Save these instructions. This manual will help you to obtain
efficient, dependable service from the heater, and enable
you to order repair parts correctly. Keep in a safe place for
If this heater is not properly installed, a house fire may result.
For your safety, follow the installation instructions. Never
use make-shift compromises during the installation of this
heater. Contact local building or fire officials about permits,
restrictions and installation requirements in your area.
Please read this entire manual before you install or use your
new room heater. Failure to follow instructions may result in
property damage, bodily injury, or even death. Improper
Installation Could Void Your Warranty!
MODEL: US2000E
future reference.
SAFETY NOTICE:
CAUTION!
United States Stove Company
PO Box 151, 227 Industrial Park Rd.,
South Pittsburg, TN 37380
PH: (800) 750-2723
www.usstove.com
Report Number: F19-476
Certified to: UL 1482-2011 (R2015) and
ULC-S627-00 (R2016)
Mobile home approved (U.S. ONLY)
U.S. Environmental Protection Agency
Certified to comply with 2020
Ce produit peut vous exposer à des agents chimiques, y compris au monoxyde de
particulate emissions standards.
carbone, lesquels sont reconnus dans l'État de la Californie comme causant le cancer et
des malformations congénitales ou autres dommages au fœtus. Pour obtenir plus de
renseignements, veuillez consulter le site www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is known to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
R
853377-1204i
Advertisement
Table of Contents
Related Manuals for United States Stove Forester US2000E
Summary of Contents for United States Stove Forester US2000E
- Page 1 State of California to cause cancer, birth defects and/or other Installation Could Void Your Warranty! reproductive harm. For more information, go to www.P65warnings.ca.gov United States Stove Company PO Box 151, 227 Industrial Park Rd., South Pittsburg, TN 37380 PH: (800) 750-2723 www.usstove.com...
-
Page 2: Optional Accessories
Wood is our only renewable energy resource. Please do your part to preserve our wood supply. Plant at least one tree each year. Future generations will thank you. The instructions pertaining to the installation of your wood stove comply with UL-1482 (R2015) and ULC-S627 standards. This manual describes the installation and operation of the Forester, US2000E wood heater. -
Page 3: Blower Assembly
Assembly Instructions BLOWER ASSEMBLY FLUE COLLAR ASSEMBLY The blower assembly must be disconnected from the Mount the flue collar to the top of the unit as shown source of electrical supply before attempting the using the (3) 5/16-18 x 1-1/2 bolts, (3) washers, and (3) installation. -
Page 4: Installation
Installation SAFETY NOTICE • IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. • CONSULT YOUR MUNICIPAL BUILDING DEPARTMENT OR FIRE OFFICIALS ABOUT PERMITS, RESTRICTIONS AND INSTALLATIONS REQUIREMENTS IN YOUR AREA. •... -
Page 5: Clearances To Combustibles
CLEARANCES TO COMBUSTIBLES It is of utmost importance that the clearances to combustible materials be strictly adhered to during installation of the stove. Refer to the tables below. Single Wall Pipe (Double Wall Pipe) 15 (12) 381 (305) 18 (18) 458 (458) 19 (16) 483 (407) -
Page 6: Outside Combustion Air
OUTSIDE COMBUSTION AIR Your wood stove is approved to be installed with an outside air intake (4FAK) which is necessary for a mobile home. This type of installation is also required in air tight houses and houses with negative pressure problems. You can purchase this option through your heater dealer. - Page 7 For use in MOBILE HOMES (U.S. installations ONLY): • WARNING! DO NOT INSTALL IN SLEEPING ROOM. • CAUTION! THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED. • INSTALL IN ACCORDANCE WITH 24 CFR, PART 3280 (HUD). •...
