SAVE THESE INSTRUCTIONS THIS MANUAL WILL HELP YOU TO
OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER,
AND ENABLE YOU TO ORDER REPAIR PARTS CORRECTLY.
KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
SAFETY NOTICE: If this heater is not properly installed, a
house fire may result. For your safety, follow the installation
instructions. Never use make shift compromises during
the installation of this heater. Contact local building or
fire officials about permits, restrictions and installation
requirements in your area.
CAUTION! Please read this entire manual before you install
or use your new room heater. Failure to follow instructions
may result in property damage, bodily injury, or even
death. Improper Installation Could Void Your Warranty!
ALL PICTURES SHOWN ARE FOR ILLUSTRATIVE PURPOSES
ONLY. ACTUAL PRODUCT MAY VARY DUE TO PRODUCT
ENHANCEMENT.
This manual is subject to change without notice.
U.S. Environmental Protection Agency
Certified
to
comply
Ce produit peut vous exposer à des agents chimiques, y compris au monoxyde de
particulate emissions standards.
carbone, lesquels sont reconnus dans l'État de la Californie comme causant le cancer et
des malformations congénitales ou autres dommages au fœtus. Pour obtenir plus de
renseignements, veuillez consulter le site www.P65warnings.ca.gov
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon monoxide, which
is known to the State of California to cause cancer, birth defects and/or other
reproductive harm. For more information, go to www.P65warnings.ca.gov
MODEL: VG4020
with
2020
United States Stove Company
227 Industrial Park Rd.,
South Pittsburg, TN 37380
PH: (800) 750-2723
www.usstove.com
Report #: F20-596
Tested to ALT-125, ASTM E2515,
ASTM E3053 and CSA B415.1-10
Certified to: UL 1482-11 (R2015) and
Certified to: ULC-S627-00-REV1
Room Heater, Solid Fuel Type, Also
For Use In Mobile Homes (USA Only)
853773B-1002K
R
Advertisement
Table of Contents
Related Manuals for United States Stove VOGELZANG VG4020
Summary of Contents for United States Stove VOGELZANG VG4020
- Page 1 Certified to: ULC-S627-00-REV1 reproductive harm. For more information, go to www.P65warnings.ca.gov Room Heater, Solid Fuel Type, Also For Use In Mobile Homes (USA Only) United States Stove Company 227 Industrial Park Rd., South Pittsburg, TN 37380 PH: (800) 750-2723 www.usstove.com...
- Page 2 The instructions pertaining to the installation of your wood stove comply with UL-1482 (R2015) and ULC-S627-00 (R2016) standards. This manual describes the installation and operation of the Vogelzang, VG4020 wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s cordwood emission limits for wood heaters sold after May 15, 2020.
- Page 3 Assembly Instructions UNPACK AND INSPECT 2. Place the knob on the outside of the cabinet door, re-install the machine screw and tighten. Be Remove the packing from the appliance and inspect careful not to strip out the threads in the handle. for any damage.
-
Page 4: Installation
SMOKE CURTAIN INSTALLATION 3. Slide the smoke curtain through the fire door and hook into place. Note: the smoke curtain has a 1. Open the cabinet door and the fire door. bend at the bottom. When placing the smoke Cabinet Door curtain into place ensure the bend it facing toward the fire door as shown. -
Page 5: Floor Protector
FLOOR PROTECTOR This heater must have a non-combustible floor protector with a minimum type 1 ember protection extending beneath the heater if the floor is constructed of combustible material. If a floor pad is used, it should be UL listed or equal. The floor protector should be large enough to extend under the stove and beyond each side as indicated. - Page 6 SPECIAL MOBILE HOME REQUIREMENTS (APPROVED FOR USE IN MOBILE HOMES (USA ONLY) WARNING - DO NOT INSTALL IN A SLEEPING ROOM. CAUTION - THE STRUCTURAL INTEGRITY OF THE MOBILE HOME FLOOR, WALL, AND CEILING/ROOF MUST BE MAINTAINED. In addition to the previously detailed installation requirements, mobile home installations must meet the following requirements: •...
