! Tools required:
! Do not throw away packaging materials until assembly is complete.
! Assemble this item on a soft surface, such as cardboard or carpet, to protect finish.
A
C
E
mounting plate x
G
9857 / 986 - 0/07
cam screw 8x
shelf bracket 2x
bergen closet wide open shelf
B
D
F
felt pad 6x
cam lock 8x
wooden dowel 8x
screw 2x
Page of 4
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for West Elm bergen closet wide open shelf
Summary of Contents for West Elm bergen closet wide open shelf
- Page 1 ! Tools required: ! Do not throw away packaging materials until assembly is complete. ! Assemble this item on a soft surface, such as cardboard or carpet, to protect finish. cam lock 8x...
- Page 2 .Insert cam locks (B) into holes of side panels. Turn cam locks with a phillips screwdriver so that the arrow on top is pointing out as shown. 2. With a hammer gently tap wooden dowels (D) into holes in side of panels as shown.
- Page 3 4. Fasten side panels to bottom panel. Fit cam screws into cam locks and tighten using phillips screwdriver. 5. Slide back panel into groove. Make sure panel slides all the way into the bottom panel groove.
- Page 4 7. Attach felt pads (G) to base of unit. 8. Insert shelf brackets (C) into holes at desired position. Slide shelf over brackets into cabinet. 9. Multiple units can be attached together as shown using screws (F) and mounting plates (E).
