WARNING
Please read and understand this manual, the operation and all safety aspects
required for the safe operation of the product. Before use, if you feel that this
product is not for you, please return it to the place of purchase.
Manual Specifications and Description Changes
The instruction manual, warranties, and other associated documentation are
subject to change without notice. Hobbico assumes no responsibility for
inadvertent errors to this manual.
WARNING! This product includes a lithium polymer (LiPo) battery.
Improper handling may result in FIRE! You are responsible for following all safety
precautions as outlined in this instruction manual.
© 2018 RISE, a Hobbico company.
130 RACER
INSTRUCTION
MANUAL
RTF – RISE0210
FPV-R – RISE0211
v1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INDORFIN 130 RACER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rise INDORFIN 130 RACER

  • Page 1 WARNING! This product includes a lithium polymer (LiPo) battery. Improper handling may result in FIRE! You are responsible for following all safety precautions as outlined in this instruction manual. ™ © 2018 RISE, a Hobbico company. RTF – RISE0210 FPV-R – RISE0211 v1.1...
  • Page 2: Lithium Battery Warning

    INTRODUCTION Thank you for purchasing the INDORFIN 130 RACER. We want the time you spend with your new R/C quadcopter to be fun and successful, so please read the entire manual before beginning setup. If for any reason you think this R/C model is not for you, return it to the dealer immediately.
  • Page 3: Warranty

    In no case shall RISE’s liability exceed the original cost of the purchased kit. Further, RISE reserves the right to change or modify this warranty without notice. In that RISE has no control over the final assembly or material used for final assembly, no liability shall be assumed nor accepted for any damage resulting from the use by the user of the final user assembled product.
  • Page 4: Know Before You Fly

    DO NOT alter or modify the model. Doing so may result in an unsafe or unflyable model. When and if repairs are necessary you must correctly install all components so that the model operates properly on the ground and in the air. Please check the operation of the model before every fl ight to insure that all equipment is operating and that the model has remained structurally sound.
  • Page 5 Prop: 70mm (2.75 in.) 3 blade propeller diameter Weight: 106g (3.7 oz.) without battery Indorfi n RTF Racer Contents AA batteries Screwdriver RISE Indorfin Racer Transmitter Indorfi n FPV-R Racer Contents FPV Goggle and Monitor with RISE Indorfin Racer antenna...
  • Page 6: Battery Charging

    Indorfin FPV-R to Vusion Transmitter” section on page 7 to link the transmitter and receiver. NOTE: Always turn on the RISE RISJ200 transmitter before connecting the battery to the Indorfin. BATTERY CHARGING (RISE2023 Balance Charger & RISE2024 Charge Adapter) The battery will need to be charged before the first flight.
  • Page 7: Battery Installation

    LINKING THE INDORFIN FPV-R TO THE RISE J2000 TRANSMITTER The Indorfin FPV-R can be linked to the RISE J2000 transmitter included with the Vusion 250, House Racer, etc. To link the drone to the J2000...
  • Page 8: Fpv Camera

    FPV CAMERA The Indorfin has a built in FPV camera and a 40 channel VTX that transmits on the A, B, E, F and R bands. Your monitor or goggle must be set to the correct band and channel to display the video feed from the camera. If a Tactic FPV-RM2 LCD monitor is being used: 1.
  • Page 9: Flight Controls

    FLYING FLIGHT CONTROLS DUAL RATES The stock transmitter for the Indorfin has two settings for the sensitivity of the controls. When the switch is pushed toward the back of the controller, it is in the high rate position. The controls are at the maximum sensitivity. Low Rates –...
  • Page 10: Takeoff And Landing

    ACRO-MODE FLIGHT To hover, quick movements with right stick in the opposite direction of any drifting will be needed to keep the Indorfin level. To fly the Indorfin in this mode, move the right stick in the desired direction and adjust the throttle position as needed to maintain the Indorfin’s altitude.
  • Page 11: Maintenance

