- Page 1 TECHNICAL MANUAL UC searchlights and control panel Den Haan Rotterdam Version 2.0 July 2015...
- Page 2 DISCLAIMER Despite constant care and attention DHR puts in its manuals it is still possible that information in this manual is incomplete or incorrect. We do not guarantee that the information in the manual is suitable for the purpose for which the information was consulted.
-
Page 3: Table Of Contents
Den Haan Rotterdam TABLE OF CONTENTS Mounting instructions Maintenance Specifications control panel Specifications motor housing Specifications DHR150/180 Head Specifications DHR210/220 head Dimensions searchlight Dimensions control panel Wiring diagram 12/24VDC Wiring diagram 115/230VAC Version 2.0 October 2015... -
Page 4: Mounting Instructions
Den Haan Rotterdam 1. MOUNTING INSTRUCTIONS 352 - 390 Mounting the panel 90 mm Place the control panel inside the wheelhouse, where it is protected against weather influences. The housing is especially constructed to be flush mounted in an instrument cabinet according the illustration on the right. -
Page 5: Specifications Control Panel
Den Haan Rotterdam 3. SPECIFICATIONS CONTROL PANEL • Pnom. : 15 W • Unom.input : 12 – 24 VDC • Unom.output motor (2x) : 4 – 10 VDC • U output lamp : See input • Protection class : IP 20 •... -
Page 6: Specifications Dhr150/180 Head
Den Haan Rotterdam 5. SPECIFICATIONS DHR150/180 HEAD • Housing DHR180/150: - Material : Stainless steel 316 - Finish : Brushed - Sealing : Silicone, black • Electrical insulation class : III • Optics : Sealed beam mirror reflector • Protection class : IP X6 •... -
Page 7: Dimensions Searchlight
Den Haan Rotterdam 7. DIMENSIONS SEARCHLIGHT 150 - 220 15° 30° 352 - 390 ø131 ø201 3 x M6 3 x 8,5 All sizes are in mm. Version 2.0 October 2015... -
Page 8: Dimensions Control Panel
Den Haan Rotterdam 8. DIMENSIONS CONTROL PANEL SPEED U/D SPEED L/R ON/OFF All sizes are in mm. Controls Switches 1. ON/OFF, switches the panel on or off. Potentiometers 2. UP/DOWN, speed of the movement up and down. 3. LEFT/RIGHT, speed of the movement left and right. 4. -
Page 9: Wiring Diagram 12/24Vdc
Den Haan Rotterdam 9. WIRING DIAGRAM 12/24VDC BULB Searchlight bottom view 2 x 2,5 mm 4 x 0,75 mm - 12/24 VDC Fuse F16A Control panel back view Fuse 5x20 T1A Version 2.0 October 2015... -
Page 10: Wiring Diagram 115/230Vac
Den Haan Rotterdam 10. WIRING DIAGRAM 115/230VAC BULB Searchlight bottom view 3 x 1,5 mm 4 x 0,75 mm 2 x 1,5 mm 12/24 VDC N PE Control panel back view Fuse 5x20 T1A Version 2.0 October 2015... - Page 11 Den Haan Rotterdam [This page is intentionally left blank] Version 2.0 October 2015...
- Page 12 ADVANCED MARITIME SIGNALLING SOLUTIONS Den Haan Rotterdam Fascinatio Boulevard 1182 2909 VA Capelle a/d IJssel The Netherlands T +31 (0) 10 413 07 55 E sales@dhr.nl www.dhr.nl...
