N86XX Decoded Engine
User's Guide
™
http://manualforhoneywellthermostat.com

Advertisement

Table of Contents
loading

Related Manuals for Honeywell N86 Series

Summary of Contents for Honeywell N86 Series

  • Page 1 N86XX Decoded Engine User’s Guide ™ http://manualforhoneywellthermostat.com...
  • Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in speci- fications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not repre- sent a commitment on the part of HII.
  • Page 3 Honeywell shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.
  • Page 4 Dust and Dirt The engine must be sufficiently enclosed to prevent dust particles from gathering on the imager and lens. When stocking the unit, keep it in its protective packaging. Dust and other external contaminants will eventually degrade unit performance. RoHS The engine is in compliance with Directive 2002/95/EC, Restriction of the Use of Certain Hazardous Substances in...

  • Page 5: Table Of Contents

    Table of Contents Chapter 1 - Getting Started Introduction ..............1-1 About This Manual ............1-1 Unpacking Your Device..........1-1 OEM Engine Models ........... 1-2 Connecting the Development Engine to the PC..1-3 Connecting with USB ..........1-3 Connecting with RS232 Serial Port ....... 1-5 Menu Bar Code Security Settings .......
  • Page 6 Chapter 3 - Input/Output Settings Power Up Beeper ............3-1 Beep on BEL Character..........3-1 Trigger Click..............3-2 Good Read and Error Indicators........3-2 Beeper – Good Read ..........3-2 Beeper Volume – Good Read........ 3-3 Beeper Pitch – Good Read ........3-3 Beeper Pitch – Error ..........3-4 Beeper Duration –...
  • Page 7 Multiple Symbols ............3-16 No Read ..............3-17 Video Reverse............3-18 Chapter 4 - Data Editing Prefix/Suffix Overview ..........4-1 To Add a Prefix or Suffix: ........4-1 To Clear One or All Prefixes or Suffixes....4-2 To Add a Carriage Return Suffix to All Symbologies............
  • Page 8 Chapter 6 - Symbologies All Symbologies ............6-2 Message Length Description ........6-2 Codabar ...............6-3 Codabar Concatenation ......... 6-4 Code 39 ...............6-6 Code 32 Pharmaceutical (PARAF) ......6-8 Full ASCII............... 6-9 Code 39 Code Page ..........6-9 Interleaved 2 of 5 ............6-10 NEC 2 of 5 ..............6-12 Code 93 ..............6-14 Code 93 Code Page ..........
  • Page 9 Codablock F .............. 6-41 PDF417 ..............6-42 MicroPDF417 ............6-43 GS1 Composite Codes ..........6-44 UPC/EAN Version ..........6-44 GS1 Emulation ............6-45 TCIF Linked Code 39 (TLC39) ........6-46 QR Code ..............6-46 Data Matrix ..............6-48 Data Matrix Code Page ........6-48 MaxiCode ..............
  • Page 10 Chapter 9 - Utilities To Add a Test Code I.D. Prefix to All Symbologies..............9-1 Show Decoder Revision ..........9-1 Show Scan Driver Revision .........9-1 Show Software Revision..........9-1 Show Data Format............9-2 Test Menu..............9-2 TotalFreedom ..............9-2 Application Plug-Ins (Apps) .........9-3 EZConfig Introduction ..........9-3 Installing EZConfig from the Web ......

  • Page 11: Chapter 1 - Getting Started

    N86XX engine. Dimensions, warranty, and customer sup- port information are also included. Honeywell’s bar code scanners are factory programmed for the most common terminal and communications settings. If you need to change these settings, programming is accomplished by scanning the bar codes in this guide.

  • Page 12: Oem Engine Models

    OEM Engine Models There are three models of the OEM engine, which may be used with the inter- faces described in this manual. Refer to the chart below to determine the mod- els that can be used with your interface. Models Interface Decoding Capability...

  • Page 13: Connecting The Development Engine To The Pc

    Connecting the Development Engine to the PC The development OEM engine can connect to a PC for evaluation. Connecting with USB Note: If using the N86XXX-XXX-XX5 engine with USB Micro-B, do not supply power through the flex connector. Doing so may damage the host or engine.
  • Page 14 2a. If using hi-speed USB, connect the USB interface cable to the side of the engine and to the USB port on the computer. Note: For additional USB programming and technical information, refer to Honeywell’s “USB Application Note,” available at www.honeywellaidc.com. When connecting the engine using full-speed or high-speed USB, all communication parameters between the engine and terminal must match for correct data transfer using USB protocol.

  • Page 15: Connecting With Rs232 Serial Port

    Connecting with RS232 Serial Port If using an RS-232 connection, connect the serial interface cable to the interface board and to the matching port on the back of the com- puter. Connect the power supply connector to the serial interface cable. Plug in the power supply.

  • Page 16: Menu Bar Code Security Settings

    Manual. Menu Bar Code Security Settings Honeywell scanners are programmed by scanning menu bar codes or by send- ing serial commands to the engine. If you want to restrict the ability to scan menu codes, you can use the Menu Bar Code Security settings. Contact the...

  • Page 17: Resetting The Factory Defaults

    are no custom defaults, it will reset the engine to the factory default settings. Any settings that have not been specified through the custom defaults will be defaulted to the factory default settings. Activate Custom Defaults Resetting the Factory Defaults This selection erases all your settings and resets the engine to the origi- nal factory defaults.
  • Page 18 1 - 8...

  • Page 19: Chapter 2 - Programming The Interface

    USB COM Port Emulation Scan the following code to program the engine to emulate a regular RS232-based COM Port. If you are using a Microsoft® Windows® PC, you will need to download a driver from the Honeywell website 2 - 1...

  • Page 20: Verifone ® Ruby Terminal Default Settings

    (www.honeywellaidc.com). The driver will use the next available COM Port number. Apple® Macintosh computers recognize the engine as a USB CDC class device and automatically uses a class driver. USB COM Port Emulation Note: No extra configuration (e.g., baud rate) is necessary. CTS/RTS Emulation CTS/RTS Emulation On * CTS/RTS Emulation Off...

  • Page 21: Gilbarco ® Terminal Default Settings

    Verifone Ruby Settings ® Gilbarco Terminal Default Settings Scan the following Plug and Play code to program the scanner for a Gil- barco terminal. This bar code sets the baud rate to 2400 bps and the data format to 7 data bits, even parity, 2 stop bits. It also adds a carriage return (CR) suffix and programs the following prefixes for each symbology: Symbology Prefix...

  • Page 22: Keyboard Country Layout

    Keyboard Country Layout Scan the appropriate country code below to program the keyboard layout for your country or language. As a general rule, the following characters are sup- ported, but need special care for countries other than the United States: @ | $ # { } [ ] = / ‘...
  • Page 23 Keyboard Country (continued) Brazil (MS) Bulgaria (Cyrillic) Bulgaria (Latin) Canada (French legacy) Canada (French) Canada (Multilingual) Croatia Czech Czech (Programmers) Czech (QWERTY) Czech (QWERTZ) Denmark Dutch (Netherlands) 2 - 5...
  • Page 24 Keyboard Country (continued) Estonia Faeroese Finland France Gaelic Germany Greek Greek (220 Latin) Greek (220) Greek (319 Latin) Greek (319) Greek (Latin) Greek (MS) 2 - 6...
  • Page 25 Keyboard Country (continued) Greek (Polytonic) Hebrew Hungarian (101 key) Hungary Iceland Irish Italian (142) Italy Japan ASCII Kazakh Kyrgyz (Cyrillic) Latin America Latvia 2 - 7...
  • Page 26 Keyboard Country (continued) Latvia (QWERTY) Lithuania Lithuania (IBM) Macedonia Malta Mongolian (Cyrillic) Norway Poland Polish (214) Polish (Programmers) Portugal Romania Russia 2 - 8...
  • Page 27 Keyboard Country (continued) Russian (MS) Russian (Typewriter) Serbia (Cyrillic) Serbia (Latin) Slovakia Slovakia (QWERTY) Slovakia (QWERTZ) Slovenia Spain Spanish variation Sweden Switzerland (French) 2 - 9...

