Parabolic mirror reflector Ø 230 mm Range 775m Adjustable Focus...
- Page 10 Den Haan Rotterdam (Intentionally blank page) Version 1.1 January 2019...
-
Page 11: Dimensions
Den Haan Rotterdam 3. DIMENSIONS Control Panel SPEED U/D SPEED L/R BEAM ON/OFF ON/OFF Joystick Ø3 All sizes are in mm. Version 1.1 January 2019... - Page 12 Den Haan Rotterdam Searchlight 162,5 4 x Ø10 162,5 Base RCN All sizes are in mm. Version 1.1 January 2019...
-
Page 13: Photos
Den Haan Rotterdam 4. PHOTOS Version 1.1 January 2019... -
Page 14: Wiring Diagrams
Den Haan Rotterdam 5. WIRING DIAGRAMS A. Internal Connections Drum Head searchlight Mounting plate motor house cable Ground* Down Motor Up / down 6 - 13VDC Motor left / right 6 - 13VDC 24VDC (for PTC) Left Terminal Pole Motor 1 Motor 2 Right J1-6... - Page 15 Den Haan Rotterdam B. External Connections Motor up / down Motor left / right 3 x 1,5 mm² Joystick (Four directions and neutral) LED On/Off 6-12VDC 24VDC 230VAC* *110VAC on request Version 1.1 January 2019...
- Page 16 Den Haan Rotterdam C. Control panel 3 x 1,5 mm² 5 x 1 mm² PE L N 230VAC 24VDC Version 1.1 January 2019...
- Page 17 Den Haan Rotterdam Dual control panel Moter house 3 x 1,5 mm ² 5 x 1 mm ² K3** 12 11 7 6 5 PE L N 230VAC 24VDC Secondary Panel Main Panel ** K3 not standaard in delivery Coil operating range 70-110% Version 1.1 January 2019...
- Page 18 Den Haan Rotterdam Joystick 10 11 16 17 3 x 1,5 mm² 5 x 1 mm² 24/12VDC JOY2011 Remarks: - To use the Joystick switch-off panel - Fuses, K1 and S1 not standaard in delivery PE L N 230VAC 24VDC Version 1.1 January 2019...
-
Page 19: Maintenance And Correct Use
Den Haan Rotterdam 6. MAINTENANCE AND CORRECT USE Safety notes • Handle with care • Turn off main power • Warning, lamp is hot • Do not touch the lamp with bare hands Tips for correct use • Do not overheat the searchlight - max. burning time 20 min. •... -
Page 20: Replacing Of Motor Frame
Den Haan Rotterdam 7. REPLACING OF MOTOR FRAME Motor frame replacement 1. Switch off the main power 2. Open the backplate of the motor housing 3. Disconnect the power cables connected to the motor frame 4. Unscrew the four (4) bolts to dismount the searchlight from the base structure 5. -
Page 21: Recommended Spare Parts
Den Haan Rotterdam 8. RECOMMENDED SPARE PARTS Spare Part Description Order code COB led 23980010 Lampholder COB led 23980020 LED-driver 230V/70W 23980030 Mirror reflector 230 23980040 Front glass 230 23980050 Motor frame 23980060 Control Panel PAN2011 Joystick JOY2011 Version 1.1 January 2019... - Page 22 Den Haan Rotterdam Version 1.1 January 2019...
- Page 23 Den Haan Rotterdam (Intentionally blank page) Version 1.1 January 2019...
- Page 24 ADVANCED MARITIME SIGNALLING SOLUTIONS Den Haan Rotterdam Fascinatio Boulevard 1182 2909 VA Capelle a/d IJssel The Netherlands T +31 (0) 10 413 07 55 E sales@dhr.nl www.dhr.nl...
