Summary of Contents for Seagate ST500LX015
- Page 1 Product Manual ® Seagate Ultra Mobile SSHD Standard models Self-Encryption Drive models ST500LX015 ST500LX009 ST500LX016 ST500LX012 SED (FIPS 140-2) models Standard models w/ZGS (Review Pending) ST500LX011 ST500LX010 ST500LX014 ST500LX013 Gen 1.0 100742811 Rev. D May 2014...
- Page 2 Publication number: 100742811, Rev. D May 2014 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Seagate Ultra Mobile SSHD and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.
-
Page 3: Table Of Contents
ONTENTS ......... . . 1 EAGATE ECHNOLOGY UPPORT... - Page 4 ONTENTS ........19 UTHENTICATED IRMWARE OWNLOAD...
- Page 5 IGURES 5V S ....8 IGURE YPICAL TARTUP AND PERATION URRENT ROFILE FOR MODELS 5V S 16GB ... . . 8 IGURE YPICAL TARTUP AND...
-
Page 6: Seagate Technology Support Services
Authorized Service Centers • For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit: http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners/ For Seagate reseller portal, visit: http://www.seagate.com/partners/my-spp-dashboard/ Seagate Ultra Mobile SSHD Product Manual, Rev. D... -
Page 7: Introduction
NTRODUCTION ® This manual describes the functional, mechanical and interface specifications for the following Seagate Ultra Mobile SSHD model drives: MODEL MODEL MODEL MODEL SED (FIPS 140-2) TANDARD MODELS TANDARD MODELS MODELS MODELS ST500LX009 1HM162 ST500LX011 1HMG62 ST500LX015 1MV162 ST500LX010... -
Page 8: About The Serial Ata Interface
ATA I BOUT THE ERIAL NTERFACE The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages include: Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other ... -
Page 9: Drive Specifications
The specification summaries listed in the following tables are for quick reference. For details on specification measurement or definition, refer to the appropriate section of this manual. Table 1 Drive Specifications Summary ST500LX012, ST500LX013, ST500LX009, ST500LX010, RIVE PECIFICATION ST500LX014 & ST500LX016 ST500LX011 & ST500LX015 Formatted capacity 500 GB Guaranteed sectors 976,773,168 Heads Disks Bytes per sector... -
Page 10: Formatted Capacity
PECIFICATIONS Table 1 Drive Specifications Summary (continued) ST500LX012, ST500LX013, ST500LX009, ST500LX010, RIVE PECIFICATION ST500LX014 & ST500LX016 ST500LX011 & ST500LX015 Relative humidity gradient 30% per hour max 37.7°C max (operating) Wet bulb temperature (max) 40.0°C max (nonoperating) Altitude, operating –304.8 m to 3048 m (–1000 ft to 10,000+ ft) Altitude, nonoperating –304.8 m to 12,192 m (–1000 ft to 40,000+ ft) -
Page 11: Physical Organization
RIVE PECIFICATIONS HYSICAL ORGANIZATION Drive model Read/write heads Number of discs All models ECORDING AND NTERFACE ECHNOLOGY Interface Serial ATA (SATA) Recording method Perpendicular Recording density 1885 Kb/in Track density 366 ktracks/in avg Areal density 690 Gb/in Spindle speed 5400 RPM +/- 0.2% Sustained data transfer rate 100 MB/s max I/O data-transfer rate... -
Page 12: Start / Stop Times
RIVE PECIFICATIONS TART STOP TIMES Table 3 Start/stop times ° Typical seek times (ms) Typical Max @ 25 Power-on to ready (sec) Standby to ready (sec) OWER PECIFICATIONS The drive receives DC power (+5V) through a native SATA power connector (refer to Figure 3 2.7.1 Power consumption... -
Page 13: Figure 1 Typical 5V S
RIVE PECIFICATIONS 2.7.1.1 Typical current profiles The typical 5V startup and operation current profile is shown in Figure 1 Figure 1 Typical 5V Startup and Operation Current Profile for 8GB models Figure 2 Typical 5V Startup and Operation Current Profile for 16GB models SSHD P EAGATE LTRA... -
Page 14: Conducted Noise
RIVE PECIFICATIONS 2.7.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 15-ohm resistive load on the +5 volt line. Using 5-volt power, the drive is expected to operate with a maximum of 100 mV peak-to-peak square-wave injected noise ... -
Page 15: Environmental Specifications
NVIRONMENTAL PECIFICATIONS This section provides the temperature, humidity, shock, and vibration specifications for Seagate Ultra Mobile SSHD drives. Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Above 1000 feet (305 meters), the maximum temperature is derated linearly by 1°C every 1000 feet. -
Page 16: Vibration
Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses the lower limit for the threshold curve* to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards. -
Page 17: Lectromagnetic Mmunity
TB per 8760 power-on hours. Workload rate limit = TB transferred × (8760/ recorded power-on hours). To determine the warranty for a specific drive, use a web browser to access the http://www.seagate.com/support/warranty-and-replacements/ following web page: Warranty From this page, click on “Check to see if the drive is under Warranty”. Users will be asked to provide the drive serial number, model number (or part number) and coun- try of purchase. -
Page 18: Agency Certification
As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure, disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules. -
Page 19: Environmental Protection
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%. -
Page 20: Configuring And Mounting The Drive
Figure 3 Figure 3 Attaching SATA Cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Seagate Ultra Mobile SSHD drives support latching SATA connectors. SSHD P EAGATE LTRA OBILE RODUCT ANUAL... -