  • Page 28: Keyboard Style

    Keyboard Country (continued) Switzerland (German) Tatar Turkey F Turkey Q Ukrainian United Kingdom United Stated (Dvorak right) United States (Dvorak left) United States (Dvorak) United States (International) Uzbek (Cyrillic) Keyboard Style This programs keyboard styles, such as Caps Lock and Shift Lock. If you have used Keyboard Conversion settings, they will override any of the following Key-...
  • Page 29 Regular is used when you normally have the Caps Lock key off. * Regular Caps Lock is used when you normally have the Caps Lock key on. Caps Lock Shift Lock is used when you normally have the Shift Lock key on (not common to U.S.

  • Page 30: Keyboard Conversion

    Emulate External Keyboard should be scanned if you do not have an external keyboard (IBM AT or equivalent). Emulate External Keyboard Note: After scanning the Emulate External Keyboard bar code, you must power cycle your computer. Keyboard Conversion Alphabetic keyboard characters can be forced to be all upper case or all lower- case.

  • Page 31: Keyboard Modifiers

    Default = Off. Control Character Output On * Control Character Output Off Keyboard Modifiers This modifies special keyboard features, such as CTRL+ ASCII codes and Turbo Mode. Control + ASCII Mode On: The engine sends key combinations for ASCII con- trol characters for values 00-1F.
  • Page 32 Turbo Mode: The engine sends characters to a terminal faster. If the terminal drops characters, do not use Turbo Mode. Default = Off Turbo Mode On * Turbo Mode Off Numeric Keypad Mode: Sends numeric characters as if entered from a numeric keypad.

  • Page 33: Rs232 Baud Rate

    RS232 Baud Rate Baud Rate sends the data from the engine to the terminal at the specified rate. The host terminal must be set for the same baud rate as the engine. Default = 9600. 1200 2400 4800 * 9600 19200 38400 57,600...

  • Page 34: Rs232 Word Length: Data Bits, Stop Bits, And Parity

    RS232 Word Length: Data Bits, Stop Bits, and Parity Data Bits sets the word length at 7 or 8 bits of data per character. If an applica- tion requires only ASCII Hex characters 0 through 7F decimal (text, digits, and punctuation), select 7 data bits.

  • Page 35: Rs232 Receiver Time-Out

    RS232 Receiver Time-Out The unit stays awake to receive data until the RS232 Receiver Time-Out expires. A manual or serial trigger resets the time-out. When an RS232 receiver is sleeping, a character may be sent to wake up the receiver and reset the time-out.

  • Page 36: Rs232 Timeout

    RS232 Timeout When using Flow Control with Timeout, you must program the length of the delay you want to wait for CTS from the host. Set the length (in millisec- onds) for a timeout by scanning the bar code below, then setting the time- out (from 1-5100 milliseconds) by scanning digits from the inside back cover, then scanning Save.
  • Page 37 the engine waits for ACK/NAK again. Turn on the ACK/NAK protocol by scanning the ACK/NAK On bar code below. To turn off the protocol, scan ACK/NAK Off. Default = ACK/NAK Off . ACK/NAK On * ACK/NAK Off 2 - 19...
  • Page 38 2 - 20...

  • Page 39: Power Up Beeper

    Input/Output Settings Power Up Beeper The engine can be programmed to beep when it’s powered up. If you are using a cordless system, the base can also be programmed to beep when it is pow- ered up. Scan the Off bar code(s) if you don’t want a power up beep. Default = Power Up Beeper On - Scanner.

  • Page 40: Trigger Click

    Trigger Click To hear an audible click every time the trigger is pressed, scan the Trigger Click On bar code below. Scan the Trigger Click Off code if you don’t wish to hear the click. (This feature has no effect on serial or automatic triggering.) Default = Trigger Click Off.

  • Page 41: Beeper Volume - Good Read

    Beeper Volume – Good Read The beeper volume codes modify the volume of the beep the engine emits on a good read. Default = High. Medium * High Beeper Pitch – Good Read The beeper pitch codes modify the pitch (frequency) of the beep the engine emits on a good read.

  • Page 42: Beeper Pitch - Error

    Beeper Pitch – Error The beeper pitch codes modify the pitch (frequency) of the sound the engine emits when there is a bad read or error. Default = Razz. * Razz (250 Hz) Medium (3250 Hz) High (4200 Hz) Beeper Duration – Good Read The beeper duration codes modify the length of the beep the engine emits on a good read.

  • Page 43: Number Of Beeps - Good Read

    Number of Beeps – Good Read The number of beeps of a good read can be programmed from 1 - 9. The same number of beeps will be applied to the beeper and LED in response to a good read. For example, if you program this option to have five beeps, there will be five beeps and five LED flashes in response to a good read.

  • Page 44: Good Read Delay

    Good Read Delay This sets the minimum amount of time before the engine can read another bar code. Default = 0 ms (No Delay). * No Delay Short Delay (500 ms) Medium Delay (1,000 ms) Long Delay (1,500 ms) User-Specified Good Read Delay If you want to set your own length for the good read delay, scan the bar code below, then set the delay (from 0-30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save.

  • Page 45: Serial Trigger Mode

    slightly less range than Normal mode. Enhanced mode is best used when you require a very fast scan speed and don’t require a long working range. Default = Manual Trigger-Normal. * Manual Trigger - Normal Manual Trigger - Enhanced Serial Trigger Mode You can activate the scanner either by pressing the trigger, or using a serial trig- ger command (see Trigger Commands...

  • Page 46: Image Snap And Ship

    Image Snap and Ship Image Snap and Ship tells the engine to take a picture (rather than read a bar code) when the trigger is pressed. Once the picture is snapped, it is shipped to the host system as a jpeg file by default. To revert to bar code reading, you must change to a different trigger mode (see Manual Trigger Modes beginning...

  • Page 47: User-Specified Reread Delay

    User-Specified Reread Delay If you want to set your own length for the reread delay, scan the bar code below, then set the delay (from 0-30,000 milliseconds) by scanning digits from the inside back cover, then scanning Save. User-Specified Reread Delay Illumination Lights If you want the illumination lights on while reading a bar code, scan the Lights On bar code, below.
  • Page 48 The default centering window is a 169x128 pixel area in the center of the engine’s field of view. The following diagram illustrates the default top, bottom, left, and right pixel positions, measured from the top and the left side of the engine’s field of view, which is 844 by 640 pixels.

  • Page 49: Preferred Symbology

    Preferred Symbology The engine can be programmed to specify one symbology as a higher priority over other symbologies in situations where both bar code symbologies appear on the same label, but the lower priority symbology cannot be disabled. For example, you may be using the engine in a retail setting to read U.P.C. sym- bols, but have occasional need to read a code on a drivers license.

  • Page 50: Low Priority Symbology

    Low Priority Symbology To specify the low priority symbology, scan the Low Priority Symbology bar code below. On the Symbology Chart on page A-1, find the symbology you want to set as low priority. Locate the Hex value for that symbology and scan the 2 digit hex value from the Programming Chart (inside back cover).

  • Page 51: Output Sequence Overview

    Output Sequence Overview Require Output Sequence When turned off, the bar code data will be output to the host as the engine decodes it. When turned on, all output data must conform to an edited sequence or the engine will not transmit the output data to the host device. Note: This selection is unavailable when the Multiple Symbols Selection is turned on.

  • Page 52: Other Programming Selections

    5. End Output Sequence Editor Scan F F to enter an Output Sequence for an additional symbology, or Save to save your entries. Other Programming Selections • Discard This exits without saving any Output Sequence changes. Output Sequence Example In this example, you are scanning Code 93, Code 128, and Code 39 bar codes, but you want the engine to output Code 39 1st, Code 128 2nd, and Code 93 3rd, as shown below.

  • Page 53: Output Sequence Editor

    termination string for third code To program the previous example using specific lengths, you would have to count any programmed prefixes, suffixes, or formatted characters as part of the length. If you use the example on page 3-14, but assume a <CR> suffix and specific code lengths, you would use the following command line: SEQBLK62001241FF6A001342FF69001243FF The breakdown of the command line is shown below:...