-
Page 8: Chimney Connector (Stove Pipe)
CHIMNEY CONNECTOR (STOVE PIPE) The chimney connector and chimney must have the same diameter as the stove outlet (6”). If this is not the case, we recommend you contact your dealer to ensure there will be no problem with the draft. -
Page 9: Factory Built Chimney
FACTORY BUILT CHIMNEY When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass-through and “T” section package, firestops (where needed), insulation shield, roof flashing, chimney cap, etc. Maintain proper clearance to the structure as recommended by the manufacturer. -
Page 10: Combustible Wall Chimney Connector Pass-Throughs
COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS METHOD A - 12” (304.8 mm) Clearance to Combustible Wall Le dégagement minimum de la cheminée à la brique et les Member: Using a minimum thickness 3.5” (89 mm) brick matériaux combustibles est de 5 cm (2 po) (50,8 mm) and a 5/8”... -
Page 11: Operation
Operation WOOD STOVE UTILIZATION The operation of this wood heater in a manner inconsistent with the owner’s manual will void your warranty and is also against federal regulations. This heater is designed to burn natural wood only. Higher efficiencies and lower emissions generally result when burning air dried seasoned hardwoods, as compared to softwoods or too green or freshly cut hardwoods. -
Page 12: Operational Tips
It is EXTREMELY IMPORTANT to use DRY WOOD only in your wood stove. The wood should have dried for 9 to 15 months, such that the humidity content (in weight) is reduced below 20% of the weight of the log. It is very important to keep in mind that even if the wood has been cut for one, two or even more years, it is not necessarily dry, if it has been stored in poor conditions. - Page 13 IGNITION After making sure that the stove air intake controls are fully open (completely pull-out towards you), The top- down method of fire building is recommended for this appliance. After making sure that the stove air intake controls are fully open (completely pull-out towards you), Place the largest pieces of wood on the bottom, laid in parallel and close together.
-
Page 14: Creosote Formation And Need For Removal
WARNINGS: • NEVER OVERFIRE YOUR STOVE. IF ANY PART OF THE STOVE STARTS TO GLOW RED, OVER FIRING IS HAPPENING. READJUST THE AIR INTAKE CONTROL AT A LOWER SETTING. • THE INSTALLATION OF A LOG CRADLE OR GRATES IS NOT RECOMMENDED IN YOUR WOOD STOVE. BUILD FIRE DIRECTLY ON FIREBRICK. -
Page 15: Maintenance
Maintenance Your wood stove is a high-efficiency stove and therefore requires little maintenance. It is important to perform a visual inspection of the stove every time it is emptied, to ensure that no parts have been damaged, in which case repairs must be performed immediately. Inspect and clean the chimney and connector pipe periodically for creosote build-up or obstructions. -
Page 16: Repair Parts
Repair Parts Part No. Description Qty. 40292A 6” Flue Collar 88042 Rope Gasket 1/4” 25845 Air Deflector 891492 Blower Assembly (B36) 26060 Rear Shield 610926 Rear Ashpan (US2000E-BP) 29068 Pedestal (US2000E-BP) 29065 Pedestal Front (US2000E-BP) 610922 Pedestal Weldment (US2000E-BP) 610925 Ashpan Housing (US2000E-BL) 40566... - Page 17 Repair Parts Part No. Description Qty. 88316 Kao Wool Blanket 88146 Ceramic Fiber Board 86953 Secondary Air Tube (Ø1/8) 86952 Secondary Air Tube (Ø11/64) 29039 Brick Retainer (left) 29040 Brick Retainer (right) 40561 Ash Plug 24103A Half Pumice Firebrick (4-1/2 X 4-1/2) 891414A Half Firebrick 89066A...
-
Page 18: Service Record
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary. - Page 19 2. The PART DESCRIPTION / UNE DESCRIPTION DE LA PIÈCE ________________________ 3. The MODEL NUMBER / LE NUMÉRO DE MODÈLE ________________________________ 4. The SERIAL NUMBER / LE NUMÉRO DE SÉRIE ____________________________________ United States Stove Company PO Box 151, 227 Industrial Park Rd., South Pittsburg, TN 37380 PH: (800) 750-2723 www.usstove.com...
