- Page 1 ELECTRIC COOKER ZCE 640 ZCE 641 INSTRUCTION BOOKLET Please read this instruction booklet before using the appliance...
-
Page 2: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the appliance. If you need assistance, contact our Customer Care Department on 08705 727727 Installation Service • This cooker must be installed by qualified personnel, according to the manufacturer’s instructions and to •... -
Page 3: Table Of Contents
Contents For the User For the Installer Important Safety Information Important Safety Requirements Control Panel Instructions for the Installer Operation Electrical connections The Minute Minder Electric Oven Before the First Use of the Oven Using the Oven Using the Fan Oven Cooking Chart Defrosting Grilling... -
Page 4: Control Panel
Control Panel 1. Front left hotplate control knob 6. Oven thermostat control knob 2. Back left hotplate control knob 7. Minute Minder 3. Back right hotplate control knob 8. Mains Pilot Light 4. Front right hotplate control knob 9. Oven Thermostat Pilot Light 5. -
Page 5: Operation
Operation Electric Hotplates To switch on a hotplate, turn the relevant control knob to the required heat setting. The control knob is numbered 1 - 6 0 - OFF 1 - Minimum 6 - Maximum. The hob has two types of hotplates: Normal Hotplates (Back right and left) We recommend the plates are switched to maximum (6) for a short while to boost the plate, and then adjusted to... -
Page 6: The Minute Minder
Hints and Tips Saucepans for use on solid plates should have several characteristics: • They should be fairly heavy duty • They should fit the heat area exactly, or be slightly larger for efficient use, NEVER smaller. • They should have a flat base to ensure good contact with the plate. -
Page 7: Electric Oven
Electric Oven Oven Function Control Knob Oven Light - The oven light will be on without any cooking function Defrost Setting - This setting is intended to assist in thawing of frozen food . Fan cooking - This allows you to roast or roast and bake simultaneously using any shelf, without flavour transference. -
Page 8: Using The Oven
Using the Oven Always cook with the oven door closed. Stand clear when opening the drop down oven door. Do not allow it to fall open - support the door using the door handle, until it is fully open. The oven has four shelf levels, and is supplied with two shelves. -
Page 9: Using The Fan Oven
Using the Fan Oven The air inside the oven is heated by the element around Hints and Tips the fan situated behind the back panel. The fan circulates hot air to maintain an even temperature inside the oven. Shelf positions are not critical, but make sure the shelves are evenly spread. -
Page 10: Cooking Chart
Cooking Chart This chart is intended as a guide only. It may be necessary to increase or decrease the temperature to suit your individual requirements. Only experience will enable you to determine the correct setting for your personal requirements. Food Shelf Cooking Cooking... -
Page 11: Defrosting
Defrosting Hints and Tips The oven fan operates without heat and circulates the air, at room temperature, inside the oven. This increases the speed of defrosting. However, please note that the • Cover food with a lid, aluminium foil or plastic film temperature of the kitchen will influence the speed of to prevent drying out during defrosting. -
Page 12: Grilling
Grilling Cooking chart Grilling must be carried out with the oven door closed. The grill pan handles must be removed Cooking time depends on the thickness of the meat and from the pan. not on its weight. How to Use the Grill Type of food Mins per side 1. -
Page 13: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the cooker from the electricity supply. This appliance cannot be cleaned with steam or with a steam cleaning machine. The Hob Top The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. - Page 14 Cleaning the Oven Oven Cavity Before cleaning always allow the cooling fan to cool the oven down before switching off at the The enamelled oven cavity is best cleaned whilst the electricity supply. oven is still warm. The oven should be kept clean at all times. A Wipe the oven over with a soft cloth soaked in warm build-up of fats or other foodstuffs could result in soapy water after each use.
-
Page 15: Something Not Working
Something Not Working If the appliance is not working correctly, please carry out the following checks, before contacting your local Zanussi Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 16: Customer Care Department
Service and Spare Parts Before calling out an engineer, please ensure you have read the details under the heading “Something Not Working.” In the event of your appliance requiring service, or if When you contact the Service Force Centre you will need you wish to purchase spare parts, please contact your to give the following details: local Service Force Centre by telephoning:... -
Page 17: Guarantee Conditions
Guarantee Conditions Zanussi Guarantee Conditions European Guarantee We, Zanussi, undertake that if, within 12 months of the If you should move to another country within Europe then your guarantee moves with you to your new home date of the purchase, this Zanussi appliance or any part subject to the following qualifications: thereof is proved to be defective by any reason only of faulty workmanship or materials, we will, at our option,... -
Page 18: Important Safety Requirements
Instructions for the Installer Technical Data Appliance Class 2 sub class 1 and Class 1 Oven Dimensions Convection Heating Element 2000 W Height 900 mm Grill Element 1650 W Depth 600 mm Convection Fan 30 W Width 600 mm Oven light 25 W Oven Capacity 56 litres / 1.97 Cu. -
Page 19: Electrical Connections
Electrical connections The cooker should be connected to a double pole switch Any electrical work required to install this hob with a minimum gap of 3 mm. between the switch should be carried out by a qualified electrician contacts and of a type suitable for the required load in or competent person, in accordance with the compliance with the current electric regulations. - Page 20 ZCE640/ZCE641 0,78 kWh 41 min. ² 1040 cm CUSTOMER CARE Zanussi-Electrolux Cornwall House 55-77 High Street Slough Berkshire, SL1 1DZ Tel: 08705 727727 © Electrolux plc 2004 From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