  • Page 54: Require Output Sequence

    Scan Discard Partial Sequence to discard partial sequences when the output sequence operation is terminated before completion. Scan Trans- mit Partial Sequence to transmit partial sequences. (Any fields in the sequence where no data match occurred will be skipped in the output.) Transmit Partial Sequence * Discard Partial Sequence Require Output Sequence...

  • Page 55: No Read

    for each read. The engine attempts to find and decode new symbols as long as the trigger is pulled. When this programming selection is turned Off, the engine will only read the symbol closest to the center of the image. Default = Off. * Off No Read With No Read turned On, the engine notifies you if a code cannot be read.

  • Page 56: Video Reverse

    Video Reverse Video Reverse is used to allow the engine to read bar codes that are inverted. The Video Reverse Off bar code below is an example of this type of bar code. Scan Video Reverse Only to read only inverted bar codes. Scan Video Reverse and Standard Bar Codes to read both types of codes.

  • Page 57: Chapter 4 - Data Editing

    Data Editing Prefix/Suffix Overview When a bar code is scanned, additional information is sent to the host computer along with the bar code data. This group of bar code data and additional, user-defined data is called a “message string.” The selections in this section are used to build the user-defined data into the message string.

  • Page 58: To Clear One Or All Prefixes Or Suffixes

    symbology to which you want to apply the prefix or suffix. For example, for Code 128, Code ID is “j” and Hex ID is “6A”. Step 3. Scan the 2 hex digits from the Programming Chart inside the back cover of this manual or scan 9, 9 for all symbologies. Step 4.

  • Page 59: To Add A Carriage Return Suffix To All Symbologies

    Step 1. Scan the Clear One Prefix or Clear One Suffix symbol. Step 2. Determine the 2 digit Hex value from the Symbology Chart (included in the Symbology Chart, beginning on page A-1) for the symbology from which you want to clear the prefix or suffix. Step 3.

  • Page 60: Suffix Selections

    Suffix Selections Add Suffix Clear One Suffix Clear All Suffixes Function Code Transmit When this selection is enabled and function codes are contained within the scanned data, the engine transmits the function code to the terminal. Charts of these function codes are provided in Supported Interface Keys starting on page...

  • Page 61: Intercharacter Delay

    Intercharacter Delay An intercharacter delay of up to 5000 milliseconds (in 5ms increments) may be placed between the transmission of each character of scanned data. Scan the Intercharacter Delay bar code below, then scan the number of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.

  • Page 62: Interfunction Delay

    Interfunction Delay An interfunction delay of up to 5000 milliseconds (in 5ms increments) may be placed between the transmission of each segment of the message string. Scan the Interfunction Delay bar code below, then scan the num- ber of 5ms delays, and the Save bar code using the Programming Chart inside the back cover of this manual.

  • Page 63: Chapter 5 - Data Formatting

    Data Formatting Data Format Editor Introduction You may use the Data Format Editor to change the engine’s output. For exam- ple, you can use the Data Format Editor to insert characters at certain points in bar code data as it is scanned. The selections in the following pages are used only if you wish to alter the output.
  • Page 64 you are programming. (See Primary/Alternate Data Formats on page 5-10 for further information.) Step 3. Terminal Type Refer to Terminal ID Table (page 5-4) and locate the Terminal ID number for your PC. Scan three numeric bar codes on the inside back cover to program the engine for your terminal ID (you must enter 3 digits).

  • Page 65: Other Programming Selections

    Other Programming Selections Clear One Data Format This deletes one data format for one symbology. If you are clearing the primary format, scan 0 from the Programming Chart inside the back cover of this manual. If you are clearing an alternate format, scan 1, 2, or 3, depending on the format you are clearing.

  • Page 66: Terminal Id Table

    Discard to exit without saving any data format changes. Clear One Data Format Clear All Data Formats Save Discard Terminal ID Table Terminal Interface Description RS232 COM Port Emulation PC Keyboard Data Format Editor Commands Send Commands Send all characters F1 Include in the output message all of the characters from the input message, starting from current cursor position, followed by an insert character.

  • Page 67: Move Commands

    1252), page A-4 for decimal, hex and character codes. Insert symbology name B3 Insert the name of the bar code’s symbology in the output message, without moving the cursor. Only symbologies with a Honeywell ID are included (see Symbology Chart on page A-1).

  • Page 68: Search Commands

    Move the cursor to the beginning F7 Move the cursor to the first character in the input message. Syntax = Move the cursor to the end EA Move the cursor to the last character in the input message. Syntax = Search Commands Search forward for a character F8 Search the input message forward for “xx”...

  • Page 69: Miscellaneous Commands

    Search forward for a non-matching character E6 Search the input message forward for the first non-“xx” character from the current cursor position, leaving the cursor pointing to the non-“xx” character. Syntax = E6xx where xx stands for the search character’s hex value for its ASCII code.

  • Page 70: Data Formatter

    Compare characters FE Compare the character in the current cursor position to the character “xx.” If characters are equal, move the cursor forward one position. Syntax = FExx where xx stands for the comparison character’s hex value for its ASCII code. Refer to the ASCII Conversion Chart (Code Page 1252), page A-4 for...

  • Page 71: Data Format Non-Match Error Tone

    Data Formatter On, Not Required, Drop Prefix/Suffix Scanned data is modified according to your data format. If a data format is found for a particular symbol, those prefixes and suffixes are not transmitted. Data Format Required, Keep Prefix/Suffix Scanned data is modified according to your data format, and prefixes and suffixes are transmitted.

  • Page 72: Primary/Alternate Data Formats

    If you wish to hear the error tone when a non-matching bar code is found, scan the Data Format Non-Match Error Tone On bar code. Default = Data Format Non-Match Error Tone On . * Data Format Non-Match Error Tone On Data Format Non-Match Error Tone Off Primary/Alternate Data Formats...
  • Page 73 For example, you may have set your device to the data format you saved as Data Format 3. You can switch to Data Format 1 for a single trigger pull by scanning the Single Scan-Data Format 1 bar code below. The next bar code that is scanned uses Data Format 1, then reverts back to Data Format Single Scan-Primary Data Format...
  • Page 74 5 - 12...
  • Page 75 Symbologies This programming section contains the following menu selections. Refer to Chapter 10 for settings and defaults. • All Symbologies • Interleaved 2 of 5 • Aztec Code • Korea Post • China Post (Hong Kong 2 of 5) • Matrix 2 of 5 •...

  • Page 76: All Symbologies

    All Symbologies If you want to decode all the symbologies allowable for your engine, scan the All Symbologies On code. If on the other hand, you want to decode only a particular symbology, scan All Symbologies Off followed by the On symbol for that particular symbology.

  • Page 77: Codabar

    Codabar <Default All Codabar Settings> Codabar On/Off * On Codabar Start/Stop Characters Start/Stop characters identify the leading and trailing ends of the bar code. You may either transmit, or not transmit Start/Stop characters. Default = Don’t Transmit . Transmit * Don’t Transmit Codabar Check Character Codabar check characters are created using different “modulos.”...

  • Page 78: Codabar Concatenation

    When Check Character is set to Validate, but Don’t Transmit , the unit will only read Codabar bar codes printed with a check character, but will not transmit the check character with the scanned data. * No Check Character Validate Modulo 16, but Don’t Transmit Validate Modulo 16 and Transmit...
  • Page 79 Codabar Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 2-60. Minimum Default = 4, Maximum Default = 60. Minimum Message Length Maximum Message Length 6 - 5...

  • Page 80: Code 39

    Code 39 < Default All Code 39 Settings > Code 39 On/Off * On Code 39 Start/Stop Characters Start/Stop characters identify the leading and trailing ends of the bar code. You may either transmit, or not transmit Start/Stop characters. Default = Don’t Transmit.
  • Page 81 When Check Character is set to Validate and Transmit, the engine only reads Code 39 bar codes printed with a check character, and will transmit this character at the end of the scanned data. Default = No Check Charac- ter. * No Check Character Validate, but Don’t Transmit Validate and Transmit...

