- Page 1 Navigation Lights Signalling Lights Searchlights Whistles TECHNICAL DOCUMENT DHR 230RCN 230 Remote Controlled Searchlight Den Haan Rotterdam...
- Page 2 Den Haan Rotterdam (Intentionally blank page) Version 1.0 October 2018...
- Page 3 Den Haan Rotterdam Safety notes: • Turn power off before inspection, installation or removal • Keep combustible materials away from lamp • Do not exceed 105% of rated voltage • Allow lamp/fixture to cool before handling • Do not use the searchlight if outer glass is scratched or broken Damage due to inappropriate handling is not covered by the warranty.
- Page 4 The RCN-series is the second generation of DHR remote controlled type of searchlights introduced in 2011. This product range is very popular, because of its compact size and its simplicity in installation and operation. The RCN-series includes various types of light sources, such as: halogen bulbs, sealed beams and metal halide bulbs.
-
Page 5: Table Of Contents
Den Haan Rotterdam TABLE OF CONTENTS 1. Mounting instructions 2. Specifications 3. Dimensions 4. Photos 5. Wiring diagrams 6. Maintenance and correct use 7. Replacing of motor frame 8. Recommended spare parts Version 1.0 October 2018... -
Page 6: Mounting Instructions
Den Haan Rotterdam 1. MOUNTING INSTRUCTIONS Warning! Den Haan Rotterdam does not accept responsibility for any damage if the searchlight is in- stalled incorrectly and/or used improperly. When in doubt consult a qualified electrical techni- cian. Mounting the panel Place the control panel inside the wheelhouse, where it is protected against weather influences. The housing is especially constructed to be flush mounted in an instrument cabinet according the illustration on the right. - Page 7 Den Haan Rotterdam Electrical installation Install the electrical wiring according to the wiring diagrams showed on pages 11 - 14. Keep the distance between the power supply and halogen lamp as short as possible. Long wires will increase a voltage drop near the halogen lamp, which affects the light output.
-
Page 8: Specifications
Den Haan Rotterdam 2. SPECIFICATIONS Control panel Model PAN2011 Dimensions Depth 110 mm Width 110 mm Weight 0,6 kg Electrical Voltage 24 VDC±20% Maximum wattage 20 W Fuse Electrical insulation class Housing Front Stainless steel 316 Back Aluminium, painted black Operating temperature 0°... - Page 9 Den Haan Rotterdam Searchlight Model 230RCN230 Dimensions Height 617 mm Width 331 mm Weight Electrical LED-driver 230 VAC / 75W Motor voltage 6-13 VDC Preferred cable type H07RN-F Cable diameter Ø 6-12 mm Optics Mirror Parabolic mirror reflector Ø 230 mm Range 775m Adjustable Focus...
- Page 10 Den Haan Rotterdam Version 1.0 October 2018...
-
Page 11: Dimensions
Den Haan Rotterdam 3. DIMENSIONS Control Panel SPEED U/D SPEED L/R BEAM ON/OFF ON/OFF Joystick Ø3 All sizes are in mm. Version 1.0 October 2018... - Page 12 Den Haan Rotterdam Searchlight 162,5 4 x Ø10 162,5 Base RCN All sizes are in mm. Version 1.0 October 2018...
-
Page 13: Photos
Den Haan Rotterdam 4. PHOTOS Version 1.0 October 2018... -
Page 14: Wiring Diagrams
Den Haan Rotterdam 5. WIRING DIAGRAMS A. Internal Connections Head searchlight Motor Up / down Motor left / right 6 - 13VDC 6 - 13VDC Ground CAUTION: Ground is used as return pad when on the end-position switch. Always use the ground from the control panel to avoid unwanted potential differences. - Page 15 Den Haan Rotterdam B. External Connections Motor up / down Motor left / right 230VAC Joystick (Four directions and neutral) Beam On/Off 6-13VDC 6-13VDC F0.5A Voltage 24VDC Voltage 230VAC Version 1.0 October 2018...
- Page 16 Den Haan Rotterdam C. Control panel Power for LEDdriver PTC Heater Motor left / right Motor up / down Motor housing 3 x 1,5 mm² 5 x 1 mm² 12 11 8 7 6 3 2 1 L N PE 230VAC 24VDC Version 1.0 October 2018...
- Page 17 Den Haan Rotterdam Dual control panel Power for LEDdriver PTC Heater Motor left / right Motor up / down Motor housing 5 x 1 mm² 3 x 1,5 mm² ** K3 not standard in delivery Coil operating range 70-110% K3** 3 2 1 10 9 24VDC...
- Page 18 Den Haan Rotterdam Joystick Power for LEDdriver PTC Heater Motor left / right Motor up / down Motor housing 5 x 1 mm² 3 x 1,5 mm² 12/24VDC See table 1 L N PE 230VAC 24VDC Version 1.0 October 2018...
-
Page 19: Maintenance And Correct Use
Den Haan Rotterdam 6. MAINTENANCE AND CORRECT USE Safety notes • Handle with care • Turn off main power • Warning, lamp is hot Tips for correct use • Do not overheat the searchlight - max. burning time 20 min. •... -
Page 20: Replacing Of Motor Frame
Den Haan Rotterdam 7. REPLACING OF MOTOR FRAME Motor frame replacement 1. Switch off the main power 2. Open the backplate of the motor housing 3. Disconnect the power cables connected to the motor frame 4. Unscrew the four (4) bolts to dismount the searchlight from the base structure 5. -
Page 21: Recommended Spare Parts
Den Haan Rotterdam 8. RECOMMENDED SPARE PARTS Spare Part Description Order code COB led CLU-731 Lampholder COB led LED-driver 230V/70W ELG-75-42 Mirror reflector 230 Front glass 230 Motor frame 35025 Control Panel PAN2011 Joystick JOY2011 Version 1.0 October 2018... - Page 22 Den Haan Rotterdam Version 1.0 October 2018...
- Page 23 Den Haan Rotterdam (Intentionally blank page) Version 1.0 October 2018...
- Page 24 ADVANCED MARITIME SIGNALLING SOLUTIONS Den Haan Rotterdam Fascinatio Boulevard 1182 2909 VA Capelle a/d IJssel The Netherlands T +31 (0) 10 413 07 55 E sales@dhr.nl www.dhr.nl...
