Hawking HFS16T Specification

C A R E F R E E N E T W O R K I N G
Fast and Easy Networking
The Hawking HFS16T is an ideal solution for workgroup and enterprise
users, and is designed for easy installation, high performance, and seamless
migration between 10Base-T and 100Base-TX network speeds. The switch includes
(16) 10/100M auto-negotiation, auto-MDI/MDIX ports and provides a flexible,
reliable, and affordable solution for an Ethernet network. Each port delivers up to
200Mbps throughput, which can give workstations a congestion-free data pipe for
simultaneous access to the server.
duplex modes, and store-and-forward architecture filters eliminate error packets
and improve efficiency. In addition, the HFS16T can be expanded by cascading two
or more switches together. And the built-in universal power supply lets you easily
install the switch without an external power adapter.
Features
(16) 10/100M auto-negotiation, auto-MDI/MDIX Ethernet ports
Complies with IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX standards
Supports store-and-forward architecture and performs forwarding and filtering
at non-blocking full wire-speed
Supports "Link/Activity" LED modes with "Power" (on) auto diagnostic
Supports IEEE 802.3x flow control for full duplex operation
Supports back pressure for half duplex operation
Built-in 12K x 64 SRAM
Supports packet lengths of up to 1522 bytes
Supports 2K MAC address entries
Supports aging function (300 seconds)
Broadcast Storming filter function
Built-in universal power supply (100-240V AC)
EMI certifications: FCC Class A, CE Mark
Network Requirements:
IEEE 802.3 10Base-T, or 802.3u 100Base-TX Ethernet
16-Port
C O N N E C T W H E R E V E R Y O U W A N T
The switch can operate in either half or full-
10/100M
Rack Mount Switch
• W H E N E V E R Y O U W A N T
H FS 16 T
(16) 10/100M Auto-negotiation,
Auto-MDI/MDIX Ports
19" 1U Rack Mount
Two Year Warranty
PACKAGE CONTENTS:
One HFS16T 16-Port 10/100M Rack Mount Switch
Four Rubber Feet with Adhesive Backing
19" Rack Mount Kit
One Power Cord
One User's Manual
