Rx-R RXS270
Flight Controller
RX Cable
Propellers
Prop adapters with screws
Battery Strap
NOTE: Battery pad is not included
PROP ADAPTER INSTALLATION
The silver prop adapters should be installed on the front left and rear right motors.
The black prop adapters should be installed on the front right and rear left motors.
Please use a threadlocking compound on the screws.
FLIGHT CONTROLLER INSTALLATION
When installing the Flight Controller (FC), be sure to orient the case so the Mini USB
Port is facing the back of the quadcopter. Apply the mounting tape to the bottom of
the flight controller and place it at the center of the frame.
™
MANUAL ADDENDUM
Black
Propeller
Adapter
FRONT
Silver
Propeller
Adapter
Flight
Controller
Black
Propeller
Adapter
Silver
Propeller
Adapter
(not included)
REAR
FPV Transmitter
(not included)
