Save These Instructions. This manual will help you to obtain efficient,
dependable service from the heater, and enable you to order repair
parts correctly. Keep in a safe place for future reference.
SAFETY NOTICE: If this heater is not properly installed, a house fire
may result. For your safety, follow the installation instructions. Never
use make-shift compromises during the installation of this heater.
Contact local building or fire officials about permits, restrictions
and installation requirements in your area.
CAUTION! Please read this entire manual before you install or use
your new room heater. Failure to follow instructions may result in
property damage, bodily injury, or even death. Improper Installation
Could Void Your Warranty!
ALL PICTURES SHOWN ARE FOR ILLUSTRATIVE PURPOSES ONLY.
ACTUAL PRODUCT MAY VARY DUE TO PRODUCT ENHANCEMENT.
This manual is subject to change without notice.
MODEL: VG3200
United States Stove Company
227 Industrial Park Rd.,
South Pittsburg, TN 37380
PH: (800) 750-2723
www.usstove.com
Report Number: F20-586
Tested Per EPA Methods ALT-125, ASTM
E2515, ASTM E3053 and CSA B415
Certified to UL 1482-2011 (R2015) and
ULC-S627-00 (R2016)
Approved for mobile home installation
in (USA ONLY)
U.S. Environmental Protection Agency
Certified to comply with 2020
Ce produit peut vous exposer à des agents chimiques, y compris au monoxyde de
particulate emissions standards.
carbone, lesquels sont reconnus dans l'État de la Californie comme causant le cancer et
des malformations congénitales ou autres dommages au fœtus. Pour obtenir plus de
renseignements, veuillez consulter le site www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is known to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
R
853745-0705J
Advertisement
Table of Contents
Related Manuals for United States Stove VOGELZANG VG3200
Summary of Contents for United States Stove VOGELZANG VG3200
- Page 1 State of California to cause cancer, birth defects and/or other This manual is subject to change without notice. reproductive harm. For more information, go to www.P65warnings.ca.gov United States Stove Company 227 Industrial Park Rd., South Pittsburg, TN 37380 PH: (800) 750-2723 www.usstove.com...
- Page 2 The instructions pertaining to the installation of your wood stove comply with UL-1482 (R2015) and ULC-S627 standards. This manual describes the installation and operation of the Vogelzang, VG3200 wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s cordwood emission limits for wood heaters sold after May 15, 2020.
-
Page 3: Unpack And Inspect
Assembly UNPACK AND INSPECT Remove the packing from the appliance and inspect for any damage. Your appliance is packed with the door handle spring not installed. Ensure that the bricks are positioned correctly and not broken (see illustration for proper brick arrangement). Make sure that the baffle board, above the air tubes, is in place and undamaged. (DO NOT REMOVE). -
Page 4: Installation
Installation SAFETY NOTICE • IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. • CONSULT YOUR MUNICIPAL BUILDING DEPARTMENT OR FIRE OFFICIALS ABOUT PERMITS, RESTRICTIONS AND INSTALLATIONS REQUIREMENTS IN YOUR AREA. •... - Page 5 CLEARANCES TO COMBUSTIBLES It is of utmost importance that the clearances to combustible materials be strictly adhered to during installation of the stove. Refer to the provided tables: Backwall Backwall Ceiling CORNER INSTALLATION CLEARANCE TO CORNER INSTALLATION WALLS & CELING CLEARANCE TO WALLS CLEARANCE TO WALLS •...
- Page 6 • Your stove does not draw steadily, smoke rollout occurs, wood burns poorly, or back-drafts occur whether or not there is combustion present. • Existing fuel-fired equipment in the house, such as fireplaces or other heating appliances, smell, do not operate properly, suffer smoke roll-out when opened, or back-drafts occur whether or not there is combustion present.