  • Page 82: Code 32 Pharmaceutical (Paraf)

    which the bar codes are read, deleting the first space from each. The engine transmits the appended data when it reads a Code 39 bar code that starts with a character other than a space. Default = Off. * Off Code 32 Pharmaceutical (PARAF) Code 32 Pharmaceutical is a form of the Code 39 symbology used by Ital- ian pharmacies.

  • Page 83: Full Ascii

    Full ASCII If Full ASCII Code 39 decoding is enabled, certain character pairs within the bar code symbol will be interpreted as a single character. For example: $V will be decoded as the ASCII character SYN, and /C will be decoded as the ASCII character #.

  • Page 84: Interleaved 2 Of 5

    and scan the value and the Save bar code from the Programming Chart the inside the back cover of this manual. The data characters should then appear properly. Code 39 Code Page Interleaved 2 of 5 < Default All Interleaved 2 of 5 Settings > Interleaved 2 of 5 On/Off * On Check Digit...
  • Page 85 When Check Digit is set to Validate and Transmit, the engine only reads Interleaved 2 of 5 bar codes printed with a check digit, and will transmit this digit at the end of the scanned data. Default = No Check Digit. * No Check Digit Validate, but Don’t Transmit Validate and Transmit...

  • Page 86: Nec 2 Of 5

    NEC 2 of 5 < Default All NEC 2 of 5 Settings > NEC 2 of 5 On/Off * On Check Digit No Check Digit indicates that the engine reads and transmits bar code data with or without a check digit. When Check Digit is set to Validate, but Don’t Transmit, the unit only reads NEC 2 of 5 bar codes printed with a check digit, but will not transmit the check digit with the scanned data.
  • Page 87 NEC 2 of 5 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 2-80. Minimum Default = 4, Maximum Default = 80. Minimum Message Length Maximum Message Length 6 - 13...

  • Page 88: Code 93

    Code 93 < Default All Code 93 Settings > Code 93 On/Off * On Code 93 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 0-80. Minimum Default = 0, Maximum Default = 80.

  • Page 89: Straight 2 Of 5 Industrial (Three-Bar Start/Stop)

    and scan the value and the Save bar code from the Programming Chart the inside the back cover of this manual. The data characters should then appear properly. Code 93 Code Page Straight 2 of 5 Industrial (three-bar start/stop) <Default All Straight 2 of 5 Industrial Settings> Straight 2 of 5 Industrial On/Off * Off Straight 2 of 5 Industrial Message Length...

  • Page 90: Straight 2 Of 5 Iata (Two-Bar Start/Stop)

    Straight 2 of 5 IATA (two-bar start/stop) <Default All Straight 2 of 5 IATA Settings> Straight 2 of 5 IATA On/Off * Off Straight 2 of 5 IATA Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information.

  • Page 91: Matrix 2 Of 5

    Matrix 2 of 5 <Default All Matrix 2 of 5 Settings> Matrix 2 of 5 On/Off * Off Matrix 2 of 5 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-80.

  • Page 92: Code 11

    Code 11 <Default All Code 11 Settings> Code 11 On/Off * Off Check Digits Required This option sets whether 1 or 2 check digits are required with Code 11 bar codes. Default = Two Check Digits. One Check Digit * Two Check Digits 6 - 18...

  • Page 93: Code 128

    Code 11 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-80. Minimum Default = 4, Maximum Default = 80. Minimum Message Length Maximum Message Length Code 128 <Default All Code 128 Settings>...
  • Page 94 that supports concatenation of neighboring symbols, and 4) the standard layout for bar codes on a blood product label. Use the bar codes below to turn concatenation on or off. Default =Off. * Off Code 128 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information.

  • Page 95: Code 128 Code Page

    Code 128 Code Page Code pages define the mapping of character codes to characters. If the data received does not display with the proper characters, it may be because the bar code being scanned was created using a code page that is different from the one the host program is expecting.

  • Page 96: Gs1-128

    GS1-128 <Default All GS1-128 Settings> GS1-128 On/Off * On GS1-128 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-80. Minimum Default = 1, Maximum Default = 80.

  • Page 97: Telepen

    Telepen <Default All Telepen Settings> Telepen On/Off * Off Telepen Output Using AIM Telepen Output, the engine reads symbols with start/stop pat- tern 1 and decodes them as standard full ASCII (start/stop pattern 1). When Original Telepen Output is selected, the engine reads symbols with start/stop pattern 1 and decodes them as compressed numeric with optional full ASCII (start/stop pattern 2).

  • Page 98: Upc-A

    Telepen Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-60. Minimum Default = 1, Maximum Default = 60. Minimum Message Length Maximum Message Length UPC-A <Default All UPC-A Settings>...
  • Page 99 UPC-A Number System The numeric system digit of a U.P.C. symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will not transmit it. Default = On. * On UPC-A Addenda This selection adds 2 or 5 digits to the end of all scanned UPC-A data.

  • Page 100: Upc-A/Ean-13

    UPC-A Addenda Separator When this feature is on, there is a space between the data from the bar code and the data from the addenda. When turned off, there is no space. Default = On. * On UPC-A/EAN-13 with Extended Coupon Code Use the following codes to enable or disable UPC-A and EAN-13 with Extended Coupon Code.

  • Page 101: Upc-E0

    UPC-E0 <Default All UPC-E Settings> UPC-E0 On/Off Most U.P.C. bar codes lead with the 0 number system. To read these codes, use the UPC-E0 On selection. If you need to read codes that lead with the 1 number system, use UPC-E1 (page 6-30).
  • Page 102 UPC-E0 Addenda Required When Required is scanned, the engine will only read UPC-E bar codes that have addenda. Default = Not Required. Required * Not Required UPC-E0 Addenda Separator When this feature is On, there is a space between the data from the bar code and the data from the addenda.
  • Page 103 UPC-E0 Number System The numeric system digit of a U.P.C. symbol is normally transmitted at the beginning of the scanned data, but the unit can be programmed so it will not transmit it. To prevent transmission, scan Off. Default = On. * On UPC-E0 Addenda This selection adds 2 or 5 digits to the end of all scanned UPC-E data.

  • Page 104: Upc-E1

    UPC-E1 Most U.P.C. bar codes lead with the 0 number system. For these codes, use UPC-E0 (page 6-27). If you need to read codes that lead with the 1 number system, use the UPC-E1 On selection. Default = Off. UPC-E1 On * UPC-E1 Off EAN/JAN-13 <Default All EAN/JAN Settings>...
  • Page 105 EAN/JAN-13 Addenda This selection adds 2 or 5 digits to the end of all scanned EAN/JAN-13 data. Default = Off for both 2 Digit and 5 Digit Addenda. 2 Digit Addenda On * 2 Digit Addenda Off 5 Digit Addenda On * 5 Digit Addenda Off EAN/JAN-13 Addenda Required When Required is scanned, the engine will only read EAN/JAN-13 bar...

  • Page 106: Isbn Translate

    EAN/JAN-13 Addenda Separator When this feature is On, there is a space between the data from the bar code and the data from the addenda. When turned Off, there is no space. Default = On. * On Note: If you want to enable or disable EAN13 with Extended Coupon Code, refer to UPC-A/EAN-13 with Extended Coupon Code (page 6-26).

  • Page 107: Ean/Jan-8

    EAN/JAN-8 <Default All EAN/JAN-8 Settings> EAN/JAN-8 On/Off * On EAN/JAN-8 Check Digit This selection allows you to specify whether the check digit should be transmitted at the end of the scanned data or not. Default = On. * On 6 - 33...
  • Page 108 EAN/JAN-8 Addenda This selection adds 2 or 5 digits to the end of all scanned EAN/JAN-8 data. Default = Off for both 2 Digit and 5 Digit Addenda. 2 Digit Addenda On * 2 Digit Addenda Off 5 Digit Addenda On * 5 Digit Addenda Off EAN/JAN-8 Addenda Required When Required is scanned, the engine will only read EAN/JAN-8 bar...

