Save These Instructions. This manual will help you to obtain efficient,
dependable service from the heater, and enable you to order
repair parts correctly. Keep in a safe place for future reference.
SAFETY NOTICE: If this heater is not properly installed, a house
fire may result. For your safety, follow the installation instructions.
Never use make-shift compromises during the installation of this
heater. Contact local building or fire officials about permits,
restrictions and installation requirements in your area.
CAUTION! Please read this entire manual before you install or use
your new room heater. Failure to follow instructions may result
in property damage, bodily injury, or even death. Improper
Ce produit peut vous exposer à des agents chimiques, y compris au monoxyde de
carbone, lesquels sont reconnus dans l'État de la Californie comme causant le cancer et
Installation Could Void Your Warranty!
des malformations congénitales ou autres dommages au fœtus. Pour obtenir plus de
renseignements, veuillez consulter le site www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is known to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
MODEL: US2500E
United States Stove Company
PO Box 151, 227 Industrial Park Rd.,
South Pittsburg, TN 37380
PH: (800) 750-2723
www.usstove.com
Report Number: F19-487
Tested Per EPA Methods ALT-125, ASTM
E2515, ASTM E3053 and CSA B415
Certified to UL 1482-2011 (R2015) and
ULC-S627-00 (R2016)
Mobile home approved (U.S. ONLY)
U.S. Environmental Protection Agency
Certified to comply with 2020 particulate
emissions standards.
ALL PICTURES SHOWN ARE FOR ILLUSTRATIVE
PURPOSES ONLY. ACTUAL PRODUCT MAY
VARY DUE TO PRODUCT ENHANCEMENT.
This manual is subject to change without
notice.
II
R
853578D-1004J
Advertisement
Table of Contents
Related Manuals for United States Stove Magnolia II
Summary of Contents for United States Stove Magnolia II
- Page 1 State of California to cause cancer, birth defects and/or other VARY DUE TO PRODUCT ENHANCEMENT. reproductive harm. For more information, go to www.P65warnings.ca.gov This manual is subject to change without United States Stove Company notice. PO Box 151, 227 Industrial Park Rd., South Pittsburg, TN 37380 PH: (800) 750-2723 www.usstove.com...
- Page 2 The instructions pertaining to the installation of your wood stove comply with UL-1482 (R2015) and ULC-S627-00 (R2016) standards. This manual describes the installation and operation of the Magnolia II, US2500E wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s cordwood emission limits for wood heaters sold after May 15, 2020.
- Page 3 Assembly Instructions TOOLS AND MATERIALS NEEDED FOR INSTALLATION You will need a drill with a 1/8” bit to install sheet metal screws into connector pipe. A 5/16” socket/wrench or screw driver to install the room air deflector, and blower assembly described. A 1/2” socket/wrench to install flue collar.
-
Page 4: Installation
Installation SAFETY NOTICE • IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. • CONSULT YOUR MUNICIPAL BUILDING DEPARTMENT OR FIRE OFFICIALS ABOUT PERMITS, RESTRICTIONS AND INSTALLATIONS REQUIREMENTS IN YOUR AREA. •... -
Page 5: Clearances To Combustibles
CLEARANCES TO COMBUSTIBLES It is of utmost importance that the clearances to combustible materials be strictly adhered to during installation of the stove. Single Wall Pipe (Double Wall Pipe) 10 (10) 254 (254) 19 (19) 483 (483) 13 (13) 331 (331) 30 (29) 762 (737) 10 (10) - Page 6 For use in MOBILE HOMES (U.S. installations ONLY): • WARNING! DO NOT INSTALL IN SLEEPING ROOM. • CAUTION! THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED. • INSTALL IN ACCORDANCE WITH 24 CFR, PART 3280 (HUD). •...
-
Page 7: Chimney Connector (Stove Pipe)
CHIMNEY CONNECTOR (STOVE PIPE) The chimney connector and chimney must have the same diameter as the stove outlet (6”). If this is not the case, we recommend you contact your dealer to ensure there will be no problem with the draft. -
Page 8: Factory Built Chimney
FACTORY BUILT CHIMNEY When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc. Maintain proper clearance to the structure as recommended by the manufacturer. -
Page 9: Combustible Wall Chimney Connector Pass-Throughs
COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS METHOD A - 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent. -
Page 10: Fuel Recommendations
Fuel Recommendations WOODSTOVE UTILIZATION Your heating appliance was designed to burn wood only; no other materials should be burned. Waste and other flammable materials should not be burned in your stove. Any type of wood may be used in your stove, but specific varieties have better energy yields than others. -
Page 11: Do Not Burn
Operating Instructions CAUTIONS: HOUSE FIRE HAZARDS • Do not store wood on floor protector, underneath stovepipe(s) if applicable, or anywhere within clearances to combustible surfaces specified for this appliance. • Never operate with secondary tubes, fiber board, or insulation removed. OPERATING SAFETY PRECAUTIONS •... -
Page 12: Fueling Instructions
TAMPER WARNING This wood heater has a manufacturer-set minimum low burn rate that must not be altered. It is against federal regulations to alter this setting or otherwise operate this wood heater in a manner inconsistent with operating instructions in this manual. EFFICIENCIES Efficiencies can be based on either the lower heating value (LHV) or the higher heating value (HHV) of the fuel. -
Page 13: Adding Fuel
Pull the air control out fully. Light the newspaper and leave the door slightly open for about a minute. NOTE: You may have to leave it open a bit longer, depending on your chimney height and outdoor conditions. After about a minute (or once your fire HIGH is well started) close the door and allow the kindling to ignite. -
Page 14: Blower Operation
1. Adjust the air inlet control as described in the “Fueling Instruction” section of this manual. 2. Empty ashes regularly. Do not allow ashes to pile up. Properly dispose of hot ashes (see the “Ash Removal And Disposal” section of this manual). 3. -
Page 15: Glass Care
• If a chimney or creosote fire occurs, close all dampers immediately. Wait for the fire to go out and the heater to cool, then inspect the chimney for damage. If no damage results, perform a chimney cleaning to ensure no more creosote deposits is remaining in the chimney. -
Page 16: Repair Parts
Repair Parts Part # Description 40292A 6” Flue Collar 88042 1/4” Rope Gasket 25845 Air Deflector 891492 Blower Assembly (B36) 26060 Rear Shield 610926 Rear Ashpan (US2500E-BP) 29243 Pedestal (US2500E-BP) 29065 Pedestal Front (US2500E-BP) Pedestal Base Weldment 610969 (US2500E-BP) 610968 Ashpan Housing (US2500E-BL) 40566... - Page 17 Repair Parts Part # Description 88325 Kao Wool Blanket 88138 Ceramic Fiber Board 86643 Secondary Air Tube (Ø5/32) 29247 Right Brick Panel 86645 Secondary Air Tube (Ø7/32) 29248 Left Brick Panel 24103A Half Firebrick Pumice (4-1/2 X 4-1/2) 40561 Ash Plug 891530A Firebrick (4.5 X 7.5 X 1.25) 89066A...
-
Page 18: Service Record
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary. - Page 19 2. The PART DESCRIPTION / UNE DESCRIPTION DE LA PIÈCE ________________________ 3. The MODEL NUMBER / LE NUMÉRO DE MODÈLE ________________________________ 4. The SERIAL NUMBER / LE NUMÉRO DE SÉRIE ____________________________________ United States Stove Company PO Box 151, 227 Industrial Park Rd., South Pittsburg, TN 37380 PH: (800) 750-2723 www.usstove.com...
