Maxi-Buffet®
INSTRUCTIONS FOR USE &
M
MAINTENANCE MANUAL
Version: 15.12
"
®
Advertisement
Table of Contents
Related Manuals for Elektral TRU-VEND Maxi-Buffet
Summary of Contents for Elektral TRU-VEND Maxi-Buffet
- Page 1 “She sells, You earn!.. ” ® Headquarters & FACTORIES: ® Elektral Elektromekanik San. ve Tic. A.S. Izmir Ataturk Industrial Zone M.K. Ataturk Blv.23 Cigli 35620 İzmir-TR Phone : +90 232 376 7300 : +90 232 376 7030 E-mail : elektral@elektral.com.tr www.elektral.com.tr...
-
Page 2: Table Of Contents
CONTENTS PAGE INTRODUCTION OPERATION and SAFETY WARNINGS 1. GENERAL DESCRIPTION 2. MAIN UNITS 2.1 Product Trays 2.2 Control Panel 2.2.1 Capacitive Touch Keypad 2.2.2 Graphical LCD Screen 2.2.3 Payment System (Optional) 2.2.3.1 Coin Selector 2.2.3.2 Change Giver 2.2.3.3 Bill Validator 2.2.3.4 Prepaid Card System (Cashless Payment Device) 2.3 Coin Return Push Button 2.4. - Page 3 4.2.1.4 Date-Time Settings 4.2.1.5 Language Setting 4.2.1.6 Change Password 4.2.1.7 Illumination Settings 4.2.1.7.1 Illumınation Power 4.2.1.7.2 LED Settings 4.2.1.8. Authorization 4.2.2 Statistics Main Menu 4.2.2.1 Sale Counter 4.2.2.2 Cash Counter 4.2.2.3 Errors 4.2.2.4 Reset 4.2.2.5 Get Report (Optional 4.2.3 Prices Main Menu 4.2.3.1 Price Settings 4.2.3.2 Discount (Optional) 4.2.4 Machine Test Main Menu...
- Page 4 9.6 Optional Heating /Conditioning 10. TROUBLESHOOTING 10.1 Warnings 10. 2 Frequently Asked Questions 10. 2.1 General Questions 10.2.2 Operational Questions 11. MENU TREE 12. SERVICE CENTRE and CERTIFICATE OF WARRANTY...
-
Page 5: Introduction
Turkish Export Assembly and IMMIB (Istanbul Mining and Metal Exporters Union). Another award won by Elektral is “The year 2013 First Rank in Innovation” organised by IAOSB (Izmir Ataturk Industrial Zone)-Ege University. Believing that real growth target is to be achieved with a global industrial understanding and a global move, Elektral is motivating all its employees with this understanding and continues rapidly with an intensive R&D work to... -
Page 6: Operation And Safety Warnings
OPERATION AND SAFETY WARNING Maxi-Buffet® Procedures & Safety Warnings before using the Maxi-Buffet® Technical specifications of the Maxi-Buffet® Installation of the Maxi-Buffet® Programming and further procedures The arrow-end lightning symbol inside the The exclamation mark inside the equilateral triangle equilateral triangle informs that in the context of informs the user that there are important instructions of the product, there is enough amount of ‘not usage and information inside the booklets given with the... - Page 7 Maxi-Buffet® BEFORE USE AND SAFETY WARNINGS Maxi-Buffet® TruVEND Vending Machine is secured by three electronic PIN CODEs and two mechanic locks which only allows the owner to operate the machine. Please do not share your PIN CODE. If you forget or lose the code, get in contact with our factory premises. Maxi-Buffet®...