  • Page 109: Msi

    <Default All MSI Settings> MSI On/Off * Off MSI Check Character Different types of check characters are used with MSI bar codes. You can program the engine to read MSI bar codes with Type 10 check characters. Default = Validate Type 10, but Don’t Transmit. When Check Character is set to Validate Type 10/11 and Transmit, the engine will only read MSI bar codes printed with the specified type check character(s), and will transmit the character(s) at the end of the scanned...
  • Page 110 When Check Character is set to Validate Type 10/11, but Don’t Transmit, the unit will only read MSI bar codes printed with the specified type check character(s), but will not transmit the check character(s) with the scanned data. * Validate Type 10, but Don’t Transmit Validate Type 10 and Transmit Validate 2 Type 10 Characters,...

  • Page 111: Gs1 Databar Omnidirectional

    GS1 DataBar Omnidirectional < Default All GS1 DataBar Omnidirectional Settings > GS1 DataBar Omnidirectional On/Off * On GS1 DataBar Limited < Default All GS1 DataBar Limited Settings > GS1 DataBar Limited On/Off * On 6 - 37...

  • Page 112: Gs1 Databar Expanded

    GS1 DataBar Expanded < Default All GS1 DataBar Expanded Settings > GS1 DataBar Expanded On/Off * On GS1 DataBar Expanded Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 4-74.

  • Page 113: Trioptic Code

    Trioptic Code Note: If you are going to scan Code 32 Pharmaceutical codes (page 6-8), Trioptic Code must be off. Trioptic Code is used for labeling magnetic storage media. * Off Codablock A <Default All Codablock A Settings> Codablock A On/Off * Off 6 - 39...
  • Page 114 Codablock A Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-600. Minimum Default = 1, Maximum Default = 600. Minimum Message Length Maximum Message Length 6 - 40...

  • Page 115: Codablock F

    Codablock F <Default All Codablock F Settings> Codablock F On/Off * Off Codablock F Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-2048. Minimum Default = 1, Maximum Default = 2048.

  • Page 116: Pdf417

    PDF417 < Default All PDF417 Settings > PDF417 On/Off * On PDF417 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-2750. Minimum Default = 1, Maximum Default = 2750.

  • Page 117: Micropdf417

    MicroPDF417 < Default All MicroPDF417 Settings > MicroPDF417 On/Off * Off MicroPDF417 Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-366. Minimum Default = 1, Maximum Default = 366.

  • Page 118: Gs1 Composite Codes

    GS1 Composite Codes Linear codes are combined with a unique 2D composite component to form a new class called GS1 Composite symbology. GS1 Composite symbologies allow for the co-existence of symbologies already in use. * Off UPC/EAN Version Scan the UPC/EAN Version On bar code to decode GS1 Composite sym- bols that have a U.P.C.

  • Page 119: Gs1 Emulation

    GS1 Emulation The engine can automatically format the output from any GS1 data carrier to emulate what would be encoded in an equivalent GS1-128 or GS1 DataBar symbol. GS1 data carriers include UPC-A and UPC-E, EAN-13 and EAN-8, ITF-14, GS1-128, and GS1-128 DataBar and GS1 Composites. (Any applica- tion that accepts GS1 data can be simplified since it only needs to recognize one data carrier type.) If GS1-128 Emulation is scanned, all retail codes (U.P.C., UPC-E, EAN8,...

  • Page 120: Tcif Linked Code 39 (Tlc39)

    TCIF Linked Code 39 (TLC39) This code is a composite code since it has a Code 39 linear component and a MicroPDF417 stacked code component. All bar code readers are capable of reading the Code 39 linear component. The MicroPDF417 component can only be decoded if TLC39 On is selected.
  • Page 121 QR Code Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-7089. Minimum Default = 1, Maximum Default = 7089. Minimum Message Length Maximum Message Length QR Code Append This function allows the scanner to append the data from several QR Code...

  • Page 122: Data Matrix

    Data Matrix < Default All Data Matrix Settings > Data Matrix On/Off * On Data Matrix Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-3116. Minimum Default = 1, Maximum Default = 3116.

  • Page 123: Maxicode

    page A-6), and scan the value and the Save bar code from the Programming Chart on the inside the back cover of this manual. The data characters should then appear properly. Data Matrix Code Page MaxiCode < Default All MaxiCode Settings > MaxiCode On/Off *Off MaxiCode Message Length...

  • Page 124: Aztec Code

    Aztec Code < Default All Aztec Code Settings > Aztec Code On/Off * On Aztec Code Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Mini- mum and Maximum lengths = 1-3832. Minimum Default = 1, Maximum Default = 3832.

  • Page 125: Chinese Sensible (Han Xin) Code

    and scan the value and the Save bar code from the Programming Chart the inside the back cover of this manual. The data characters should then appear properly. Aztec Code Page Chinese Sensible (Han Xin) Code < Default All Han Xin Settings > Han Xin Code On/Off * Off Han Xin Code Message Length...

  • Page 126: Postal Codes - 2D

    Postal Codes - 2D The following lists the possible 2D postal codes, and 2D postal code combina- tions that are allowed. Only one 2D postal code selection can be active at a time. If you scan a second 2D postal code selection, the first selection is over- written.

  • Page 127: Combination 2D Postal Codes

    Postnet On Also see Postnet Check Digit, page 6-55. Postnet with B and B’ Fields On InfoMail On Combination 2D Postal Codes: InfoMail and British Post On Intelligent Mail Bar Code and Postnet with B and B’ Fields On Postnet and Postal-4i On Postnet and Intelligent Mail Bar Code On...
  • Page 128 Planet Code and Postal-4i On Planet Code and Intelligent Mail Bar Code On Planet Code, Postnet, and Postal-4i On Planet Code, Postnet, and Intelligent Mail Bar Code On Planet Code, Postal-4i, and Intelligent Mail Bar Code On Postnet, Postal-4i, and Intelligent Mail Bar Code On Planet Code, Postal-4i, and...

  • Page 129: Postal Codes - Linear

    Planet Code Check Digit This selection allows you to specify whether the check digit should be transmitted at the end of Planet Code data. Default = Don’t Transmit. Transmit Check Digit * Don’t Transmit Check Digit Postnet Check Digit This selection allows you to specify whether the check digit should be transmitted at the end of Postnet data.
  • Page 130 China Post (Hong Kong 2 of 5) On/Off * Off China Post (Hong Kong 2 of 5) Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maxi- mum Default = 80.

  • Page 131: Korea Post

    Korea Post <Default All Korea Post Settings> Korea Post * Off Korea Post Message Length Scan the bar codes below to change the message length. Refer to Message Length Description (page 6-2) for additional information. Minimum and Maximum lengths = 2-80. Minimum Default = 4, Maxi- mum Default = 48.
  • Page 132 6 - 58...

  • Page 133: Chapter 7 - Imaging Commands

    Imaging Commands The engine is like a digital camera in the way it captures, manipulates, and transfers images. The following commands allow you to alter the way the engine performs these functions. Single-Use Basis Imaging Commands with their modifiers send instructions to the engine on a single-use basis, and take effect for a single image capture.

  • Page 134: Image Snap - Imgsnp

    Step 1 - Take a Picture Using IMGSNP Image Snap - IMGSNP An image is taken whenever the hardware button is pressed, or when the Image Snap (IMGSNP) command is processed. The image snap command has many different modifiers that can be used to change the look of the image in memory.
  • Page 135 E - Exposure Exposure is used in Manual Style only (2P), and allows you to set the expo- sure time. This is similar to setting a shutter speed on a camera. The exposure time determines how long the engine takes to record an image. On a bright day, exposure times can be very short because plenty of light is available to help record an image.
  • Page 136 W - Target White Value Sets the target for the median grayscale value in the captured image. For capturing close-up images of high contrast documents, a lower setting, such as 75, is recommended. Higher settings result in longer exposure times and brighter images, but if the setting is too high, the image may be overexposed.

