Asus PA32U Firmware Update Procedures

English
PA32U Firmware Update Procedures
1. Download and extract the latest firmware file to the root directory of a USB 2.0
drive. (File system: FAT32.) The monitor can only be upgraded using firmware file
named "PA32U.bin".
Remove the USB cover and insert the USB drive into the USB 2.0 A-type port at
2.
the back of the monitor.
3. Press both buttons above the power button simultaneously. The monitor will
begin the firmware update which takes about 25 seconds. If you have a power
failure during firmware update, the monitor will stop the process and turn off. After
power resumes, the monitor will continue the firmware update and reboot within 5
minutes. Contact your local service center if you encounter any problems.
4. After the firmware update completes, switch off the monitor using the power switch
on the back.
5. Turn on the monitor and reset all settings via the System Setup menu. The OSD
menu settings will be restored to factory defaults. Check the firmware version in the
System Setup > Information menu.
System Setup
B a c k
L a n g u a g e
Di s p l a y P o r t S t rea m
K e y L o c k
P o w er I n d i c at o r
A m b i e n t E ff e c t
I n f o r m a t i o n
A l l Re s e t
When there is a newer version of firmware available on the ASUS website,
follow the procedures below to update your monitor. Make sure that the power
supply is stable and the USB drive is plugged in during the whole process.
Updating firmware.
Do not turn off power until the
finishing message appears.
Standard Mode DisplayPort 3840 x 2160@
DisplayPort
3840x2160
HDR OFF
.
.
.
FW Version MCMxxx
Firmware update completed.
Please switch AC power on/off
once before using monitor.
ASUS PA32U
60Hz
1