Page 21: Drive Mounting
ONFIGURING AND OUNTING THE RIVE RIVE OUNTING Users can mount the drive in any orientation using four screws in the side-mounting holes. Refer to for drive Figure 4 mounting dimensions. Follow these important mounting precautions when mounting the drive: Allow a minimum clearance of 0.030 in (0.76 mm) around the entire perimeter of the drive for cooling. ... -
Page 22: About Fips
For more information, refer to 'Security Rules' section in the 'Security Policy' document uploaded on the NIST website. To reference the product certification visit: http://csrc.nist.gov/groups/STM/cmvp/documents/140-1/1401vend.htm, and search for “Seagate”. Security Level 2. -
Page 23: About (Sed) Self -Encrypting Drives
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. Seagate's SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two SATA commands: Trusted Send ... -
Page 24: R Ng
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1. -
Page 25: Serial Ata (Sata) Interface
OMPATIBILITY Seagate Ultra Mobile SSHD drives incorporate connectors which enable users to hot plug these drives in accordance with the Serial ATA: High Speed Serialized AT Attachment specification revision 2.0. This specification can be downloaded from www.serialata.org. This device requires a COMRESET from the host after a hotplug event. -
Page 26: Sata D P C Pd
ATA (SATA) I ERIAL NTERFACE ATA D ERIAL EVICE ONNECTOR EFINITIONS summarizes the signals on the Serial ATA interface and power connectors. Refer to the below. Table 8 Notes Table 8 Serial ATA Connector Pin Definitions EGMENT UNCTION EFINITION Ground 2nd mate Differential signal pair A from Phy Ground... -
Page 27: Supported Ata Commands
ATA (SATA) I ERIAL NTERFACE ATA C UPPORTED OMMANDS lists Serial ATA standard commands that the drive supports. For a detailed description of the ATA commands, refer to Table 9 the Serial ATA International Organization: Serial ATA (Revision 3.2). Refer to www.sata-io.org. Refer to on page 29 for details and subcommands used in the S.M.A.R.T. - Page 28 ATA (SATA) I ERIAL NTERFACE Table 9 Supported ATA commands ATA-standard commands names Command code (in hex) S.M.A.R.T. Enable Operations B0h/D8h S.M.A.R.T. Enable/Disable Auto Offline B0h/DBh S.M.A.R.T. Enable One Attribute Modification B0h/E0h S.M.A.R.T. Execute Offline B0h/D4h S.M.A.R.T. Free Fall Protection Host Interface S.M.A.R.T.
-
Page 29: Identify Device Command
ST500LX011 Drive model number: ST500LX012 27–46 (40 ASCII characters, padded with blanks to end of string) ST500LX013 ST500LX014 ST500LX015 ST500LX016 (Bits 7–0) 8010 Maximum sectors per interrupt on Read multiple and Write multiple (16) Trusted Computing Feature set options 0000... - Page 30 The maximum value that shall be placed in this ST500LX013 = 0FFFFFFFh field is 0FFFFFFFh. The 0FFFFFFFh value applies to all capacities over ST500LX014 = 0FFFFFFFh 137GB (see Section 2.1 for related information). ST500LX015 = 0FFFFFFFh ST500LX016 = 0FFFFFFFh Retired 0000 Multiword DMA active and modes supported...
- Page 31 ST500LX012 = 976,773,168 100–103 ST500LX013 = 976,773,168 These words are required for drives that support the 48-bit addressing ST500LX014 = 976,773,168 feature. Maximum value: 0000FFFFFFFFFFFFh. ST500LX015 = 976,773,168 ST500LX016 = 976,773,168 Streaming Transfer Time - PIO 0000 Reserved 0000 Physical sector size / Logical sector size...
- Page 32 ATA (SATA) I ERIAL NTERFACE Table 11 Bit Descriptions (continued) Ultra DMA mode 0 is supported. Ultra DMA mode 1 is supported. Ultra DMA mode 2 is supported. Ultra DMA mode 3 is supported. Ultra DMA mode 4 is supported. Ultra DMA mode 5 is supported.
-
Page 33: Set Features Command
ATA (SATA) I ERIAL NTERFACE 6.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted. -
Page 34: Commands
) that eliminates unnecessary drive returns. The diagnostic software ships with all new drives and is also available at: http://www.seagate.com/support/downloads/seatools/. This drive is shipped with S.M.A.R.T. features disabled. Users must have a recent BIOS or software package that supports S.M.A.R.T. to enable this feature. The table below shows the S.M.A.R.T. command codes that the drive uses. - Page 35 NDEX UMERICS 32-byte Data Encryption Key 18 electrical fast transient 12 32-byte hardware RNG 19 Electromagnetic Compatibility (EMC) 13 Electromagnetic Compatibility control Regulation 13 Electromagnetic Compatibility Directive (2004/108/EC) 13 electromagnetic immunity 12 acoustics 11 electrostatic discharge (ESD) 12 active mode 9 EN 55022, Class B 13 Address 22 EN 55024 13...
- Page 36 11 S.M.A.R.T. implementation 22 safety certification 13 SATA ports 3 screws 16 physical characteristics 6 Seagate Technology Support Services 1 Physical organization 6 sectors 5 point-to-point 3 Security Disable Password 23 power consumption 7 Security Erase Prepare 23...
- Page 37 sleep mode 9 spindle speed 6 spinup (DC power) 7 spinup power 7 Standby 23 standby 7 Standby Immediate 23 standby mode 7 standby timer 9 Start/stop times 7 static-discharge 15 subassembly 13 surge immunity 12 temperature 6 timers (Idle and Standby) 9 track density 6 Track-to-track seek time 6 Transport major version number 26...
- Page 38 Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100742811, Rev.