-
Page 7: Chimney Connector (Stove Pipe)
CHIMNEY CONNECTOR (STOVE PIPE) Install Your chimney connector and chimney must have the same crimped diameter as the stove outlet (6”). If this is not the case, we 1/4” slope per foot towards recommend you contact your dealer in order to ensure there stove. -
Page 8: Factory Built Chimney
Listed Attic Chimney Insulation Sheild Combustible Specified Ceiling Joists Clearance Ceiling Chimney Support Connector FACTORY BUILT CHIMNEY To Stove When a metal prefabricated chimney is used, the manufacturer’s installation instructions must be followed. Listed Cap You must also purchase (from the same manufacturer) and install the ceiling support package or wall pass- Maintain 2”... -
Page 9: Combustible Wall Chimney Connector Pass-Throughs
COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS Method A. 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent. -
Page 10: Fuel Recommendations
Fuel Recommendations WOODSTOVE UTILIZATION Your heating appliance was designed to burn wood only; no other materials should be burned. Waste and other flammable materials should not be burned in your stove. Any type of wood may be used in your stove, but specific varieties have better energy yields than others. -
Page 11: Operating Safety Precautions
Operating Instructions CAUTIONS: HOUSE FIRE HAZARDS • Do not store wood on floor protector, underneath stovepipe(s) if applicable, or anywhere within clearances to combustible surfaces specified for this appliance. • Never operate with secondary tubes, fiber board, or insulation removed. OPERATING SAFETY PRECAUTIONS •... -
Page 12: Fueling Instructions
TAMPER WARNING This wood heater has a manufacturer-set minimum low burn rate that must not be altered. It is against federal regulations to alter this setting or otherwise operate this wood heater in a manner inconsistent with operating instructions in this manual. EFFICIENCIES Efficiencies can be based on either the lower heating value (LHV) or the higher heating value (HHV) of the fuel. -
Page 13: Air Tubes
For a low burn setting once the high burn (or medium) fuel load is burned down to an established coal bed, load the unit with 27-28 lbs of cordwood and keep the door slightly open for 5 minutes. Leave the air control fully open (in the “HI”... -
Page 14: Chimney Maintenance
Chimney Maintenance CAUTION: Do not overfire appliance. You are overfiring if any part of the appliance glows red. Close the door and shut the damper immediately to reduce the air supply and slow down the fire. CAUTION: Slow burning fires for extended use or burning green wood may cause excessive creosote build-up. Ignition of creosote or overfiring could cause a chimney fire. -
Page 15: Blower Wiring Diagram
CAUTIONS: • ASHES COULD CONTAIN HOT EMBERS EVEN AFTER TWO DAYS WITHOUT OPERATING THE STOVE. • THE ASH PAN CAN BECOME VERY HOT. WEAR GLOVES TO PREVENT INJURY. • NEVER BURN THE STOVE WITH THE ASH TRAP OPEN. THIS WOULD RESULT IN OVER FIRING THE STOVE. DAMAGE TO THE STOVE AND EVEN HOUSE FIRE MAY RESULT. -
Page 16: Repair Parts
Repair Parts Part # Description 25550 H. Pin Draft Damper 67966 Cabinet Top Assy 27469 Damper Arm 22761 Flue Collar Ring 610987 Air Distribution Box Assembly 610143 Casing Back 89687 Black Thermostat Knob 40246 6” C.I. Flue Collar 610985 Cabinet Front Weldment/Assy. 88032 Flue Collar Gasket 611015... - Page 17 Repair Parts Part # Description 88336 Insulation Blanket 88335 Baffle Board 29437 Tube Retainer 29438 Baffle Side 27291 Front Liner Top 29408 Right Retainer 893285 Firebrick 27484 Top Brick Rack 89066A Pumice Firebrick (4-1/2 X 9) 610223 Cleanout Cover Weldment 610227 Primary Air Outlet (Welded) 610221...
-
Page 18: Service Record
Service Record It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. -
Page 19: How To Order Repair Parts
1. Le numéro de pièce __________________________________________________________________________ 2. La description de la pièce _____________________________________________________________________ 3. Le numéro de modèle ________________________________________________________________________ 4. Le numéro de série ___________________________________________________________________________ United States Stove Company 227 Industrial Park Rd., South Pittsburg, TN 37380 PH: (800) 750-2723...
