2016 RX 350/450h Pre-Delivery Service Manual
Lexus Technician:
Before you perform Pre-Delivery Service (PDS) on this vehicle, be sure you:
• Read and understand this PDS Manual
• Read and understand all applicable PDS Technical Service Information Bulletins (TSIBs) for this vehicle
• Read and understand the PDS Precautions in the TSIBs and on pages 0, 4 and 56.
• Attend the "Technical Introduction to Lexus Course L005" at the Lexus Area Office
When performing PDS on this vehicle:
• Use the PDS Manual when performing this service
• Check the Technical Information System (TIS) for any updated PDS TSIBs that apply to the model you are
servicing
• Verify that the Vehicle Identification Number (VIN) on repair order and vehicle match
• Lift vehicle and perform under vehicle safety/damage inspection
• Road test vehicle long enough to test hot engine and drive over rough road (Bott dots) to test for rattles/
squeaks
The following TSIBs are available on TIS:
Battery Maintenance for In-Stock Vehicles & Pre-Delivery (Revised)
D/C Cut Fuse Installation during PDS
Enform Apps & Data Services Download & Installation Process
Floor Mat Installation during PDS
Front License Plate & Mounting Bracket Installation
Hybrid System Electrical Safety Precautions
Initial Calibration of Compass during PDS
Long-Term Vehicle Storage Guidelines
Maintenance for HV & Auxiliary Batteries
Parking Assist Monitor System Initialization
Tire Positioning Before New Vehicle Delivery
Tire Pressure Warning System Initialization
XM Activation Confirmation during PDS
TPWS Operation Verification
1. Connect Techstream to DLC3.
2. Adjust all tires, including the spare tire, to the standard tire inflation pressure as indicated on the tire and
loading information label on vehicle.
NOTE:
• To adjust tire pressure correctly when outside temperature is significantly colder or warmer than shop
temperature, perform a Health Check using Techstream and select the "Compensation Tire Pressure"
check box. Compensation pressures will be displayed on the Health Check results screen.
• Adjust the tire pressure when the tires are cold.
To obtain PDS material:
Manual
• Download from TIS website or Lexus Customer Services website on Dealer Daily
Check Sheet
• Download and print from TIS website or Lexus Customer Services website on Dealer Daily
• Sheet is two-sided; back side has procedure tips
Other PDS TSIBs
• Download from TIS website
Contact your District Service & Parts Manager if you have any questions.
ENGINE = POWER switch on hybrid models
© 2015 Lexus, a Division of Toyota Motor Sales USA, Inc.
JBS 20151012
