Pratica Chef Express Service Manual page 79

The following table shows the description of each status as well as the indication in HMI display.
P006 Status
0 READY
1 RUN
2 SUB
3 FAULT
4 NOT USED
5 CONFIGURATION
When a failure occurs, the frequency inverter will flash the code on the screen and will prevent
the blower motor from operating.
HMI
Indicates the inverter is ready to be enabled.
Indicates the inverter is enabled.
Indicates the incoming voltage is too low for
operation (under voltage) and will not accept the
enabling command.
The inverter will flash the fault code on the screen
when there is a problem.
- Without indication.
Indicates the inverter has an incompatible program
for the parameter. After pressing the
keep showing an arrow until the incorrect setting is
corrected, as shown in the figure.
Description
key, it will
73