  • Page 137: Image Ship - Imgshp

    Step 2 - Ship a Picture Using IMGSHP Image Ship - IMGSHP An image is taken whenever the button is pressed, or when the Image Snap (IMGSNP) command is processed. The last image is always stored in memory. You can “ship” the image by using the IMGSHP command. The image ship commands have many different modifiers that can be used to change the look of the image output.
  • Page 138 C - Compensation Flattens the image to account for variations in illumination across the image. 0C Compensation disabled (default) 1C Compensation enabled Example of Compensation at 0C: Example of Compensation at 1C: D - Pixel Depth Indicates the number of bits per pixel in the transmitted image (KIM or BMP format only).
  • Page 139 E - Edge Sharpen An edge sharpen filter cleans up the edges of an image, making it look cleaner and sharper. While edge sharpening does make the image look cleaner, it also removes some fine detail from the original image. The strength of the edge sharpen filter can be entered from 1 to 24.
  • Page 140 H - Histogram Stretch Increases the contrast of the transmitted image. Not available with some image formats. 0H No stretch (default) 1H Histogram stretch Example of Histogram Stretch at 0H: Example of Histogram Stretch at 1H: I - Invert Image Invert image is used to rotate the image around the X or Y axis.
  • Page 141 IF- Noise Reduction Used to reduce the salt and pepper noise in an image. 0if No salt and pepper noise reduction (default) 1if Salt and pepper noise reduction Example of Noise Reduction Off (0if): Example of Noise Reduction On (1if): IR - Image Rotate 0ir Image as snapped (rightside up) (default) 1ir Rotate image 90 degrees to the right...
  • Page 142 J - JPEG Image Quality Sets the desired quality when the JPEG image format is selected. Higher numbers result in higher quality, but larger files. Smaller numbers result in greater amounts of lossy compression, faster transmission times, lower quality, but smaller files. (Default = 50) n J Image is compressed as much as possible while preserving quality factor of n ( n = 0 - 100) 0J worst quality (smallest file)
  • Page 143 n B The bottom edge of the shipped image corresponds to row n - 1 of the image in memory. Range: 000 - 480. (Default = all rows) Uncropped Image: Example of Image Crop Example of Image set to 300R: Crop set to 300L: Example of Image Crop set to 200B: Example of Image Crop set to 200T:...
  • Page 144 1S ship every pixel (default) 2S ship every 2nd pixel, both horizontally and vertically 3S ship every 3rd pixel, both horizontally and vertically Example of Pixel Example of Pixel Example of Pixel Ship set to 1S: Ship set to 2S: Ship set to 3S: U - Document Image Filter Allows you to input parameters to sharpen the edges and smooth the area...
  • Page 145 V - Blur Image Smooths transitions by averaging the pixels next to the hard edges of defined lines and shaded areas in an image. 0V Don’t blur (default) 1V Blur Example of Blur Image Off (0V): Example of Blur Image On (1V): W - Histogram Ship A histogram gives a quick picture of the tonal range of an image, or key type.

  • Page 146: Intelligent Signature Capture - Imgbox

    Image Size Compatibility If you have applications that expect an image ship to return exactly 640x480 pixels, scan the Force VGA Resolution bar code. Default = Native Resolution Force VGA Resolution * Native Resolution Intelligent Signature Capture - IMGBOX IMGBOX allows you to configure the size and location of a signature capture area relative to its proximity to a bar code.

  • Page 147: Imgbox Modifiers

    The following IMGBOX example was executed and viewed using QuickView software. This software is available at www.honeywellaidc.com. Click on Soft- ware Downloads. Select 4600r from the Products list, then select QuickView Software Utility. Below is an example of a signature capture application. In this example, the signature capture area should be centered in the image when the trigger is pressed.
  • Page 148 This option is used to size the image horizontally. If using this option, set the resolution (R) to zero. Example of Image Width set to 200A: Example of Image Width set to 600A: B - Output Image Height This option is used to size the image vertically. If using this option, set the resolution (R) to zero.
  • Page 149 8F BMP format H - Height of Signature Capture Area The height of the signature capture area must be measured in inches divided by .01. In the example, the height of the area to be captured is 3/8 inch, resulting in a value of H = .375/0.01 = 37.5. Example: IMGBOX245w37h55y.
  • Page 150 For example, use 2500 to specify a resolution of 2.5. Set to zero when using the A and B modifiers (see A - Output Image Width B - Output Image Height on page 7-16). Example of Resolution set to 0R: Example of Resolution set to 1000R: Example of Resolution set to 2000R: S - Bar Code Aspect Ratio...
  • Page 151 Y - Vertical Bar Code Offset The vertical bar code offset allows you to offset the vertical center of the signature capture area. Negative numbers indicate that the signature cap- ture is above the bar code, and positive numbers indicate that the area is below the bar code.
  • Page 152 7 - 20...

  • Page 153: Chapter 8 - Interface Keys

    Interface Keys Keyboard Function Relationships The following Keyboard Function Code, Hex/ASCII Value, and Full ASCII “CTRL”+ relationships apply to all terminals that can be used with the engine. Refer to page 2-13 enable Control + ASCII mode. Function Code HEX/ASCII Value Full ASCII “CTRL”...

  • Page 154: Supported Interface Keys

    The last five characters in the Full ASCII “CTRL”+ column ( [ \ ] 6 - ), apply to US only. The following chart indicates the equivalents of these five characters for different countries. Country Codes United States Belgium < Scandinavia <...
  • Page 155 IBM AT/XT and IBM XTs and IBM, DDC, PS/2 Compatibles Memorex Telex, ASCII Compatibles, Supported Harris* WYSE PC/AT Keys Supported Keys Supported Keys Insert Insert Insert Escape Escape Reserved Error Reset Home Home Home Print Print Back Space Back Space Back Space Back Tab Back Tab...
  • Page 156 IBM, Memorex Telex Memorex Telex (88)** (102)* ASCII Supported Keys Supported Keys Field Forward Reserved Tab/Field Forward Field Forward Delete Delete Field Exit New Line Insert Insert Clear Erase Error Reset Error Reset Home Reserved Print Print Back Space Back Space Back Tab Back Field Reserved...
  • Page 157 Esprit 200, 400 Esprit 200, 400 Esprit 200, 400 ANSI ASCII ASCII Supported Supported Supported Keys Keys Keys New Line New Line New Line Delete New Line New Line New Line Insert Escape Escape Escape Insert Insert Home Print Back Space Back Space Back Space Back Tab...
  • Page 158 Apple Mac/iMac ASCII Supported Keys CAPS ALT make ALT break CNTRL make CNTRL break RETURN APPLE make APPLE break RETURN Ins Help Home Prnt Scrn BACKSPACE LSHIFT TAB BACKSPACE 8 - 6...

  • Page 159: Chapter 9 - Utilities

    Utilities To Add a Test Code I.D. Prefix to All Symbologies This selection allows you to turn on transmission of a Code I.D. before the decoded symbology. (See the Symbology Chart, beginning on page A-1) for the single character code that identifies each symbology.) This action first clears all current prefixes, then programs a Code I.D.

  • Page 160: Show Data Format

    Show Data Format Scan the bar code below to show current data format settings. DFMBK3?. Data Format Settings Test Menu When you scan the Test Menu On code, then scan a programming code in this manual, the engine displays the content of a programming code. The program- ming function will still occur, but in addition, the content of that programming code is output to the terminal.

  • Page 161: Application Plug-Ins (Apps)

    Application Plug-Ins (Apps) Any apps that you are using can be turned off or on by scanning the following bar codes. Apps are stored in groups: Decoding and Formatting. You can enable and disable these groups of apps by scanning that group’s On or Off bar code below.

  • Page 162: Installing Ezconfig From The Web

    Note: EZConfig requires .NET software. If .NET is not installed on your PC, you will be prompted to install it during the EZConfig installation. 1. Access the Honeywell web site at www.honeywellaidc.com 2. Click on the Resources tab. Select Product Downloads-Software.

  • Page 163: Chapter 10 - Serial Programming Commands

    Serial Programming Commands The serial programming commands can be used in place of the programming bar codes. Both the serial commands and the programming bar codes will pro- gram the engine. For complete descriptions and examples of each serial pro- gramming command, refer to the corresponding programming bar code in this manual.