-
Page 8: General Description
1. GENERAL DESCRIPTION The Vending Machine that you have chosen has been produced by our factory using high technology systems in parallel with other developing technologies and modern aesthetic design providing versatile usage. Tru-VEND® Vending Machines can be used in all public areas such as hotels, factories, hospitals, restaurants, clinics, cinemas, bus terminals, gas stations, doctor &... -
Page 9: Main Units
2. MAIN UNITS a- Stock Tray: Extra Storage Area for Products, User’s Manuals etc. items b- Product Trays: Described under Chapter 2.1 c- Compartment: Where Products fall before being picked; Product dispense hole. d- Control Panel: Described under Chapter 2.2 e- Mechanical Lock: There are Two Mechanical Locks and they are same f- Payment System Installation Panel: This part is used for installing Coin Selector/Change Giver/Bill Validator and Cashless Systems, Coin Return Push Button and Coin Return Chute... -
Page 10: Product Trays
m- Bill Validator (Optional) n- Change Giver (Optional) o- Change Giver Tubes p- Coin Return Push Button q- LED Illumination Module r- Control Cover: In case of failure, the hardware is used for ease of access s- Cash Box 2.1 Product Trays Filling up the Vending Machine and Placing the Products to the Trays 19 14 12 8 10 14 19... -
Page 11: Control Panel
WARNING: When pulling the trays out, make sure the front door is opened with a 180° angle. Otherwise the Rubber Front Door Gasket can be damaged. 2.2 Control Panel All operational controls can be followed on the Graphical LCD Screen, also Payment Systems and Touchpad Keypad are installed on this panel. -
Page 12: Bill Validator
2.2.3.3 Bill Validator The bill validator accepts only the pre-defined banknotes and proceeds with the payment process. It recognizes the currency bills which had been programmed and returns the unidentified or counterfeit banknotes. It can be used at the same time with either MDB Supporting Change Giver or Coin Selector. -
Page 13: Vending Machine Safety
b) Power Supply Module: This module is to provide DC Voltage. c) Main Electronic Module: All functions of the Maxi-Buffet Vending Machine are being controlled by this Module. d) Capacitive Touchpad Keypad e) Graphical LCD Screen f) IR Product Sensor: This module is used for checking the Proper Physical Vending Process. If there is no real vend then the credit will remain so that another product can be selected or the credit can be taken. -
Page 14: Programming
Maxi-Buffet® All programming settings of the can be done using the Touchpad Keypad on the Control Panel. Keypad buttons are as follows; X EXIT/NO www.elektral.com.tr √ SAVE/YES/SELECT 8 Up Arrow to Scroll Up READY TO OPERATE INSERT COIN/BILL 0 Down Arrow to Scroll Down 7 To copy the selected value in some menus i.e., Price... -
Page 15: Menus
PRICES Price Settings: This menu is for setting Prices, Currency PRICE SETTINGS Settings and Discount Rates. EXCHANGE OF RATE DISCOUNT MACHINE TEST Machine Test: This menu is for testing the hardware MOTOR CONTROL equipped on the Vending Machine (motors, IR Product IR CONTROL Sensor etc.). -
Page 16: Serial Protocol
4.2.1.1.1 Serial Protocol This menu is used for selecting the Payment System in SERIAL PROTOCOL use. EXECUTIVE Use UP (8) and DOWN (0) Scroll Keys and (√ ) CCTALK SELECT. impMDB PARALLEL MDB SETTINGS 4.2.1.1.2 MDB Settings MAX. WAIT This menu is for MDB Payment System Settings. MAX CHANGE 20.00 MAX. -
Page 17: Cctalk Settings (Optional)
Free Vend: This feature enables free distribution of products with prices set to ‘0’. Full bracket (X) means this feature is active. Product (XX): When in Price Holding operation mode these values become active. This is to mention that Nr. XX product belongs to Nr. XX Value in sequence. 4.2.1.1.4 CCTALK Settings (Optional) This menu is for CCTALK payment system settings. -
Page 18: Language Setting