-
Page 7: Chimney Connector (Stove Pipe)
CHIMNEY CONNECTOR (STOVE PIPE) The chimney connector and chimney must have the same diameter as the stove outlet (6”). If this is not the case, we recommend you contact your dealer to ensure there will be no problem with the draft. -
Page 8: Factory Built Chimney
FACTORY BUILT CHIMNEY When metal prefabricated chimney used, manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc. -
Page 9: Combustible Wall Chimney Connector Pass-Throughs
COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS METHOD A - 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent. -
Page 10: Fuel Recommendations
Fuel Recommendations WOODSTOVE UTILIZATION Your heating appliance was designed to burn wood only; no other materials should be burned. Waste and other flammable materials should not be burned in your stove. Any type of wood may be used in your stove, but specific varieties have better energy yields than others. -
Page 11: Do Not Burn
Operating Instructions CAUTIONS: HOUSE FIRE HAZARDS • Do not store wood on floor protector, underneath stovepipe(s) if applicable, or anywhere within clearances to combustible surfaces specified for this appliance. • Never operate with secondary tubes, fiber board, or insulation removed. OPERATING SAFETY PRECAUTIONS •... -
Page 12: Fueling Instructions
Do not burn manufactured logs made of wax impregnated sawdust or logs with any chemical additives. Manufactured logs made of 100% compressed sawdust can be burned, but be careful burning too much of these logs at the same time. Start with one manufactured log and see how the stove reacts. -
Page 13: Adding Fuel
Push both air control slides to the fully open position. Light the newspaper and close the door. Once the kindling has burned down to a starter coal bed, load the unit with approximately 26 to 27 lbs of fuel for the first high burn load. -
Page 14: Blower Operation
4. Close the feed door and secure tightly. 5. Adjust the air inlet control as described in the “Fueling Instruction” section of this manual. 6. Empty ashes regularly. Do not allow ashes to pile up. Properly dispose of hot ashes (see the “Ash Removal And Disposal”... -
Page 15: Glass Care
• If a chimney or creosote fire occurs, close all dampers immediately. Wait for the fire to go out and the heater to cool, then inspect the chimney for damage. If no damage results, perform a chimney cleaning to ensure no more creosote deposits is remaining in the chimney. - Page 16 WIRING DIAGRAM - MODEL F-6 BLOWER OPTION Wiring Diagram CAUTION: MOVING PARTS CAN CAUSE DANGER: SHOCK HAZARD. DISCONNECT INJURY. DO NOT OPERATE WITH COVER POWER SOURCE BEFORE INSTALLATION REMOVED. AND WHENEVER SERVICING BLOWER ASSEMBLY. NOTICE: ANY REPLACE- MENT WIRING MUST HAVE E Q U I VA L E N T I N S U L A - TION AND TEMPERATURE RATING (105°C).
-
Page 17: Ordering Parts
Ordering Parts Part # Description 69912 Ash Drawer 892268 Heat Shield (Left) 26548 Ash Drawer Support 892269 Heat Shield (Rear) 26541 Left Side Skirt F6 Blower Assembly 40597 Skirt Corner 892267 Heat Shield (Right) 26546 Front Skirt 892278 Top Trim 26553 Right Side Skirt 892279... -
Page 18: Parts List
Parts List Part # Description 88194 C-Cast Bottom 892280 Notched Firebrick 891414 Half Firebrick 89066 Firebrick (4-1/2 X 9) 892281 1.5” Firebrick 40595 Half Brick Ash Plug 86698 Tube(1), Secondary Air Tube (4mm) 86699 Tube(2,3), Secondary Air Tube (3mm) 86700 Tube(4), Secondary Air Tube (2.5mm) 86701 Tube(5), Secondary Air Tube (2.0mm) - Page 19 Notes -19-...
-
Page 20: Service Provider
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary. - Page 21 2. The Part Description / La Description De La Pièce _______________________________________ 3. The Model Number / Le Numéro De Modèle ___________________________________________ 4. The Serial Number / Le Numéro De Série _______________________________________________ United States Stove Company 227 Industrial Park Road South Pittsburg, TN 37380 800-750-2723 www.usstove.com...