  • Page 164: Query Commands

    Query Commands Several special characters can be used to query the device about its settings. What is the default value for the setting(s). What is the device’s current value for the setting(s). What is the range of possible values for the setting(s). (The device’s response uses a dash (-) to indicate a continuous range of values.
  • Page 165 NAK Indicates the command was good, but the Data field entry was out of the allowable range for this Tag and SubTag combination, e.g., an entry for a minimum message length of 100 when the field will only accept 2 characters. When responding, the device echoes back the command sequence with the status character inserted directly before each of the punctuation marks (the period, exclamation point, comma, or semicolon) in the command.

  • Page 166: Trigger Commands

    the Minimum Message Length (MIN) is set to 2 characters; the Maximum Message Length (MAX) is set to 60 characters; and the Default setting (DFT) has no value. Trigger Commands You can activate and deactivate the engine with serial trigger commands. First, the engine must be put in Manual Trigger Mode by scanning a Manual Trigger Mode bar code (page...

  • Page 167: Menu Commands

    Menu Commands Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Product Default Settings Setting Custom Set Custom Defaults MNUCDF Defaults Save Custom MNUCDS Defaults Resetting the Activate Custom DEFALT Custom Defaults Defaults Resetting the Factory Remove Custom DEFOVR Defaults...
  • Page 168 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Program Keyboard *U.S.A. KBDCTY0 Country Albania KBDCTY35 Azeri (Cyrillic) KBDCTY81 Azeri (Latin) KBDCTY80 Belarus KBDCTY82 Belgium KBDCTY1 Bosnia KBDCTY33 Brazil KBDCTY16 Brazil (MS) KBDCTY59 Bulgaria (Cyrillic) KBDCTY52 Bulgaria (Latin) KBDCTY53 Canada (French...
  • Page 169 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Program Keyboard Czech KBDCTY40 Country (Programmers) Czech (QWERTY) KBDCTY39 Czech (QWERTZ) KBDCTY38 Denmark KBDCTY8 Dutch (Netherlands) KBDCTY11 Estonia KBDCTY41 Faeroese KBDCTY83 Finland KBDCTY2 France KBDCTY3 Gaelic KBDCTY84 Germany KBDCTY4 Greek...
  • Page 170 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Program Keyboard Latvia (QWERTY) KBDCTY43 Country Lithuania KBDCTY44 Lithuania (IBM) KBDCTY45 Macedonia KBDCTY34 Malta KBDCTY74 Mongolian (Cyrillic) KBDCTY86 Norway KBDCTY9 Poland KBDCTY20 Polish (214) KBDCTY57 Polish KBDCTY58 (Programmers) Portugal KBDCTY13...
  • Page 171 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Program Keyboard Ukrainian KBDCTY76 2-10 Country United Kingdom KBDCTY7 2-10 United Stated KBDCTY89 2-10 (Dvorak right) United States KBDCTY88 2-10 (Dvorak left) United States KBDCTY87 2-10 (Dvorak) United States KBDCTY30 2-10...
  • Page 172 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Keyboard Modifiers *Control + ASCII Off KBDCAS0 2-13 DOS Mode Control KBDCAS1 2-13 + ASCII Windows Mode KBDCAS2 2-13 Control + ASCII Windows Mode KBDCAS3 2-13 Prefix/Suffix Off *Turbo Mode Off KBDTMD0 2-14...
  • Page 173 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry 2-16 Word Length: Data 7 Data, 1 Stop, 232WRD3 Bits, Stop Bits, and Parity Even Parity 7 Data, 1 Stop, 232WRD0 2-16 Parity None 7 Data, 1 Stop, 232WRD6 2-16 Parity Odd...
  • Page 174 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Input/Output Selections Power Up Beeper Power Up Beeper BEPPWR0 Off - Scanner *Power Up Beeper BEPPWR1 On - Scanner Beep on BEL Beep on BEL On BELBEP1 Character *Beep on BEL Off BELBEP0...
  • Page 175 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Good Read Delay *No Delay DLYGRD0 Short Delay (500 DLYGRD500 Medium Delay (1000 DLYGRD1000 Long Delay (1500 DLYGRD1500 User-Specified Good Range 0 - 30,000 DLYGRD##### Read Delay Manual Trigger *Manual Trigger - PAPHHF...
  • Page 176 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Centering Window Centering On DECWIN1 3-10 *Centering Off DECWIN0 3-10 Left of Centering DECLFT### 3-10 Window (*40%) Right of Centering DECRGT### 3-10 Window (*60%) Top of Centering DECTOP### 3-10 Window (*40%)
  • Page 177 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry No Read SHWNRD1 3-17 *Off SHWNRD0 3-17 Video Reverse Video Reverse Only VIDREV1 3-18 Video Reverse and VIDREV2 3-18 Standard Bar Codes *Video Reverse Off VIDREV0 3-18 Prefix/Suffix Selections Add CR Suffix to All Symbologies VSUFCR...
  • Page 178 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Data Formatter Selections Data Format Editor *Default Data DFMDF3 Format (None) Enter Data Format DFMBK3## Clear One Data DFMCL3 Format Clear All Data DFMCA3 Formats Data Formatter Data Formatter Off DFM_EN0 *Data Formatter On,...
  • Page 179 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Single Scan Data Single Scan-Primary VSAF_0 5-11 Format Change Data Format Single Scan-Data VSAF_1 5-11 Format 1 Single Scan-Data VSAF_2 5-11 Format 2 Single Scan-Data VSAF_3 5-11 Format 3 Symbologies All Symbologies...
  • Page 180 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Code 39 Start/Stop *Don’t Transmit C39SSX0 Char. Transmit C39SSX1 Code 39 Check Char. *No Check Char. C39CK20 Validate, But Don’t C39CK21 Transmit Validate, C39CK22 and Transmit Code 39 Message Minimum (0 - 48) *0 C39MIN## Length...
  • Page 181 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry NEC 2 of 5 Default All NEC N25DFT 6-12 2 of 5 Settings N25ENA0 6-12 N25ENA1 6-12 NEC 2 of 5 Check *No Check Char. N25CK20 6-12 Digit Validate, But Don’t N25CK21...
  • Page 182 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Straight 2 of 5 IATA Minimum (1 - 48) *4 A25MIN## 6-16 Message Length Maximum (1 - 48) A25MAX## 6-16 Matrix 2 of 5 Default All Matrix 2 X25DFT 6-17 of 5...
  • Page 183 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry GS1-128 Default All GS1-128 GS1DFT 6-22 Settings GS1ENA1 6-22 GS1ENA0 6-22 GS1-128 Message Minimum (1 - 80) *1 GS1MIN 6-22 Length Maximum (0 - 80) GS1MAX 6-22 Telepen Default All Telepen TELDFT...
  • Page 184 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry UPC-A/EAN-13 with *Off CPNENA0 6-26 Extended Coupon Allow Concatenation CPNENA1 6-26 Code Require CPNENA2 6-26 Concatenation UPC-E0 Default All UPC-E UPEDFT 6-27 Settings UPEEN00 6-27 UPEEN01 6-27 UPC-E0 Expand *Off UPEEXP0...
  • Page 185 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry EAN/JAN-13 2 Digit 2 Digit Addenda On E13AD21 6-31 Addenda *2 Digit Addenda Off E13AD20 6-31 5 Digit Addenda On E13AD51 6-31 *5 Digit Addenda Off E13AD50 6-31 EAN/JAN-13 *Not Required...
  • Page 186 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry MSI Check Character *Validate Type 10, MSICHK0 6-36 but Don’t Transmit Validate Type 10 and MSICHK1 6-36 Transmit Validate 2 Type 10 MSICHK2 6-36 Chars, but Don’t Transmit Validate 2 Type 10 MSICHK3...
  • Page 187 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry GS1 DataBar Default All GS1 RSEDFT 6-38 Expanded DataBar Expanded Settings RSEENA0 6-38 RSEENA1 6-38 GS1 DataBar Minimum (4 - 74) *4 RSEMIN## 6-38 Expanded Msg. Maximum (4 - 74) RSEMAX## 6-38 Length...
  • Page 188 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry PDF417 Msg. Length Minimum (1-2750) PDFMIN 6-42 Maximum (1-2750) PDFMAX 6-42 *2750 MicroPDF417 Default All Micro MPDDFT 6-43 PDF417 Settings MPDENA1 6-43 *Off MPDENA0 6-43 MicroPDF417 Msg. Minimum (1-366) *1 MPDMIN 6-43...
  • Page 189 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry QR Code Msg. Minimum (1-7089) QRCMIN 6-47 Length Maximum (1-7089) QRCMAX 6-47 *7089 QR Code Append QRCAPP1 6-47 QRCAPP0 6-47 Data Matrix Default All Data IDMDFT 6-48 Matrix Settings IDMENA1 6-48...
  • Page 190 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Chinese Sensible Default All Han Xin HX_DFT 6-51 (Han Xin) Code Code Settings HX_ENA1 6-51 *Off HX_ENA0 6-51 Chinese Sensible Minimum (1-7833) HX_MIN 6-51 (Han Xin) Code Msg. Length Maximum (1-7833) HX_MAX...
  • Page 191 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Combination 2D InfoMail and British POSTAL8 6-53 Postal Codes Post On Intelligent Mail Bar POSTAL20 6-53 Code and Postnet with B and B’ Fields Postnet and Postal- POSTAL14 6-53 4i On...
  • Page 192 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Combination 2D Postal-4i and POSTAL19 6-53 Postal Codes Postnet with B and (continued) B’ Fields On Planet and Postnet POSTAL12 6-53 Planet and Postnet POSTAL18 6-53 with B and B’ Fields Planet and Postal-4i POSTAL13 6-54...
  • Page 193 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Combination 2D Planet, Postal-4i, POSTAL28 6-54 Postal Codes Intelligent Mail Bar (continued) Code, and Postnet Planet, Postal-4i, POSTAL29 6-54 Intelligent Mail Bar Code, and Postnet with B and B’ Fields Planet Code Check Transmit PLNCKX1...
  • Page 194 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Imaging Default Commands Image Snap Default all Imaging IMGDFT Commands Imaging Style - SNPSTY0 Decoding *Imaging Style - SNPSTY1 Photo Imaging Style - SNPSTY2 Manual Beeper On SNPBEP1 *Beeper Off SNPBEP0...
  • Page 195 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Image Ship *Infinity Filter - Off IMGINF0 Infinity Filter - On IMGINF1 *Compensation Off IMGCOR0 Compensation On IMGCOR1 *Pixel Depth - 8 bits/ IMGBPP8 pixel (grayscale) Pixel Depth - 1 bit/ IMGBPP1 pixel (B&W) *Don’t Sharpen...
  • Page 196 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Image Ship Invert Image around IMGNVX1 (continued) X axis Invert Image around IMGNVY1 Y axis Rotate Image none IMGROT0 Rotate Image 90° IMGROT1 right Rotate Image 180° IMGROT2 right Rotate Image 90°...
  • Page 197 Serial Command Setting Selection Page # Indicates a numeric * Indicates default entry Image Ship Ship Every 2nd Pixel IMGSUB2 7-12 (continued) Ship Every 3rd Pixel IMGSUB3 7-12 *Document Image IMGUSH0 7-12 Filter Off Document Image IMGUSH### 7-12 Filter On (0-255) *Don’t Ship IMGHST0 7-13...
  • Page 198 10 - 36...