4.2.1.5 Language Setting LANGUAGE SETTING This menu is for Language Selection. Desired Language TURKISH ENGLISH can be highlighted and selected with button (√ ) GERMAN SELECT. SPANISH Languages other than Turkish and English are Optional. CHANGE PASSWORD ADMIN PASSWORD 4.2.1.6 Change Password USER PASSWORD Move onto the Password you want to change using UP ALARM PASSWORD... -
Page 19: Statistics Main Menu
4.2.2 Statistics Main Menu SALE COUNTER 4.2.2.1 Sale Counter PROD. (11): 0 pcs. This menu displays the total number of products sold PROD. (12): 1 pcs. after the last reset. PROD. (13): 9 pcs. PROD. (14): 3 pcs. Each and every Product Selection can be chosen and PROD. -
Page 20: Reset
Change Giver Error Codes Other Error Codes Motor Error 3 01-003 Extreme Current on Motor No Credit1 01-004 Motor Error 1 Defective Tube Sensor1 01-005 Motor Error 2 Double Arrival1 01-006 Heat Sensor Error Acceptor Unplugged2 01-007 EEPROM Error Tube Jam1 01-008 Flash Error ROM checksum error1... -
Page 21: Prices Main Menu
4.2.3 Prices Main Menu PRICE SETTINGS PROD. (11): 0,50 EUR 4.2.3.1 Price Settings PROD. (12): 1,50 EUR PROD. (12): 0,25 EUR This menu is to set prices. Move onto the Product Number. PROD. (13): 0,00 EUR You wish to set prices and press (√ ) SELECT to enter New PROD. -
Page 22: Gsm/Gprs
4.2.5.3 GSM/GPRS (optional) This menu is for GSM/GPRS module settings. 4.2.5.4 Impact Sensor This menu is used for activating or deactivating the Impact Sensor against Vandalism as an increased safety precaution. 4.2.6 Machine Information In this menu, machine tracing number, software version etc. information can be found. 5. -
Page 23: Operation Of Maxi Buffet
Maxi-Buffet® Maxi-Buffet® is being delivered fixed on a Palette. The can either be used on its palette or on its bingo footers after being placed on a location carried on its wheel base. (There are 4 Fixing Screws on Corners of the Palette) You may also use the Vending Machine on its adjustable foot screws (should be fixed into the same screw holes after detaching from the palette) after placing the VM in its place. -
Page 24: Installation And Cleaning
5- Press the Coin Return Push Button. 8. INSTALLATION and CLEANING Maxi-Buffet® is designed to operate 7/24 basis. The Maxi-Buffet can be operated only after proceeding necessary steps described in the User’s Manual. Do not use water directly to clean the Machine. Use dry or damp cloth for cleaning. Electronic units should be protected from water. -
Page 25: Additional Tray / Canned Drink Dispenser
Useful Information; • Open the cooling unit from behind and check if the compressor unit is in operation. • Visually check if the compressor fan is operating. • There is a pipe connected with a valve on the Compressor to be used for gas filling. •... -
Page 26: Frequently Asked Questions
Never operate your Vending Machine if there is no Norm Earthed Mains Supply. 10.2 Frequently Asked Questions In this section you may find information about Frequently Asked Questions regarding Installation and the use of your vending machine. 10.2.1 General Questions: •... -
Page 27: Menu Tree
11. Menu Tree 1 Settings 1.8.29 Alarm 1.1 Validators 1.4 Date - Time 1.8.30 Bill 1.1.1 Serial Protocol 1.4.1 Date-Time Settings 1.8.31 Gsm/Gprs 1.1.1.1 Mdb 1.5 Language Setting 1.8.32 Tilt Sensor 1.1.1.2 Executive 1.5.1 Turkish 1.9 Default Settings 1.1.1.3 Cctalk 1.5.2 English 2 Statistics 1.1.1.4 Imp Mdb... - Page 28 4.4.1.1 Displays Change Giver Data 4.4.2 Bill Validator 4.4.2.1 Displays Bill Validator Data 4.4.3 Cashless Machine 4.4.3.1 Displays Cashless Payment System Data 4.5 Touchboard 4.5.1 Displays Touchboard Version 4.6. Relay Control 4.6.1 Relay 1 (Cooling) 4.6.2 Relay 2 (Fan) 4.6.3 Relay 3 4.7 Others 5 Accessories 5.1 Alarm...
-
Page 29: Service Centre And Certificate Of Warranty
All Warranty Services are at our Factory. All transportation risks and costs to and pro our Factory belongs to Customer. Thank you for selecting a product manufactured by ELEKTRAL A.S. Before using your new item please take a minute to read and fill out the forms on the reverse side of this card.
