Summary of Contents for InWin MERCURY AM120S
- Page 1 User Manual...
- Page 2 Product Video Information Mercury AM120S Product Video Mercury AM120S Installation Video...
- Page 3 Product Story Mercury AM120S is a slender cooling fan designed by InWin. Mercury emits a silent 17 - 29 dB(A) noise level due to the carefully constructed fan blades and inner frame. The overall construction not only presents silent operation, but enhances thermal efficiency too. The...
-
Page 4: Package Contents
Package Contents Triple Pack 1. Mercury AM120S Fans x 3 2. Screws x 12 3. ARGB One-Click Controller x 1 4. ARGB Extension Cables 500 mm x 2 5. PWM Fan Extension Cables 500 mm x 2 Single Pack 1. Mercury AM120S Fan x 1 2. -
Page 5: Specifications
165 x 125 x 25 mm 165 x 125 x 65 mm (L x W x H) 6.49 x 4.92 x 0.98" 6.49 x 4.92 x 2.55" Warranty 3 Years * Specifications may vary based on different regions. * InWin products comply with RoHS regulations. -
Page 6: Cable Information
Cable Information PWM Fan Cable 20 mm 130 mm +12V ARGB Cable 20 mm 130 mm DATA DATA PWM Fan Extension Cable 500 mm +12V ARGB Extension Cable 500 mm DATA DATA ARGB One-Click Controller Note: Only in Triple Pack 200 mm... -
Page 7: Installation
Installation Please make sure the power is off. Install the fans in your PC case and mount them in the designated areas. *How to determine your airflow direction: The arrow shows the intake direction of the air blowing through. How to attach the fans and connect to a motherboard 4-Pin (12V, PWM) 3-Pin (5V, ARGB) - Page 8 Installation You can use ARGB extension cables and PWM fan extension cables for the following reasons: a. The distance between fans are too far away. b. The distance between the fan to the M/B is too far away. c. The distance between the fan to the ARGB One-Click Controller is too far away.
- Page 9 Full Circle LED-Purple Flow-Red LED-White Flow-Green Light at the endof Flow-Blue theTunnel *InWin reserves the right to change the lighting modes. * For more installation instructions, please scan the QR Code or watch the video in the website link: https://youtu.be/_S_LLcqe0KI .
-
Page 10: Troubleshooting
1. Please check your system's power. 2. Please make sure all the connectors are connected properly. 3. For more technical support, please visit InWin Forum at https://forum.in-win.com/ Important Notes 1.Please install the fans by following our instructions. 2.When storing the fans, please keep this product away from high temperatures. - Page 11 Copyright © 2022 In Win Development Inc. All Rights Reserved.
