Summary of Contents for HOTO QWLSD010
- Page 1 User Manual for HOTO Electric Precision Screwdriver Set ·15 Original instructions...
- Page 2 Scan to follow us on WeChat Get 1Y+ warranty and new follower benefits...
-
Page 3: Product Overview
01 Product Overview Thank you for purchasing the HOTO Electric Precision Screwdriver Set. Please read this manual carefully before use, and retain it for future reference. Storage box cover Magnetizing area Electric Precision screwdriver Storage box base Type-C charging port... -
Page 4: How To Use
02 How to Use How to Use the Screwdriver Bits are stored in the base magnetically. The screwdriver bit is removed from a storage box, and the bit is inserted into the bit holder. After the bit is inserted into the bit holder, it is magnetized in the middle magnetizing area. -
Page 5: Opening/Closing The Cover
This screwdriver is equipped with a Type-C charging port, and a USB charging cable is included. Illustrations of the product, accessories, and user interface in the user manual are for reference purposes only. Due to product updates and upgrades, the actual product may be slightly di erent from the schematic. - Page 6 Precautions A part of the nger may be clipped if the storage box cover is being turned upward too fast. Don’ t insert your nger into the position indicated in the gure during opening and closing. Please make sure the power of the live equipment has been cut o before using this product.
-
Page 7: General Power Tool Safety Warnings
04 General Power Tool Safety Warnings WARNING! Read all safety warnings, instructions, illustrations and speci cations provided with this power tool. Failure to follow all instructions listed below may result in electric shock, re and/or serious injury. Save all warnings and instructions for future reference. The term “power tool”... - Page 8 When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply.
- Page 9 Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
- Page 10 Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may a ect the power tool's operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
- Page 11 Do not use a battery pack or tool that is damaged or modi ed. Damaged or modi ed batteries may exhibit unpredictable behavior resulting in re, explosion or risk of injury. Do not expose a battery pack or tool to re or excessive temperature. Exposure to re or temperature above 130°C may cause explosion.
-
Page 12: Additional Safety Information
Safety instructions when using long drill bits Never operate at higher speed than the maximum speed rating of the drill bit. At higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the workpiece, resulting in personal injury. Always start drilling at low speed and with the bit tip in contact with the workpiece. - Page 13 Hold the power tool securely. When tightening and loosening screws be prepared for temporarily high torque reactions. In case of damage and improper use of the battery, vapours may be emitted. The battery can set alight or explode. Ensure the area is well ventilated and seek medical attention should you experience any adverse e ects.
- Page 14 We Shanghai HOTO Technology Co., Ltd., hereby, declares that this equipment is in compliance with the applicable Directives and European Norms, and amendments. Federal Communications Commission Supplier’s Declaration of Conformity This supplier’s declaration of conformity is hereby for Product: HOTO Electric Screwdriver Set...
- Page 15 Consult the dealer or an experienced radio/TV technician for help. Representative of Responsible Party for SDoC Company: Shanghai HOTO Technology Co., Ltd. Address: Building 45, No.50 Moganshan Road, Putuo District, Shanghai, China Country: China Telephone No.: 400-021-8696...
-
Page 16: Troubleshooting
Troubleshooting Solution Fault Cause Screwdriver Please charge the Low battery power Not work equipment in time. Bit cannot be Use an bit in C4 Bit size doesn't match the installed speci cations size of the bit holder Storage it in dry Rust on the surface High moisture in environment, and apply... -
Page 17: Speci Cations
05 Speci cations Screwdriver Model: QWLSD010 Maximum electric torque: 0.2 N.m Color: Dark Gray Maximum manual torque: 3 N.m Item Dimensions: Approx. 182×71.3×26.1 mm Input: 5 V 0.14 A Net Weight: Approx. 314 g Rated Voltage: 3.7 V Screwdriver Dimensions: Approx. 159×Φ17 mm Battery Type: Lithium-ion battery Screwdriver Net Weight: Approx. - Page 18 The battery is not replaceable. Manufacturer: Shanghai HOTO Technology Co., Ltd. Address: Building 45, No. 50, Moganshan Road, Shanghai,China...
- Page 19 EU Declaration of Conformity Shanghai HOTO Technology Co., Ltd. Declare that the product: HOTO Electric Precision Screwdriver Set / QWLSD010 Complies with the essential health and safety requirements of the following directives: 2014/30/EU Electromagnetic Compatibility directive References to the following harmonized...