    Arm the motors by holding the left stick in the lower right corner until the Indorfin beeps once. The motors are now armed. The motors will not spin until the throttle is above 0%. Advance the throttle until the motors start to spin. After verifying that all 4 motors are spinning, continue moving the throttle up until the drone is at least 2 feet above the ground.
  • Page 12 PROPELLER REPLACEMENT CCW PROP CW PROP FRONT The propellers should be checked for damage after each flight. If the Indorfin is suddenly making a strange noise while in flight, a damaged prop is the most likely cause for the vibration. Also, make sure that the screws that hold the propellers in place are not loose.
  • Page 13: Esc Calibration

    ESC REPLACEMENT To replace an ESC, remove the 6 screws that hold the Upper and Lower Body parts to the frame: 1. Unplug the camera and put the upper body aside. 2. Remove the flight battery connector cover. 3. Remove the Bottom Cover from the frame. 4.
  • Page 14 The same wires used with the PPM Receiver can be soldered to the PPM cable that comes with the converter. Another option is order the RISE Camera Cable (RISE2114). The wires will have to be moved for the cable to work correctly.
  • Page 15 Connect the Indorfin to Betaflight and change the Receiver Mode on the Configuration page to PPM. RISE2114 Cable Modifications BLACK BLACK BLACK Stock Indorfin Lock Tabs RISE2114 Adapter YELLOW YELLOW Plug Plug Plug YELLOW To remove a wire, carefully lift To make the PPM Adapter Plug, To make the Indorfin RX Plug, the Lock Tab with a hobby knife...
  • Page 16 On the Betaflight Configuration page, the appropriate Spektrum receiver must be selected in the Serial Receiver Provider part of t h e R e c e i v e r s e c t i o n (DSMX=2048 or DSM2=1024). On the Betaflight Receiver page, the Channel Map needs to be changed to Spektrum.
  • Page 17 your transmitter. 1. Remove the props from the Indorfin. 2. Open the Betaflight Configurator app. 3. Connect the Indorfin to the PC with a micro USB cable. 4. Connect the flight battery to the Indorfin. 5. Go to the Receiver page. 6.
  • Page 18: Troubleshooting

    RESTORE BETAFLIGHT SETTINGS Before making a change to any settings in the Betaflight app, please use this procedure to save the current configuration so it can be restored if needed. The Restore button does not update any of the changes made with the CLI. Please use the following procedures to save and reload all of your current settings –...
  • Page 19 PROBLEM: The Indorfin flips over when attempting to take off SOLUTION: (1) Make sure all 4 motors are spinning. SOLUTION: (2) Check the motors by manually spinning each prop. If one or more motors do not spin freely, check the motor for damage. SOLUTION: (3) Check the props for damage and verify that they are mounted on the correct motor.
  • Page 20: Exploded View

    EXPLODED VIEW...
  • Page 21: Replacement Parts

    REPLACEMENT PARTS Key # Stock No. Description RISE2125 Canopy Indorfin 130 RISE2126 Battery/Camera Frame Indorfin RISE2127 3-Blade Prop Set Indorfin 130 RISE2128 Motor 1104-4100Kv CW Indorfin RISE2129 Motor 1104-4100Kv CCW Indorfin RISE2130 Battery Plug Support Indorfin RISE2131 Battery Door Indorfin 130 RISE2132 Bottom Case w/Cam/LED Cover RISE2133...
  • Page 22 FCC Radiation Exposure Statement This device complies with part 15.249 of the FCC rules. Changes or modifications not expressly approved by RISE will void the user’s authority to operate this Tx. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
  • Page 23: Ce Compliance Information For The European Union

    Declaration of Conformity: Product: RISE 2.4GHz 6-Channel Tx Rx Item number: RISJ2000 J2000 The object of the declaration described here are in conformity with the requirements...
  • Page 24 ™ © 2018 RISE, a Hobbico company. RTF – RISE0210 FPV-R – RISE0211 v1.1...