  • Page 199: Chapter 11 - Maintenance

    Inspecting Cords and Connectors Inspect the engine’s interface cable and connector for wear or other signs of damage. A badly worn cable or damaged connector may interfere with engine operation. Contact your Honeywell distributor for information about cable replacement. Troubleshooting The engine automatically performs self-tests whenever you turn it on.
  • Page 200 • The engine may not be programmed for the appropriate terminal interface. For example, you scan “12345” and the host displays “@es%.” Reprogram the engine with the correct Plug and Play or Terminal selection bar code. See Chapter 2 Chapter The engine may not be programmed to output your bar code data properly.

  • Page 201: Chapter 12 - Customer Support

    Material Authorization number (RMA #). You should do this prior to returning the product. Limited Warranty Honeywell International Inc. ("HII") warrants its products to be free from defects in materials and workmanship and to conform to HII’s published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any HII product which is (i) improperly installed or used;...
  • Page 202 This warranty shall extend from the time of shipment for the duration published by HII for the product at the time of purchase ("Warranty Period"). Any defective product must be returned (at purchaser’s expense) during the Warranty Period to HII factory or authorized service center for inspection. No product will be accepted by HII without a Return Materials Authorization, which may be obtained by contacting HII.

  • Page 203: Appendix A - Reference Charts

    Reference Charts Symbology Chart Possible AIM ID Code ID Symbology AIM ID Modifiers (hex) ( m ) All Symbologies (0x99) Australian Post A (0x41) ]z m Aztec Code 0-9, A-C z (0x7A) British Post B (0x42) Canadian Post C (0x43) China Post Q (0x51) Chinese Sensible Code (Han Xin...
  • Page 204 Possible AIM ID Code ID Symbology AIM ID Modifiers (hex) ( m ) GS1 Composite ]e m y (0x79) GS1 DataBar ]e m y (0x79) InfoMail , (0x2c) Intelligent Mail Barcode M (0x4D) Interleaved 2 of 5 ]I m 0, 1, 3 e (0x65) Japanese Post J (0x4A)
  • Page 205 Possible AIM ID Code ID Symbology AIM ID Modifiers (hex) ( m ) UPC-A with Extended c (0x63) Coupon Code UPC-E E (0x45) UPC-E with Add-On E (0x45) UPC-E1 E (0x45) Note: “m” represents the AIM modifier character. Refer to International Technical Specification, Symbology Identifiers, for AIM modifier character details.

  • Page 206: Ascii Conversion Chart (Code Page 1252

    ASCII Conversion Chart (Code Page 1252 Note: This table applies to U.S. style keyboards. Certain characters may differ depending on your Country Code/PC regional settings. Non-Printable Characters DEC HEX Character (Code) DEC HEX Character (Code) NULL DATA LINK ESCAPE (DLE) START OF HEADING DEVICE CONTROL 1 (DC1) (SOH)
  • Page 207 Printable Characters (Continued) DEC HEX Character DEC HEX Character DEC HEX Character < > <DEL> Extended ASCII Characters DEC HEX Character DEC HEX Character DEC HEX Character € € « Ö ¬ × ‚ Ø ƒ ® Ù „ ¯ Ú...

  • Page 208: Code Page Mapping Of Printed Bar Codes

    Extended ASCII Characters (Continued) DEC HEX Character DEC HEX Character DEC HEX Character Œ · â ¸ ã Ž ¹ ä º å » æ ‘ ¼ ç ’ ½ è “ ¾ é ” ¿ ê • À ë –...
  • Page 209 the one the host program is expecting. If this is the case, select the code page with which the bar codes were created. The data characters should then appear properly. Code Page Standard Description CP ISO646 2 (Default) ISO 2022 Automatic National Replacement Characters CP Binary...
  • Page 210 A - 8...
  • Page 213 Sample Symbols UPC-A Interleaved 2 of 5 0 123456 7890 Code 128 1234567890 EAN-13 Code 128 Code 39 9 780330 290951 Codabar BC321 Code 93 A13579B Straight 2 of 5 Industrial 123456-9$ 123456...
  • Page 214 Sample Symbols Matrix 2 of 5 GS1 DataBar 6543210 PDF417 (01)00123456789012 Car Registration Postnet Zip Code Data Matrix QR Code Test Symbol Numbers 4-CB (4-State Customer Bar Code) 01,234,567094,987654321,01234567891 ID-tag (UPU 4-State) J18CUSA8E6N062315014880T...
  • Page 215 Sample Symbols Aztec Micro PDF417 Package Label MaxiCode Test Message Test Message...
  • Page 216 Programming Chart...
  • Page 217 Programming Chart Save Discard Reset Note: If you make an error while scanning the letters or digits (before scanning Save), scan Discard, scan the correct letters or digits, and Save again.
  • Page 218 Honeywell Scanning & Mobility 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com N86XX-UG Rev A 3/12...

This manual is also suitable for:

N868 3 seriesN868 2 seriesN868 5 seriesN869 2 seriesN869 3 seriesN869 5 series

Table of Contents
