Summary of Contents for Hawking HGU1
- Page 2 Hawking Customer Service in order to obtain a Return Authorization number. Warranty is for repair or replacement only. Hawking Technology does not issue any refunds. BE SURE TO HAVE YOUR PROOF OF PURCHASE.
- Page 3 Hawking Technology reserves the right to revise or update its products, software, or documentation without obligation to notify any individual entity.
-
Page 4: Table Of Contents
Table of Contents OVERVIEW... 2 System Requirements ... 3 Operating Systems... 3 Package Contents ... 3 PART NAMES AND FUNCTIONS ... 4 Parts Names and Functions ... 4 Hardware Installation ... 5 Getting Hooked Up... 5 Software Installation... 6 Installation for Windows 2000 ... 6 Installation for Windows XP... -
Page 5: Overview
Internet solution for Laptop or Desktop users. Use it to connect to your Home, Office, or Gaming Networks. The HGU1 Gigabit USB Ethernet Adapter enables you to plug into an available Universal Serial Bus port and connect your desktop or laptop with out the hassle of taking apart your computer. -
Page 6: System Requirements
SYSTEM REQUIREMENTS CD-ROM Drive An Available USB Port Windows 2000 or XP 1000Base-T Gigabit Ethernet, 100Base-TX Fast Ethernet or 10BaseT Ethernet connectivity to your local area network. Cable requirements: One Ethernet Cable Port Type 10Base-T 100/1000Base-T Operating Systems Windows 2000 and XP. Package Contents One Gigabit USB Adapter One USB Cable... -
Page 7: Part Names And Functions
PART NAMES AND FUNCTIONS Parts Names and Functions USB Device Cable (Type A-to-Type B connection): Connects the HGU1 Gigabit Adapter to your computer (USB host port). USB Type-B Device Port: USB port for the USB Device Cable. USB Gigabit Network Adapter Link LED indicator: 10M: Yellow &... -
Page 8: Hardware Installation
2. Connect the other end of the USB device cable into the USB Type- B Device port. 3. Connect the Ethernet Cable in to the HGU1’s ethernet port 4. Connect the other end of the Ethernet Cable into a Hub. -
Page 9: Software Installation
SOFTWARE INSTALLATION Installation for Windows 2000 After you finish with the hardware installation, turn on your computer if you haven’t done so already. automatically detect the newly installed hardware. A “Welcome to the Found New Hardware Wizard” will help you to install the device driver. - Page 10 Insert the HGU1 software CD into your CD-Rom drive. Select Specify a location and then click Next. Click Browse to select the driver folder and then click OK. When the Driver Files Search Results screen appears, click Next. - 7 -...
- Page 11 You will receive the message “Digital Signature Not Found”. Click Yes to continue the installation. When Windows has finished installing the software for this device. Click Finish. - 8 -...
-
Page 12: Installation For Windows Xp
The Welcome to the Found New Hardware Wizard will prompt you to insert the installation CD. HGU1 Software CD now and select Install the software automatically Recommended). Click Next to continue. 2. Select “Search for the best driver in these locations” and “Include this location in the search.”... - Page 13 3. Windows will start searching for the driver. When the following screen appears, click Continue Anyway. When the wizard has finished installing the software. Click Finish. Go to Start Control Panel click Local Area Connections. When the Network dialog box appears, click Install to set the appropriate protocols and client.
-
Page 14: Setup Diagnostics
Restart your computer to activate the HGU1 USB Gigabit Adapter. Setup Diagnostics To verify if the HGU1 is installed properly, go to Start Panel System Hardware. Select Device Manager. If the 10/100 Gigabit USB2.0 Ethernet Adapter device name is found, then you have successfully installed the HGU1 USB Gigabit Adapter. -
Page 15: Specifications
SPECIFICATIONS Network Specifications IEEE802.3 10BaseT, 802.3u 100BaseTX and 802.3ab 1000Base-T. Cat3/Cat5 UTP cable up to 328ft/100M. Host Interface High-power Bus-powered from USB HOST or HUB, no external power needed. Full Speed/High Speed USB device, upstream B USB port. Suspend power saving mode supported. Supported operating systems Windows 2000 and XP LED Indicators...
