REQUIRED FOR COMPLETION
6 Channel Transmitter and Receiver
4S 1300 –2200 mAh LiPo Battery
LiPo Battery Charger
5.8G FPV Receiver and Monitor or Goggles
WARNING
Please read and understand this manual, the operation and all safety aspects
required for the safe operation of the product. Before use, if you feel that this
product is not for you, please return it to the place of purchase.
Manual Specifications and Description Changes
The instruction manual, warranties, and other associated documentation are
subject to change without notice. Hobbico assumes no responsibility for
inadvertent errors to this manual.
© 2016 RISE, a Hobbico company.
RXS255
INSTRUCTION
MANUAL
RISE0255

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RXS255 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rise RXS255

Summary of Contents for Rise RXS255

  • Page 1 Manual Specifications and Description Changes The instruction manual, warranties, and other associated documentation are subject to change without notice. Hobbico assumes no responsibility for inadvertent errors to this manual. © 2016 RISE, a Hobbico company. RISE0255...

  • Page 2: Safety Precautions

    INTRODUCTION Thank you for purchasing the RXS255. We want the time you spend with your new R/C quadcopter to be fun and successful, so please read the entire manual before beginning setup. If for any reason you think this R/C model is not for you, return it to the dealer immediately.

  • Page 3: Battery Warnings

    In no case shall RISE’s liability exceed the original cost of the purchased kit. Further, RISE reserves the right to change or modify this warranty without notice. In that RISE has no control over the final assembly or...
  • Page 4 DIMENSIONS Size: 257mm (10.1in) diagonally motor to motor Width: 235mm (9.25in) CONTENTS Length: 218mm (8.6in) Prop: 5 x 4.5 RXR RISE RXS255 Blade Length: 127mm (5in) Pads for the battery Empty Weight: 460g (16.2oz.) without battery Propeller Set 2.4 GHz Antenna...

  • Page 5: Radio System

    SETUP The RXS255 is completely assembled. All the bolts have been set to the proper torque and have thread locking compound applied to keep them secure. RADIO SYSTEM Your transmitter should have a switch for channel 5. The model setup below is typical for most transmitters.

  • Page 6: Flight Controller Setup

    Open the GCS app and connect the RXS255 with your mini-USB cable. When the communication window shows that the flight controller is connected to the GCS app, click on the configuration button.
  • Page 7 Download the latest settings file for the RXS255 from http://www.explore-rise.com Open the File menu in LibrePilot and click on “Import UAV settings” to load the settings file. If an Entry Point error pops up, click OK until a window opens to select the file to be loaded onto the flight controller.

  • Page 8: General Settings

    At the end of the wizard is the screen to be used to set the motor arming procedure. The recommended setting is Yaw Right which requires the yaw control to be held to the right while the throttle is at 0 for 3 seconds to arm the motors. Holding the Yaw control to the left will disarm the motors.

  • Page 9: Propeller Installation

    CCW – counter clockwise rotation when viewed from above CW PROP CCW PROP FPV SYSTEM The RXS255 has a 1000TVL camera and a 32 channel VTX. The camera angle can be adjusted up to 30 degrees. T h e FP V Vid e o...

  • Page 10: Flight Modes

    BATTERIES The RXS255 has been tested with 4-cell LiPo batteries between 1300 (30C or higher) and 2200mAh (20C or higher). Typical flight time is around 4 minutes. The flight controller does not have a low voltage cutoff to protect the LiPo from damage.

  • Page 11: Spare Parts

    MOTOR ARMING & TAKEOFF Turn on the transmitter and connect the flight battery to the RXS255. Place the quadcopter on a level surface and let it sit for 10 seconds to let the flight controller set up the gyros. Arm the motors by holding the yaw control to the right for at least 3 seconds, and center the left stick.
  • Page 12 RXS255 © 2016 RISE, a Hobbico company. RISE0255...
