Reliable GFR Quick Start Manual

Model GFR Sprin kler Types
Stan dard Up right
Stan dard Pen dent
Horizontal Side wall
HSW1 De flec tor
In ter me di ate Level Up right
In ter me di ate Level Pen dent
Con ven tional
Model GFR Re cessed
Sprin kler Types
Re cessed Pen dent
Re cessed Hor i zon tal Side wall
HSW1 De flec tor
Ap provals
1. Un der writers Lab o ra tories, Inc. (UL)
2. Un der writers' Lab o ra tories of Can ada (ULC)
3. NYC BS&A No. 587-75-SA
6. MIL-S-901C and MIL-STD-167-1
7. NYC MEA 258-93-E
Up right
Con ven tional
The Re li able Au to matic Sprin kler Co., Inc. 525 North MacQuesten Park way, Mount Vernon, New York 10552
In ter me di ate
Pen dent
Level Pen dent
Hor i zon tal Side wall
HSW 1 De flec tor
Model GFR
Model GFR Re cessed
Quick Re sponse
Sprin klers
UL List ing Cat e gory
Sprin klers, Au to matic & Open
Quick Re sponse Sprin kler
UL Guide Num ber
VNIV
Prod uct De scrip tion
Re li able Models GFR and GFR Re cessed Sprin klers are
Quick Response fus ible sol der type au to matic sprin klers.
These sprin klers have dem on strated re sponse times in
lab o ra tory tests which are five times faster than stan dard
re sponse sprin klers.
This quick re sponse en ables the Models GFR and
GFR Re cessed Sprin klers to ap ply wa ter to a fire much
faster than stan dard re sponse sprin klers of the same
tem per a ture rat ing.
Ap pli ca tion
Quick re sponse sprin klers are used in fixed fire pro tec -
tion sys tems: Wet, Dry, De luge or Preaction. Care must
be ex er cised that the or i fice size, tem per a ture rat ing, de -
flec tor style and sprin kler spac ing are in ac cor dance with
the lat est pub lished stan dards of the Na tional Fire Pro tec -
tion As so ci a tion or the ap prov ing Au thor ity Hav ing Ju ris -
dic tion. Quick response sprinklers are in tended for
stan dard area cov er age and stan dard wa ter den si ties as
spec i fied in NFPA 13. Quick re sponse sprinklers and
stan dard re sponse sprin klers should not be in ter mixed.
In ter me di ate
Level Up right
Re cessed
Re cessed Pen dent
Hor i zon tal Side wall
HSW 1 De flec tor
Bul le tin 131 H
Rev.
Small Or i fice Up right
